木基柔性电子复合膜的制备及其在传感器中的应用

王怡仁; 周彤; 王露臻; 吴启静; 李大纲; 金永灿; 陈楚楚

doi:10.13801/j.cnki.fhclxb.20211027.001

木基柔性电子复合膜的制备及其在传感器中的应用

王怡仁¹,
周彤¹,
王露臻¹,
吴启静¹,
李大纲¹,
金永灿²,
陈楚楚^{1, 2, ,}

1.
南京林业大学　材料科学与工程学院，南京 210037
2.
南京林业大学　轻工与食品学院，南京 210037

基金项目: 国家自然科学基金(31901254)；江苏省研究生科研与实践创新计划项目(KYCX21_0873)；第14批中国博士后科学基金(2021T140329)；中国博士后科学基金面上项目(2020M671506)；江苏省博士后科研资助计划(2020Z027)

详细信息

通讯作者:
陈楚楚，博士，副教授，硕士生导师，研究方向为纤维素、甲壳素、复合材料　E-mail：chuchu_chen@njfu.edu.cn

中图分类号: TB332
计量
- 文章访问数: 1364
- HTML全文浏览量: 732
- PDF下载量: 75
出版历程
- 收稿日期: 2021-08-01
- 修回日期: 2021-10-15
- 录用日期: 2021-10-17
- 网络出版日期: 2021-10-26
- 刊出日期: 2022-08-30

Preparation of flexible wood-based electronic films and its application for sensors

1.
College of Materials Science and Engineering, Nanjing Forestry University, Nanjing 210037, China
2.
College of Light Industry and Food Engineering, Nanjing Forestry University, Nanjing 210037, China

摘要

摘要: 为拓展木材多功能化及高值化应用，以轻木为原料，通过脱基质工艺去除木材基质，随后干燥处理获得轻木骨架(WF)，进一步乙酰化改性后干燥可制得乙酰化轻木骨架(AWF)。利用浸渍法，将聚二甲基硅氧烷(PDMS)弹性体分别引入WF与AWF制备木基复合薄膜材料(PDMS/WF与PDMS/AWF)。系统性研究乙酰化改性对复合膜形貌特征、力学性能、化学组分及表面亲水性等的影响。结果表明，乙酰化处理能够有效促进PDMS分布于轻木骨架的孔隙结构中，二者结合紧密，界面结合性提高。同时，制得的PDMS/AWF木基复合膜具备较好的柔韧性，沿纤维生长方向断裂拉伸强度达176 MPa，韧性约6.58 MJ/m³，几乎是PDMS/WF复合膜的两倍。进一步将该PDMS/AWF木基复合膜作为柔性基材，组装柔性传感器件，在多种形变下表现出稳定及可重复的相对电阻值变化。预期在智能家居、软体机器人及柔性可穿戴电子等智能响应器件研究领域具有潜在的应用。
- 木材 /
- 聚二甲基硅氧烷 /
- 乙酰化 /
- 复合膜 /
- 柔性电子基材 /
- 传感器
Abstract: In order to expand multi-function and high-value application of wood, balsa wood was used as raw material. Firstly, they were performed with chemical treatment to remove the matrix including lignin and hemicellulose, followed with drying. The acetylated balsa wood frame (AWF) was prepared by acetylation modification. Afterwards, by vacuum impregnation, polydimethylsiloxane (PDMS) elastomer was introduced into balsa wood frame (WF) and AWF respectively, in order to fabricate composite film materials (PDMS/WF and PDMS/AWF). The effects of acetylation modification on morphology, mechanical properties, chemical composition and surface hydrophilicity of composite films were systematically studied. The results show that after acetylation, the interface between balsa wood frame and PDMS is more compact, and the pores between PDMS and white wood are smaller. At the same time, the tensile strength of PDMS/AWF composite film (along the fiber growth direction, L-direction) is around 176 MPa, and the toughness is about 6.58 MJ/m³, which is nearly twice as high as that of PDMS/WF compo-site film. Furthermore, the prepared PDMS/AWF wood-based composite film was used as a flexible substrate to assemble a flexible sensor. As a result, it shows stable and repeatable changes for relative resistance values under various deformations. Altogether, it has great potential to be applied in the research fields of smart furniture, elastic substrates of smart response devices, flexible electronic components and wearable devices.
- wood /
- polydimethylsiloxane /
- acetylation /
- composite film /
- flexible electronic substrate /
- sensor

