复合材料加筋壁板轴压屈曲载荷工程估算新方法

A new engineering method for predicting the axial compression buckling load of composite stiffened panels

  • 摘要: 加筋壁板是飞机机翼、尾翼和机身结构上普遍采用的典型结构形式,当机翼、尾翼结构受气动载荷作用时,机翼上翼面加筋壁板处于受压状态,受压壁板易发生屈曲甚至破坏。本文基于前期复合材料加筋壁板轴压稳定性工程算法研究,并借鉴已在工程上成熟应用的金属加筋壁板轴压稳定性工程方法,提出了一种能够合理预测复合材料加筋壁板轴压屈曲载荷的工程算法。通过选取2类加强筋形式,其中3种Y型及2种J型,共5种复合材料加筋壁板为算例,对5种复合材料加筋壁板的轴压屈曲载荷进行了计算,并开展了有限元数值模拟与试验验证。此工程算法的计算结果与试验值对比,相对误差均在10%以内。与有限元计算结果对比,除一种Y型长桁加筋壁板计算结果在10%,其余构型相对误差均在5%,满足工程要求,证明此种方法的有效性,此种工程算法已经在型号飞机研制中得以应用。此外,发现对加筋壁板长桁缘条的削弱会降低复合材料加筋壁板的屈曲载荷,而Y型加筋壁板削弱中间两长桁,可以使长桁与蒙皮刚度更加匹配,提升Y型长桁加筋壁板的破坏应变水平。



    Abstract: Composite stiffened panel is typical structural form, which is widely used in aircraft wing, tail, and fuselage structures. When suffering aerodynamic loading, such composite stiffened panel on the wing surface of the wing is under compressive pressure, and this pressure could cause such panel to buckle or even failure. In this paper, an engineering method of reasonably predicting the buckling load of composite stiffened panels under axial compression is proposed, according to previous research on the stability engineering method composite stiffened panels under axial compression and stability engineering method of metal stiffened panels under axial compression which has been maturely applied in engineering. Therefore, two kinds of reinforcement composite stiffened panels (i.e., three types of Y type and two types of J type) are considered. The axial buckling load of the example is calculated by using the engineering method proposed in this paper, and the finite element numerical simulation and test verification are carried out. Compared with the experimental results, the relative error of the engineering method is less than 10%. Compared with the finite element calculation results, the relative errors of the other configurations are 5% except for one Y-shaped truss stiffened panel which is 10%, which meets the engineering requirements and proves the effectiveness of this method. This engineering method has been applied in the development of model aircraft. In addition, it is found that the weakening of the stringer edge of the stiffened panel will reduce the buckling load of the composite stiffened panel, and the weakening of the middle two stringers of the Y-stiffened panel can make the stringers more match the stiffness of the skin, and improve the failure strain level of the Y-stiffened panel.



/
