复合催化材料纳米氧化铜颗粒(CuO NPs)@纤维素纳米纤丝(CNF)-Si-N(OH)2的制备及其对4-硝基苯酚的催化还原性能
doi: 10.13801/j.cnki.fhclxb.20220406.002
Preparation of catalytic composite copper oxide nanoparticles (CuO NPs)@cellulose nanofiber (CNF)-Si-N(OH)2 and its catalytic reduction of 4-nitrophenol
-
摘要: 针对目前降解工业废水中4-硝基苯酚(4-NP)的催化剂效率低，催化活性差等问题，以桉木漂白化学浆为原料，通过超微粒研磨机和高压均质机处理制备得到直径50~100 nm和长度1500~2000 nm的纤维素纳米纤丝(CNF)，在其表面原位负载纳米氧化铜颗粒(CuO NPs)，并通过3-氯丙基三甲氧基硅烷(CPTES)与二乙醇胺(DEA)进行接枝反应制备得到复合催化材料-CuO NPs@CNF-Si-N(OH)2。探讨了DEA添加量对CuO NPs@CNF–Si–N(OH)2的性能影响，采用Zeta电位、FTIR、XRD、XPS、热重分析和形貌分析等方法对复合材料进行了表征。结果表明，CuO NPs被原位还原并成功负载在CNF表面，其直径约为3.84 nm，负载量为3.83wt%，通过硅烷化改性及接枝胺基可提高CuO NPs在复合材料表面的分散性及稳定性，进而增强了其催化活性。CNF基复合催化材料对4-NP的催化还原结果显示，DEA添加量为20wt%下的CuO NPs@CNF-Si-N(OH)2对4-NP催化还原性能最佳，在180 s内可催化还原98.39%的4-NP，且反应符合伪一级动力学模型，表观速率常数为5.50×10−3 s−1，转化效率为1723.41 h−1，研究结果可为高性能催化复合材料的制备提供新思路和新途径。Abstract: In view of the low efficiency and poor catalytic activity of 4-nitrophenol (4-NP) catalysts for degradation of industrial wastewater, eucalyptus wood bleaching chemical pulp was used as the raw material and treated with ultrafine grinder and high pressure homogenizer to produce cellulose nanofiber (CNF) with the diameter of 50-100 nm and the length of 1500-2000 nm. Then, copper oxide nanoparticles (CuO NPs) were in-situ loaded onto CNF, 3-chloropropyltrimethoxysilane (CPTES) and diethanolamine (DEA) were added for grafting reaction to obtain the catalytic composite of CuO NPs@CNF-Si-N(OH)2. The catalytic composite was characterized with Zeta potential, FTIR, XRD, XPS, thermal gravimetric analysis and morphology analysis. The results show that CuO NPs are in-situ loaded on CNF, and the grafting of amine groups can make the loading of CuO NPs more uniform and stable. In addition, it is also found that CuO NPs@CNF-Si-N(OH)2 show the optimal catalytic performance with 20wt% DEA. Furthermore, 98.39% of 4-NP is catalytically reduced after 180 s, and the reaction fit the pseudo-first order kinetics equation, in which the reacting constant reaches 5.50×10−3 s−1 and the turnover frequency achieves 1723.24 h−1. The composite catalysts of CuO NPs@CNF-Si-N(OH)2 exhibite excellent recycling performance, and 94.42% of 4-NP can be catalytically reduced after a recycling time of 8. The results can provide a new idea and approach for the preparation of high-performance catalytic composite.
