纳米聚多巴胺六方氮化硼–二氧化硅/环氧树脂涂层对水泥砂浆抗碳化能力的影响

刘嘉源; 张宏亮; 左晓宝; 邹欲晓

doi:10.13801/j.cnki.fhclxb.20221213.004

纳米聚多巴胺六方氮化硼–二氧化硅/环氧树脂涂层对水泥砂浆抗碳化能力的影响

doi: 10.13801/j.cnki.fhclxb.20221213.004

南京理工大学　理学院，南京 210094

基金项目: 国家自然科学基金(52078252；51778297)

详细信息

通讯作者:
左晓宝，博士，教授，研究方向为混凝土材料与结构　E-mail：xbzuo@sina.com

中图分类号: TU593；TB332
计量
- 文章访问数: 662
- HTML全文浏览量: 312
- PDF下载量: 21
- 被引次数: 0
出版历程
- 收稿日期: 2022-10-05
- 修回日期: 2022-11-13
- 录用日期: 2022-12-02
- 网络出版日期: 2022-12-14
- 刊出日期: 2023-09-15

Effect of nano polydopamine hexagonal boron nitride-functionalised silicon dioxide/epoxy coating for resistance carbonation ability of cement mortar

School of Science, Nanjing University of Science and Technology, Nanjing 210094, China

Funds: National Natural Science Foundation of China (52078252; 51778297)

摘要

摘要: 为了获得具有良好分散性、填充性和阻隔性的纳米材料，同时将其作为填料以提升环氧树脂涂层对水泥砂浆试件的防护能力，本文制备了纳米聚多巴胺六方氮化硼–二氧化硅(PDABN-fSiO₂)/环氧树脂涂层，涂覆于水泥砂浆试件表面，研究涂层对试件的防护效果。首先，利用盐酸多巴胺(DA)自聚合形成的聚多巴胺(PDA)与偶联剂(KH550)，分别修饰纳米六方氮化硼(hBN)与纳米二氧化硅(SiO₂)，获得纳米聚多巴胺六方氮化硼(PDABN)与功能化的SiO₂(fSiO₂)；其次，经聚合以制备纳米PDABN-fSiO₂；最后，将其作为填料改性环氧树脂，并涂覆于水泥砂浆表面。通过FTIR、SEM-EDS和XPS等微观表征，观察并研究了纳米材料的微观特征；开展了碳化试验和涂层透气性试验，分析了纳米PDABN-fSiO₂对环氧树脂涂层的改性效果。结果表明：制备的纳米PDABN-fSiO₂具有“片层+颗粒”特殊结构，且在涂层中具有良好的分散性，可有效减缓其涂层中CO₂的渗透；同无填料涂层相比，涂覆有纳米PDABN-fSiO₂/环氧树脂涂层的水泥砂浆试件，在碳化7天、14天和28天时的碳化深度分别下降了68.7%、72.9%和64.8%，其涂层在48 h的透气性降低了34.7%。因此，纳米PDABN-fSiO₂掺入环氧树脂涂层后，明显地提高了涂层水泥砂浆试件的抗碳化能力，并降低了环氧树脂涂层的透气性。
- 纳米聚多巴胺六方氮化硼(PDABN)-功能化的SiO₂(fSiO₂) /
- 环氧树脂涂层 /
- 微观表征 /
- 碳化 /
- 透气性
Abstract: In order to obtain nanomaterials with better dispersal, filling and barrier properties, which were used as fillers to enhance the protection of the epoxy coatings for cement mortar, the polydopamine (PDA), which was prepared by self-polymerization of dopamine hydrochloride (DA) and silane coupling agent (KH550), was utilized to modify nano hexagonal boron nitride (hBN) and nano silicon dioxide (SiO₂), respectively, to obtain two nanomaterials polydopamine hexagonal boron nitride (PDABN) and functionalised SiO₂(fSiO₂) by polymerization reactions. A new nanomaterial, polydopamine hexagonal boron nitride-functionalised silicon dioxide (PDABN-fSiO₂), was synthesized, and it was mixed with epoxy to prepare a modified coating. The coating was covered on the surface of cement mortar to enhance its carbonation resistance. The microscopic characteristics of nano materials were observed by FTIR, SEM-EDS and XPS. The modified effect of epoxy coating by nano PDABN-fSiO₂ was analyzed by carbonation experiments and permeability tests. Results indicate that the prepared nano PDABN-fSiO₂ has a layer-particle structure and better dispersion in coating, which can effectively slow down the penetration of CO₂ in the coating. Compared with the blank coating, the carbonation depth of the cement mortar coated with nano PDABN-fSiO₂/epoxy coating is decreased by 68.7%, 72.9% and 64.8% at 7, 14 and 28 days of carbonation, respectively, and the permeability of its coating is decreased by 34.7% at 48 hours. Thus, the epoxy coating with nano PDABN-fSiO₂ can significantly improve the carbonation resistance of cement mortar and reduce its permeability.
- nano polydopamine hexagonal boron nitride (PDABN)-functionalised silicon dioxide (fSiO₂) /
- epoxy coating /
- microscopic test /
- carbonation /
- permeability

