FeVO4/Cu3(BTC)2(H2O)3异质结制备及光催化性能

刘颖琪; 翁文斌; 岑檠; 肖维; 王齐; 丛燕青; 张轶

doi:10.13801/j.cnki.fhclxb.20200917.001

FeVO₄/Cu₃(BTC)₂(H₂O)₃异质结制备及光催化性能

doi: 10.13801/j.cnki.fhclxb.20200917.001

浙江工商大学　环境科学与工程学院，杭州 310018

基金项目: 国家自然科学基金(21876154)；浙江省自然科学基金(LR18B070001)

详细信息

通讯作者:
王齐，博士，教授，研究方向为光催化　E-mail：wangqi8327@zjgsu.edu.cn

中图分类号: O643
计量
- 文章访问数: 1308
- HTML全文浏览量: 346
- PDF下载量: 91
- 被引次数: 0
出版历程
- 收稿日期: 2020-07-23
- 录用日期: 2020-09-15
- 网络出版日期: 2020-09-17
- 刊出日期: 2020-12-15

Preparation and photocatalytic properties of FeVO₄/Cu₃(BTC)₂(H₂O)₃ heterojunction

School of Environmental Science and Engineering, Zhejiang Gongshang University, Hangzhou 310018, China

摘要

摘要: 以Cu片和1, 3, 5-苯三甲酸为原料，电化学法制备经典Cu-MOF材料Cu₃(BTC)₂(H₂O)₃，即HKUST-1，作为基底金属有机框架材料(MOFs)，采用室温沉积法制备FeVO₄/HKUST-1异质结复合材料，通过XRD、SEM、BET、UV-Vis DRS等对其晶体结构、形貌、比表面积、光吸收性能等进行了表征。结果表明：FeVO₄与HKUST-1复合形成异质结后，有利于光生电子-空穴的产生和转移，对目标染料污染物罗丹明B(RhB)的降解性能显著增强。可见光照射120 min后，异质结体系中RhB的降解率可达93%，而单一FeVO₄或HKUST-1体系中仅为12%和5%。此外，对材料的组成比例进行了优化，当FeVO₄与HKUST-1摩尔比为1∶1时，制备的FeVO₄/HKUST-1复合材料具有最佳的光催化性能。进一步，考察了其循环使用的稳定性，循环5次后对RhB的降解效率仍保持在90%以上，稳定性良好。
- 金属有机骨架(MOFs) /
- FeVO₄ /
- 电化学法 /
- 复合材料 /
- 光催化
Abstract: The classic Cu-MOF material Cu₃(BTC)₂(H₂O)₃, which was also named HKUST-1, was prepared by electrochemical method using Cu flakes and 1, 3, 5-benzenetricarboxylic acid as the raw materials. Furthermore, the FeVO₄/HKUST-1 heterojunction composites were prepared by room temperature deposition using HKUST-1 as the base metal organic framework material (MOFs). The crystal structure, morphology, specific surface area and optical absorption properties were characterized by XRD, SEM, BET, UV-Vis DRS, etc. The results indicate that the formation of the heterojunction between FeVO₄ and HKUST-1 is beneficial for the generation and transfer of the photogenerated electron-hole pairs. The degradation performance of target dye pollutant rhodamine B (RhB) is significantly enhanced. After visible light irradiating for 120 min, the degradation efficiency to RhB can reach 93% in the heterojunction system, while only 12% and 5% can be observed in the system of FeVO₄or HKUST-1, respectively. In addition, the composition ratio of the composite was also optimized. When the molar ratio of FeVO₄ to HKUST-1 is 1∶1, the as-prepared FeVO₄/HKUST-1 composite has the best photocatalytic performance. Furthermore, the stability was investigated. After 5 cycles, the degradation efficiency to RhB is still above 90%, indicating good stability of the FeVO₄/HKUST-1 composite.
- metal organic framework material (MOFs) /
- FeVO₄ /
- electrochemical method /
- composite /
- photocatalysis

HTML全文

图 1 FeVO₄、HKUST-1和FeVO₄/HKUST-1的XRD图谱

Figure 1. XRD patterns of FeVO₄, HKUST-1 and FeVO₄/HKUST-1

下载: 全尺寸图片幻灯片

图 2 FeVO₄(a)、HKUST-1(b)、FeVO₄/HKUST-1((c),(d))的SEM图像

Figure 2. SEM images of FeVO₄(a), HKUST-1 (b) and FeVO₄/HKUST-1 ((c), (d))

下载: 全尺寸图片幻灯片

图 3 FeVO₄、HKUST-1和FeVO₄/HKUST-1的吸附-脱附曲线

Figure 3. Adsorption-desorption isotherms of FeVO₄, HKUST-1 and FeVO₄/HKUST-1

下载: 全尺寸图片幻灯片

图 4 FeVO₄、HKUST-1和FeVO₄/HKUST-1的TAG曲线

Figure 4. TGA curves of FeVO₄, HKUST-1 and FeVO₄/HKUST-1

下载: 全尺寸图片幻灯片

图 5 FeVO₄、HKUST-1、FeVO₄/HKUST-1的紫外/可见漫反射光谱(a)及带隙图(b)