-
Key words:
- cellulose nanofibers /
- 3-chloropropyltriethoxysilane /
- diethanolamine /
- 4-nitrophenol /
- catalytic /
- reduction
-
图 1 纤维素纳米纤丝(CNF)基复合材料的制备及对4-硝基苯酚(4-NP)催化还原示意图
Figure 1. Schematic diagram of preparation of cellulose nanofiber (CNF) based catalytic composite and its catalytic reduction of 4-nitrophenol (4-NP)
4-AP—4-aminophenol; NPs—Nanoparticles; CPTES—3-chloropropyltrimethoxysilane
图 2 CNF及CNF基复合催化材料的Zeta电位图
Figure 2. Zeta potential diagram of CNF and CNF based catalytic composite
图 3 CNF与CNF基复合催化材料的XPS图谱 (a)及CuO纳米颗粒(NPs)@CNF中Cu2p分析图 (b)
Figure 3. XPS spectra of CNF and CNF based catalytic composite (a) and Cu2p spectra (b) of CuO nanoparticles (NPs)@CNF composite
图 4 CNF及CNF基复合催化材料的FTIR图谱
Figure 4. FTIR spectra of CNF and CNF based catalytic composite
图 5 CNF及CNF基复合催化材料的XRD图谱
Figure 5. XRD patterns of CNF and CNF based catalytic composite
图 6 CNF及CNF基复合催化材料的TG (a) 与DTG (b) 曲线
Figure 6. TG (a) and DTG (b) curves of CNF and CNF based catalytic composite
图 7 CNF (a) 及CNF基复合催化材料 ((b)~(d)) 的TEM图像及CuO NPs@CNF的HRTEM图像 (e)
Figure 7. TEM images of CNF (a), CNF based catalytic composite ((b)-(d)) and HRTEM image of CuO NPs@CNF (e)
图 8 (a) 4-NP还原过程中各阶段的光学图片；(b) CNF及CNF基复合催化材料在180 s内还原4-NP的紫外-可见分光光谱图；(c) 不同DEA含量(5wt%~20wt%)的CuO NPs@CNF-Si-N(OH)2 180 s内还原4-NP的紫外-可见分光光谱图；(d) CNF、CuO NPs及CNF基复合催化材料的动力学曲线
Figure 8. (a) Color changes of 4-NP solution after adding CuO NPs@CNF-Si-N(OH)2; (b) UV-vis absorption spectra after adding CNF and CNF based catalytic composite for 180 s; (c) UV-vis absorption spectra after adding CuO NPs@CNF-Si-N(OH)2 grafted with different DEA contents (5wt%-20wt%) for 180 s; (d) Kinetic curves of CNF, CuO NPs and CNF based catalytic composite
A0−Absorbance of the mixture at the initial moment of reaction; At−Absorbance at 400 nm (4-NP) after reaction time t
图 9 不同回用次数下CuO NPs@CNF-Si-N(OH)2对4-NP的转化率
Figure 9. Conversion yield of 4-NP using the CuO NPs@CNF-Si-N(OH)2 with 20 wt% DEA dosage
表 1 CNF及CNF基复合催化材料的热重特征温度表
Table 1. The characteristic temperature of TG thermograms of CNF and CNF based catalytic composite
Sample T1/°C T2/°C Residual mass/% Mass loss/% CNF 324.76 356.00 11.43 84.56 CuO NP@CNF 321.67 352.67 14.31 81.59 CuO NP@CNF-Si 322.19 354.84 12.06 83.74 CuO NP@CNF-Si-N(OH)2 318.68 354.59 13.41 83.54 Notes: T1—Initial temperature of extrapolation; T2—Temperature at maximum rate of mass change.
下载: 导出CSV
表 2 不同催化剂对4-NP的催化还原性能分析
Table 2. Catalytic performance of the CuO NPs and CNF based catalytic composite
Sample Temperature/K Molar ratio of
4-NP/catalystTime Apparent rate
constant K/s−1Conversion
yield/%CuO NPs 298 87∶1 180 s 0.60×10−3 46.14 CuO NPs@CNF 298 87∶1 180 s 1.30×10−3 71.82 CuO NPs@CNF-Si 298 87∶1 180 s 1.50×10−3 84.46 CuO NPs@CNF-Si-N(OH)2 (5 wt% DEA) 298 87∶1 180 s 2.20×10−3 86.71 CuO NPs@CNF-Si-N(OH)2 (10 wt% DEA) 298 87∶1 180 s 3.00×10−3 87.92 CuO NPs@CNF-Si-N(OH)2 (15 wt% DEA) 298 87∶1 180 s 4.70×10−3 90.90 CuO NPs@CNF-Si-N(OH)2 (20 wt% DEA) 298 87∶1 180 s 5.50×10−3 98.39
下载: 导出CSV
表 3 CNF基复合催化材料与其他纳米纤维素基复合催化材料的转化效率分析
Table 3. Comparison of catalytic performance of the CNF based catalytic composite with other reported metal nanoparticles based catalysts
Sample Temp/K Molar ratio of4-NP/ catalyst TOF/h−1 Reference CuO NPs@CNF 298 87∶1 407.31 This work CuO NPs@CNF-Si-N(OH)2 (20 wt% DEA) 298 87∶1 1723.24 This work CuO NPs@GO 298 150∶1 816.2 [5] Au NPs@CNF 298 150∶1 563 [32] Au NPs@PDDA/NCC 298 37∶1 212 [7] Au NPs@CNCs 298 30∶1 109 [33] Ag NPs@CNCs/CTAB 298 97.2∶1 1077.3 [34] Notes: TOF—Turnover Frequency; CCF—Carboxymethylated cellulose fibers; GO—Graphene oxide; PDDA—Poly(diallyldimethylammonium chloride); NCC—Nanocellulose crystal; CNC—Cellulose nanocrystal; CTAB—Hexadecyl-trimethylammonium bromide.
