复合材料层合板缺口强度的CDM三维数值模型

李秋漳; 姚卫星; 陈方

doi:10.13801/j.cnki.fhclxb.20160328.001

复合材料层合板缺口强度的CDM三维数值模型

1.
南京航空航天大学飞行器先进设计技术国防重点学科实验室, 南京 210016;
2.
南京航空航天大学机械结构力学及控制国家重点实验室, 南京 210016

基金项目: 国家自然科学基金（11202098）

详细信息

通讯作者:
姚卫星,博士,教授,研究方向为飞行器综合设计和结构设计。E-mail:wxyao@nuaa.edu.cn

中图分类号: TB330.1;V214.8
计量
- 文章访问数: 1232
- HTML全文浏览量: 71
- PDF下载量: 311
出版历程
- 收稿日期: 2015-12-14
- 修回日期: 2016-03-18
- 刊出日期: 2016-12-14

CDM three-dimensional numerical model for notched strength of composite laminates

1.
Key Laboratory of Fundamental Science for National Defense-Advanced Design Technology of Flight Vehicle, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China;
2.
State Key Laboratory of Mechanics and Control of Mechanical Structures, Nanjing University of Aeronautics and Astronautics, Nanjing 210016, China

摘要

摘要: 针对复合材料层合结构缺口强度问题，基于连续损伤力学（CDM）提出了一种三维损伤数值模型。模型区分了层内损伤（纤维失效、纤维间失效）和层间分层损伤的不同失效模式。采用三维Puck准则与Aymerich准则对上述2类损伤进行判定，材料失效后基于CDM中线性软化模型对材料损伤进行演化。模型考虑了复合材料层合板子层的就位效应和剪切非线性行为。对Carlsson的AS4/3501-6缺口拉伸强度试验进行数值模拟。结果表明：分析结果与试验结果吻合良好，证明了该模型能够准确地预测含缺口复合材料层合板面内拉伸强度。
- 复合材料 /
- 缺口强度 /
- 就位效应 /
- 三维Puck准则 /
- 渐进损伤
Abstract: A three-dimensional damage numerical model was proposed based on continuum damage mechanics (CDM) to deal with problem of the notched strength of composite laminates. This model was able to distinguish different failure modes of in-plane damage (fiber failure, inter fiber failure) and interlaminar delamination damage. Three-dimensional Puck criterion and Aymerich criterion were used to judge two kinds of damage above. The damage was evolved based on the linear softening model of CDM after material failure. The in-situ effect and the shear nonlinear behavior of composite laminate sublayers were considered in the model. The tensile strength of notched AS4/3501-6 laminate tested by Carlsson was numerical simulated. The results show that the analysis results are in good agreement with the test results. The analysis results prove that the present model is capable of predicting the in-plane tensile strength of notched composite laminates.
- composite /
- notched strength /
- in-situ effect /
- three-dimensional Puck criterion /
- progressive damage