Figure 5. UV-Vis DRS (a) and band gap (b) of FeVO₄, HKUST-1 and FeVO₄/HKUST-1

下载: 全尺寸图片幻灯片

图 6 FeVO₄、HKUST-1、FeVO₄/HKUST-1的光电流(a)和交流阻抗谱(b)

Figure 6. Photocurrent (a) and EIS Nyquist plots (b) of FeVO₄, HKUST-1 and FeVO₄/HKUST-1

下载: 全尺寸图片幻灯片

图 7 不同比例的FeVO₄/HKUST-1对RhB的降解动力学曲线(a)和准一级动力常数拟合(b)

Figure 7. Degradation (a) and pseudo-first-order kinetic curves (b) of RhB with different proportions of FeVO₄/HKUST-1

下载: 全尺寸图片幻灯片

图 8 可见光下FeVO₄/HKUST-1催化剂光催化降解不同污染物的效果

Figure 8. Reduction of different dyes by FeVO₄/HKUST-1 under visible light irradiation

下载: 全尺寸图片幻灯片

图 9 不同pH下FeVO₄/HKUST-1对RhB的降解动力学曲线

Figure 9. Degradation kinetics curves of RhB under different pH values

下载: 全尺寸图片幻灯片

图 10 FeVO₄/HKUST-1降解染料循环稳定性

Figure 10. Stability of FeVO₄/HKUST-1 for degradation of dye

下载: 全尺寸图片幻灯片

图 11 HKUST-1和FeVO₄的Mott-Schottky曲线

Figure 11. Mott-Schottky plots of HKUST-1 and FeVO₄

下载: 全尺寸图片幻灯片

图 12 不同光催化捕获剂的捕获效率(a) 和FeVO₄/HKUST-1在可见光下照射的ESR图谱(b)

Figure 12. Removal efficiency with addition of different scavengers (a) and ESR signals of FeVO₄/HKUST-1 under visible light (b)

下载: 全尺寸图片幻灯片

图 13 FeVO₄/HKUST-1光催化降解RhB反应机制示意图

Figure 13. Proposed mechanism for photocatalytic reduction of RhB by FeVO₄/HKUST-1

下载: 全尺寸图片幻灯片

参考文献(28)