下载: 导出CSV
表 4 CuO NPs@CNF-Si-N(OH)2与其他纤维素基复合催化材料的回用效果分析
Table 4. Comparison of the conversion of the CNF based nanohybrids with other reported cellulose based composite
Sample Catalyst Carrier Repeated times Conversion yield Reference CuO NPs@CNF-Si-N(OH)2 (20 wt% DEA) CuO NPs Cellulose nanofibers 8 94.42% This work Ag NPs@ MOF‐199 s/CCFs Ag NPs Cellulose fibers 5 91.0% [35] Ag NPs@CFP Ag NPs Cellulose filter paper 4 90.0% [36] Ag NPs@CMFs Ag NPs Cellulose microfibers 6 87.0% [37] Fe3O4/Ag@NFC Ag NPs Nanofibrillated cellulose 7 81.8% [38] Notes: CFP—cellulose filter paper; CMF—cellulose microfiber; NFC—Nanofibrillated cellulose.
下载: 导出CSV
-
[1] 杨晓闪. SiO2@C负载Ni、Cu催化剂的制备及性能研究[D]. 郑州: 郑州大学, 2019.YANG Xiaoshan. Preparation and properties of SiO2@C supported Ni and Cu catalysts[D]. Zhengzhou: Zhengzhou University, 2019(in Chinese). [2] WAN N, GU J D, YAN Y. Degradation of p-nitrophenol by chromobacter xylosoxidans Ns isolated from wetland sediment[J]. International Biodeterioration & Biodegradation,2007(59):90-96. [3] 梁艳莉, 马剑琪, 郭少波. CoFe2O4@PDA@Pt核壳型磁性复合材料的制备及催化性能[J]. 复合材料学报, 2021, 38(5):1551-1557.LIANG Yanli, MA Jianqi, GUO Shaobo. Preparation and catalytic properties of CoFe2 O4@PDA@Pt magnetic composite with core shell structure[J]. Acta Materiae Compositae Sinica,2021,38(5):1551-1557(in Chinese). [4] 林兆云, 戢德贤, 杨桂花, 等. 纤维素基金属纳米粒子复合催化剂的制备与应用[J]. 复合材料学报, 2022, 39(3):977-988.LIN Zhaoyun, JI Dexian, YANG Guihua, et al. Preparation and application of cellulose-based metal nanoparticles composite catalysts[J]. Acta Materiae Compositae Sinica,2022,39(3):977-988(in Chinese). [5] ZHOU Z, LU C, WU X, et al. Cellulose nanocrystals as a novel support for CuO nanoparticles catalysts: Facile synthesis and their application to 4-nitrophenol reduction[J]. RSC Advances,2013,3(48):26066-26073. doi: 10.1039/c3ra43006e [6] CHEN L, CAO W J, QUINLAN P, et al. Sustainable catalysts from gold-loaded polyamidoamine dendrimer-cellulose nanocrystals[J]. ACS Sustainable Chemistry & Engineering,2015,3(5):978-985. [7] LAM E, HRAPOVIC S, MAJID E, et al. Catalysis using gold nanoparticles decorated on nanocrystalline cellulose[J]. Nanoscale,2012,4(3):997-1002. doi: 10.1039/c2nr11558a [8] 王海英, 刘志明, 毕晓欣, 等. 桉木浆纳米纤维素制备优化条件初探[J]. 江苏农业科学, 2012, 40(7):242-245. doi: 10.3969/j.issn.1002-1302.2012.07.092WANG Haiying, LIU Zhiming, BI Xiaoxin, et al. Preliminary study on optimum preparation conditions of nanocrystalline cellulose from Eucalyptus pulp[J]. Jiangsu Agricultural Sciences,2012,40(7):242-245(in Chinese). doi: 10.3969/j.issn.1002-1302.2012.07.092 [9] PINTO R J B, MÁRCIA C, NETO C P, et al. Growth and chemical stability of copper nanostructures on cellulosic fibers[J]. European Journal of Inorganic Chemistry,2012,2012(31):5043-5049. doi: 10.1002/ejic.201200605 [10] GOY-LÓPEZ S, TABOADA P, CAMBON A, et al. Modulation of size and shape of Au nanoparticles using amino-X-shaped poly(ethylene oxide)-poly(propylene oxide) Block Copolymers[J]. The Journal of Physical Chemistry B,2010,114(1):66-76. doi: 10.1021/jp908569z [11] 倪镜博, 刘如一, 张明, 等. 