HTML全文

图 1 聚二甲基硅氧烷/乙酰化轻木骨架(PDMS/AWF)复合膜制备流程示意图

Figure 1. Preparation process of polydimethylsiloxane/acetylated balsa wood frame (PDMS/AWF) composite film

WF—Balsa wood frame

下载: 全尺寸图片幻灯片

图 2 PDMS及木基复合膜试样表面微观形貌：(a) PDMS；(b) 轻木；(c) WF；(d) AWF；(e) PDMS/WF；(f) PDMS/AWF

Figure 2. Surface morphologies of PDMS and wood composite film samples: (a) PDMS; (b) Balsa wood; (c) WF; (d) AWF; (e) PDMS/WF; (f) PDMS/AWF

下载: 全尺寸图片幻灯片

图 3 木基复合膜试样断面微观形貌：((a), (b)) PDMS/WF；((c), (d)) PDMS/AWF

Figure 3. Fracture surface of wood composite film samples: ((a), (b)) PDMS/WF; ((c), (d)) PDMS/AWF

下载: 全尺寸图片幻灯片

图 4 WF、PDMS/WF及PDMS/AWF复合膜沿纤维生长方向(L-direction)拉伸应力-应变曲线

Figure 4. Tensile stress-strain curves of WF, PDMS/WF and PDMS/AWF composite films along longitudinal direction (L-direction)

下载: 全尺寸图片幻灯片

图 5 PDMS/WF及PDMS/AWF复合膜垂直于纤维生长方向(T-direction)的拉伸应力-应变曲线

Figure 5. Tensile stress-strain curves of PDMS/WF and PDMS/AWF composite films along perpendicular to the longitudinal direction (T-direction)

下载: 全尺寸图片幻灯片

图 6 PDMS、WF、AWF、PDMS/WF及PDMS/AWF复合膜的FTIR图谱

Figure 6. FTIR spectra of PDMS, WF, AWF, PDMS/WF andPDMS/AWF composite film

下载: 全尺寸图片幻灯片

图 7 PDMS/WF复合膜 (a) 及PDMS/AWF复合膜 (b) 水接触角测试

Figure 7. Water contact angle of PDMS/WF (a) and PDMS/AWF (b) film

下载: 全尺寸图片幻灯片

图 8 PDMS/AWF木基复合膜样品折叠(a)、打结(b)和组装柔性传感器(c)

Figure 8. PDMS/AWF composite film upon folding (a), knotting (b) and assembling into flexible sensors (c)

下载: 全尺寸图片幻灯片

图 9 木基柔性传感器弯曲折叠 (a)、点击 (b) 及书写 (c) 过程中的相对电阻(ΔR/R₀)变化

Figure 9. Relative resistance (ΔR/R₀) changes of flexible sensor upon repeated bending (a), clicking (b) and writing (c)

下载: 全尺寸图片幻灯片

表 1 WF膜、PDMS/WF复合膜及PDMS/AWF复合膜纤维生长方向拉伸应力-应变数值及PDMS在复合膜中质量分数

Table 1 Tensile stress-strain values of WF, PDMS/WF and PDMS/AWF film along L-direction and the mass fraction of PDMS

Sample	PDMS/wt%	Fracture strength/MPa	Young’s modulus/GPa	Fracture strain/%	Toughness /(MJ·m⁻³)
WF	0	213.26±3.58	12.44±0.05	2.93±0.21	4.23±0.03
PDMS/WF	53.39±0.65	164.58±12.65	11.46±0.10	3.25±0.35	3.41±0.11
PDMS/AWF	35.33±2.98	176.48±9.89	8.99±0.03	5.71±0.43	6.58±0.08

下载: 导出CSV