[1]	NASAR A, MASHKOOR F. Application of polyaniline-based adsorbents for dye removal from water and wastewater—A review[J]. Environmental Science and Pollution Research,2019,26(6):5333-5356.
[2]	WANG Q, GAO Q, WU H, et al. In situ construction of semimetal Bi modified BiOI-Bi₂O₃ film with highly enhanced photoelectrocatalytic performance[J]. Separation and Purification Technology,2019,226:232-240.
[3]	TIAN J W, WU Y P, LI Y S, et al. Integration of semiconductor oxide and a microporous(3, 10)-connected Co₆-based metal–organic framework for enhanced oxygen evolution reaction[J]. Inorganic Chemistry,2019,58(9):5837-5843.
[4]	WEI J H, YI J W, HAN M L, et al. A water-stable terbium(III)–organic framework as a chemosensor for inoranic ions, nitro-containing compounds and antibiotics in aqueous solutions[J]. Chemistry–An Asian Journal,2019,14(20):3694-3701.
[5]	HUANG D, WU X, TIAN J, et al. Assembling of a novel 3D Ag(I)-MOFs with mixed ligands tactics: Syntheses, crystal structure and catalytic degradation of nitrophenol[J]. Chinese Chemical Letters,2018,29(6):845-848.
[6]	WU Y P, ZHOU W, ZHAO J, et al. Surfactant-assisted phase-selective synthesis of new cobalt MOFs and their efficient electrocatalytic hydrogen evolution reaction[J]. Angewandte Chemie,2017,129(42):13181-13185.
[7]	WANG Q, GAO Q Y, Al-ENIZI A M, et al. Recent advances in MOF-based photocatalysis: Environmental remediation under visible light[J]. Inorganic Chemistry Frontiers,2020,7(2):300-339.
[8]	FU J, JIANG K, QIU X, et al. Product selectivity of photocatalytic CO₂reduction reactions[J]. Materials Today,2020,32:222-243.
[9]	XU Q, ZHU B, JIANG C, et al. Constructing 2D/2D Fe₂O₃/g-C₃N₄ direct Z-scheme photocatalysts with enhanced H₂ generation performance[J]. Solar RRL, 2018, 2(3): 1800006.
[10]	RAN J, GUO W, WANG H, et al. Metal-free 2D/2D phosphorene/g-C₃N₄ Van der Waals heterojunction for highly enhanced visible-light photocatalytic H₂ production[J]. Advanced Materials,2018,30(25):1800128.
[11]	HERMES S, SCHRODER F, CHELMOWSKI R, et al. Selective nucleation and growth of metal−organic open framework thin films on patterned COOH/CF₃-terminated self-assembled monolayers on Au(111)[J]. Journal of the American Chemical Society,2005,127(40):13744-13745.
[12]	魏金枝, 王雪亮, 孙晓君, 等. 绿色电化学法合成金属有机骨架材料的研究现状[J]. 材料导报A: 综述篇, 2018, 32(5):1345-1441. WEI Jinzhi, WANG Xueliang, SUN Xiaojun, et al. Research status of green electrochemical synthesis of metal organic skeleton materials[J]. Material Guide A: Overview,2018,32(5):1345-1441(in Chinese).
[13]	SUN B, KAYAL S, CHAKRABORTY A. Study of HKUST-1(copper benzene-1, 3, 5-tricarboxylate Cu-BTC MOF)-1 metal organic frameworks for CH₄ adsorption: An experimental investigation with GCMC (grand canonical Monte-carlo) simulation[J]. Energy,2014,76:419-427.
[14]	XU Q, ZHANG L, CHENG B, et al. S-scheme heterojunction photocatalyst[J]. Chem, 2020, 6(7): 1-17.
[15]	JIN M, QIAN X F, GAO J K, et al. Solvent-free synthesis of CuO/HKUST-1 composite and its photocatalytic application[J]. Inorganic Chemistry,2019,58(13):8332-8338.
[16]	SOFI F A, MAJID K, MEHRAJ O. The visible light driven copper based metal-organic-framework heterojunction: HKUST-1@Ag-Ag₃PO₄ for plasmon enhanced visible light photocatalysis[J]. Journal of Alloys and Compounds,2018,737:798-808.
[17]	OZTURK B, SOYLU G S P. Synthesis of surfactant-assisted FeVO₄ nanostructure: Characterization and photocatalytic degration of phenol[J]. Journal of Molecular Catalysis A-Chemical,2015,398:65-71.
[18]	DU X D, WANG C C, LIU J G, et al. Extensive and selective adsorption of ZIF-67 towards organic dyes: Performance and mechanism[J]. Journal of Colloid and Interface Science,2017,506:437-441.
[19]	ZHOU G, DU Z, MA Y, et al. Molecular simulation study on gas adsorption and separation performance of alkyl-functionalized HKUST materials[J]. Computational Materials Science,2020,181:109755.
[20]	HU S J, YANG J, LIAO X H. Highly efficient degradation of methylene blue on microwave synthesized FeVO₄ nanoparticles photocatalysts under visible-light irradiation[J]. In Applied Mechanics and Materials, 2013, 372: 153-157.
[21]	MOSLEH S, RAHIMI M R, GHAEDI M, et al. HKUST-1-MOF–BiVO₄ hybrid as a new sonophotocatalyst for simultaneous degradation of disulfine blue and rose bengal dyes: Optimization and statistical modelling[J]. RSC Advances,2016,6(66):61516-61527.
[22]	SI Y, LIU G, DENG C, et al. Facile synthesis and electrochemical properties of amorphous FeVO₄ as cathode materials for lithium secondary batteries[J]. Journal of Electroanalytical Chemistry,2017,787:19-23.
[23]	NIU X, ZHANG Y, TAN L, et al. Amorphous FeVO₄ as a promising anode material for potassium-ion batteries[J]. Energy Storage Materials,2019,22:160-167.
[24]	LIN K Y A, HSIEH Y T. Copper-based metal organic framework (MOF), HKUST-1, as an efficient adsorbent to remove p-nitrophenol from water[J]. Journal of the Taiwan Institute of Chemical Engineers,2015,50:223-228.
[25]	KIM H K, YUN W S, KIM M B, et al. A Chemical route to activation of open metal sites in the copper-based metal–organic framework materials HKUST-1 and Cu-MOF-2[J]. Journal of the American Chemical Society,2015,137(31):10009-10015.
[26]	DUTTA D P, RAMAKRISHNAN M, ROY M, et al. Effect of transition metal doping on the photocatalytic properties of FeVO₄nanoparticles[J]. Journal of Photochemistry and Photobiology A: Chemistry,2017,335:102-111.
[27]	JIAO Z, GUAN X, WANG M, et al. Undamaged depositing large-area ZnO quantum dots/RGO films on photoelectrodes for the construction of pure Z-scheme[J]. Chemical Engineering Journal,2019,356:781-790.
[28]	LI J, ZHAO W, GUO Y, et al. Facile synthesis and high activity of novel BiVO₄/FeVO₄ heterojunction photocatalyst for degradation of metronidazole[J]. Applied Surface Science,2015,351:270-279.