原位聚合法制备纳米核-壳型PS-CHO@RGO复合微球及其催化活化过硫酸氢钾降解亚甲基蓝[J]. 复合材料学报, 2021, 38(7):2132-2139.NI Jingbo, LIU Ruyi, ZHANG Ming, et al. Preparation of nano core-shell PS-CHO@RGO composite microspheres by in-situ polymerization as a potassium hydrogen persulfate catalytic activator for methylene blue degradation[J]. Acta Materiae Compositae Sinica,2021,38(7):2132-2139(in Chinese). [12] ARMELAO L, BARRECA D, BERTAPELLE M, et al. A sol-gel approach to nanophasic copper oxide thin films[J]. Thin Solid Films,2003,442(1):48-52. [13] VAINIO U, PIRKKALAINEN K, KISKO K, et al. Copper and copper oxide nanoparticles in a cellulose support studied using anomalous small-angle X-ray scattering[J]. The European Physical Journal D,2007,42(1):93-101. doi: 10.1140/epjd/e2007-00015-y [14] FAN J C, XIE Z. Effects of substrate temperature on structural, electrical and optical properties of As-doped ZnO films[J]. Materials Science & Engineering B,2008,150(1):61-65. [15] BHATTACHARJEE A, AHMARUZZAMAN M. Green synthesis of 2 D CuO nanoleaves (NLs) and its application for the reduction of pnitrophenol[J]. Materials Letters,2015,161:79-82. doi: 10.1016/j.matlet.2015.08.061 [16] REDDY K R. Green synthesis, morphological and optical studies of CuO nanoparticles[J]. Journal of Molecular Structure,2017,1150:553-557. doi: 10.1016/j.molstruc.2017.09.005 [17] SAITO T, KIMURA S, NISHIYAMA Y, et al. Cellulose nanofibers prepared by TEMPO-mediated oxidation of native cellulose[J]. Biomacromolecules,2007,8(8):2485-2491. doi: 10.1021/bm0703970 [18] ISOGAI A, ATALLA R H. Dissolution of cellulose in aqueous NaOH solutions[J]. Cellulose,1998,5(4):309-319. doi: 10.1023/A:1009272632367 [19] 叶瑞荣, 汪朝阳, 杨凯, 等. 二乙醇胺改性聚乳酸的直接熔融聚合法合成及其表征[J]. 化学通报, 2009, 72(7):637-643.YE Ruirong, WANG Chaoyang, YANG Kai, et al. Direct melt polycondensation and characterization of polylactic acid modified by diethanolamine[J]. Chemistry,2009,72(7):637-643(in Chinese). [20] LIONEL M, ALEXIS C, HEINRICH H. Polymer adsorption on iron oxide nanoparticles for one-step amino-functionalized silica encapsulation[J]. Journal of Nanomaterials,2015,16(1):239. [21] KHAN S B, ALAMRY K A, BIFARI E N, et al. Assessment of antibacterial cellulose nanocomposite for water permeability and salt rejection[J]. Journal of Industrial & Engineering Chemistry,2015,24:266-275. [22] TANG J, SHI Z, BERRY R M, et al. Mussel-inspired green metallization of silver nanoparticles on cellulose nanocrystals and their enhanced catalytic reduction of 4-nitrophenol in the presence of β-cyclodextrin[J]. Industrial & Engineering Chemistry Research,2015,54(13):3299-3308. [23] CAO M, HU C, WANG Y, ET AL. A controllable synthetic route to Cu, Cu2O, and CuO nanotubes and nanorods[J]. Chemical Communications,2003(15):1884-1885. doi: 10.1039/b304505f [24] MARÍNPAREJA N, CANTINI M, GONZALEZGARCIA C, et al. Different organization of type I collagen immobilized on silanized and nonsilanized titanium surfaces affects fibroblast adhesion and fibronectin secretion[J]. ACS Applied Materials & Interfaces,2015,7(37):20667-20677. [25] BOUAZIZI N, BARGOUGUI R, THEBAULT P, ET