HTML全文

图 1 掺入纳米聚多巴胺六方氮化硼-二氧化硅(PDABN-fSiO₂)的环氧树脂涂层制备流程

Figure 1. Preparation process of nano polydopamine hexagonal boron nitride-functionalised silicon dioxide (PDABN-fSiO₂) epoxy coating

下载: 全尺寸图片幻灯片

图 2 环氧树脂中纳米填料的分散过程

Figure 2. Dispersion process of nano fillers in epoxy resins

下载: 全尺寸图片幻灯片

图 3 涂层透气性试验装置示意图

Figure 3. Experimental diagram of the gas permeability of coatings

下载: 全尺寸图片幻灯片

图 4 各种纳米材料的FTIR图谱

Figure 4. FTIR spectra of various nano materials

下载: 全尺寸图片幻灯片

图 5 各种纳米填料的SEM图像及纳米PDABN-fSiO₂不同测试区域的EDS图谱

Figure 5. SEM images of various nano fillers and EDS spectra of nano PDABN-fSiO₂ about different areas

D—Diameter of nano fSiO₂ particles; T—Thickness of nano PDABN layers

下载: 全尺寸图片幻灯片

图 6 各种环氧树脂涂层断面处SEM图像及其Mapping分析结果

Figure 6. SEM images and mapping analysis results of cross sectional about various epoxy coatings

下载: 全尺寸图片幻灯片

图 7 纳米PDABN-fSiO₂的XPS图谱与纳米PDABN-fSiO₂的XPS高分辨图谱

Figure 7. XPS spectra of nano PDABN-fSiO₂ and its high-resolution XPS spectra

下载: 全尺寸图片幻灯片

图 8 水泥砂浆表面涂覆掺入不同填料的环氧树脂涂层在7、14和28天时酚酞显色结果

Figure 8. Results of phenolphthalein color test on cement mortar coated with epoxy coatings with different fillers at 7, 14 and 28 days

下载: 全尺寸图片幻灯片

图 9 水泥砂浆表面涂覆掺入不同填料的环氧树脂涂层在7、14和28天时水泥砂浆试件碳化深度

Figure 9. Carbonization depth of cement mortar coated with epoxy coatings with different fillers at 7, 14 and 28 days

下载: 全尺寸图片幻灯片

图 10 干燥剂吸水量随时间变化曲线

Figure 10. Curves of water absorption of desiccant with time

下载: 全尺寸图片幻灯片

表 1 水泥的氧化物组成

Table 1. Oxide composition of cement wt%

Cement	CaO	SiO₂	Al₂O₃	Fe₂O₃	SO₃	MgO	K₂O	Na₂O	TiO₂
P.II 52.5	66.92	19.28	4.20	3.78	2.07	1.84	0.74	0.30	0.26

下载: 导出CSV

表 2 制备各种含有填料的环氧树脂涂层所需材料与用量

Table 2. Materials and quantities required for the preparation of various epoxy coatings with fillers

Sample	Coating filler component	Epoxy dosage/g	Total amount of filler/g
Epoxy coating	Blank	5	−
Nano SiO₂/epoxy coating	Nano SiO₂	5	0.05
Nano PDABN/epoxy coating	Nano PDABN	5	0.05
Nano PDABN-SiO₂/epoxy coating	Nano PDABN-fSiO₂	5	0.05

下载: 导出CSV