AL. Development of a novel functional core-shell-shell nanoparticles: From design to anti-bacterial applications[J]. Journal of Colloid & Interface Science,2017,513:726-735. [26] WANG C, WANG H, YU H. Preparation and application of biomimetic superhydrophobic silica and polyurethane composite coating[J]. International Journal of Surface Science and Engineering,2015,9(6):510-519. doi: 10.1504/IJSURFSE.2015.072832 [27] LIU B H, LI Z P. A review: Hydrogen generation from borohydride hydrolysis reaction[J]. Journal of Power Sources,2009,187(2):527-534. doi: 10.1016/j.jpowsour.2008.11.032 [28] YANG Y, CHEN Z, WU X, et al. Nanoporous cellulose membrane doped with silver for continuous catalytic decolorization of organic dyes[J]. Cellulose,2018,25(4):2547-2558. doi: 10.1007/s10570-018-1710-x [29] BAE S, GIM S, KIM H, et al. Effect of NaBH4 on properties of nanoscale zero-valent iron and its catalytic activity for reduction of p-nitrophenol[J]. Applied Catalysis B: Environmental,2016,182:541-549. doi: 10.1016/j.apcatb.2015.10.006 [30] LI J, LIU C Y, LIU Y. Au/graphene hydrogel: Synthesis, characterization and its use for catalytic reduction of 4-nitrophenol[J]. Journal of Materials Chemistry,2012,22(17):8426-8430. doi: 10.1039/c2jm16386a [31] WU X, LU C, ZHOU Z, et al. Strategy for synthesizing porous cellulose nanocrystal supported metal nanocatalysts[J]. ACS Sustainable Chemistry & Engineering,2016,1(1):71-79. [32] KOGA H, TOKUNAGA E, HIDAKA M, et al. Topochemical synthesis and catalysis of metal nanoparticles exposed on crystalline cellulose nanofibers[J]. Chemical Communications,2010,46(45):8567-8569. doi: 10.1039/c0cc02754e [33] WU X, LU C, ZHOU Z, et al. Green synthesis and formation mechanism of cellulose nanocrystal-supported gold nanoparticles with enhanced catalytic performance[J]. Environmental Science Nano,2014,1(1):71-79. doi: 10.1039/c3en00066d [34] AN X, LONG Y, NI Y. Cellulose nanocrystal/hexadecyltrimethylammonium bromide/silver nanoparticle composite as a catalyst for reduction of 4-nitrophenol[J]. Carbohydrate Polymers[J],2017,156:253-258. doi: 10.1016/j.carbpol.2016.08.099 [35] DUAN C, LIU C, MENG X, et al. Fabrication of carboxymethylated cellulose fibers supporting Ag NPs@MOF-199 s nanocatalysts for catalytic reduction of 4-nitrophenol[J]. Applied Organometallic Chemistry,2019,33(5):4865. doi: 10.1002/aoc.4865 [36] AHMAD I, KAMAL T, KHAN S B, et al. An efficient and easily retrievable dip catalyst based on silver nanoparticles/chitosan-coated cellulose filter paper[J]. Cellulose,2016,23(6):3577-3588. [37] XU P, CEN C, CHEN N, et al. Facile fabrication of silver nanoparticles deposited cellulose microfiber nanocompo-site for catalytic application[J]. Journal of Colloid and Interface Science,2018,526:194-200. doi: 10.1016/j.jcis.2018.04.045 [38] XIONG R, LU C, WANG Y, et al. Nanofibrillated cellulose as the support and reductant for the facile synthesis of Fe3O4/Ag nanocomposite with catalytic and antibacterial activity[J]. Journal of Materials Chemistry A,2013,1(47):14910-14918. doi: 10.1039/c3ta13314a -
