本征导热液晶环氧及其复合材料的研究进展

王蕴; 周文英; 曹丹; 李婷; 曹国政; 张祥林

doi:10.13801/j.cnki.fhclxb.20210901.001

本征导热液晶环氧及其复合材料的研究进展

doi: 10.13801/j.cnki.fhclxb.20210901.001

王蕴¹,
周文英^1, ,,
曹丹¹,
李婷¹,
曹国政¹,
张祥林²

1.
西安科技大学化学与化工学院先进电工材料研究中心，西安 710054
2.
咸阳天华电子科技有限公司，咸阳 712000

基金项目: 国家自然科学基金 (51577154)

详细信息

通讯作者:
周文英，博士，教授，博士生导师，研究方向为导热电子封装与电气绝缘聚合物电介质材料　E-mail：wyzhou2004@163.com

中图分类号: TB34
计量
- 文章访问数: 1777
- HTML全文浏览量: 833
- PDF下载量: 171
- 被引次数: 0
出版历程
- 收稿日期: 2021-07-14
- 修回日期: 2021-08-09
- 录用日期: 2021-08-27
- 网络出版日期: 2021-09-02
- 刊出日期: 2022-03-23

Progress in intrinsically thermal conductive liquid crystalline epoxy and composites

1.
Advanced Electrical Materials Research Center, College of Chemistry & Chemical Engineering, Xi’an University of Science and Technology, Xi’an 710054, China
2.
Xianyang Tianhua Electronic Technology Co. Ltd., Xianyang 712000, China

摘要

摘要: 散热困难已成为制约微电子器件和电气绝缘设备日趋微型化的关键问题和技术瓶颈。传统导热环氧复合材料因热导率 (k) 与介电强度 (E_b) 之间难以协同提升及联调的矛盾而无法适应大功率、超高频微电子器件及高电压电力设备的绝缘封装的散热需求，而基于液晶 (LCE) 基元调控交联网络的结构有序性来提高k值而制备的本征导热环氧 (ITCE) 则同时具备高k及E_b性能。本论文分析了液晶环氧的微结构及本征导热机制，综述和归纳了基于不同结构液晶基元的ITCE的研究进展，系统分析了本征k的影响因素，探讨了液晶环氧及固化剂结构、温度、液晶基元含量及晶粒尺寸、外场辅助加工等因素对固化环氧的本征k的影响机制，阐述了提高液晶环氧的有序结构及本征k的途径和方法。最后，探讨了当前ITCE研究中存在的问题及展望了ITCE的未来发展方向。相比常规环氧，综合性能优异的ITCE代表了导热环氧的未来发展方向，基于ITCE的导热环氧复合材料在高频、高密度、微电子、高电压及大功率电力设备等领域具有潜在的重要用途。
- 液晶基元 /
- 本征导热环氧 /
- 热导率 /
- 有序结构 /
- 绝缘电阻
Abstract: Difficulty in prompting heat dissipation has emerged as a critical issue and technical bottleneck restricting further miniaturization of microelectronic devices and electrical insulation equipment. Traditional heat conductive epoxy composites are not qualified for meeting the heat dissipation requirements of high-power, ultra-high-frequency and high-voltage insulating packaging because the thermal conductivity (k) and dielectric strength (E_b) cannot be regulated and improved synergistically. Intrinsically thermal conductive epoxy (ITCE), whose k can be enhanced by regulating ordered structure of cross-linked network containing liquid crystal epoxy (LCE) units, simultaneously exhibits high k and E_b. This paper analyzes the microstructure and intrinsic heat conduction mecha-nism of LCE, and summarizes the latest research progress in ITCE based on different LCE structures. The present work systematically analyzes the influencing factors on k of ITCE, such as structures of LCE and curing agent, temperature, LCE content, grain size, and external field-assisted processing, and expounds the way to improve the ordered structure of LCE and the intrinsic k. Finally, it summarizes the existing problems in current ITCE research and points to the future development direction. ITCE with excellent comprehensive performances represents the future development direction of ITCE, and the ITCE based composites has significant potential applications in high-density packaging microelectronics, high-voltage and high-power power equipment.
- liquid crystal unit /
- intrinsically thermal conductive epoxy /
- thermal conductivity /
- ordered structure /
- insulating resistance

HTML全文

图 1 常见聚合物的热导率 (k)、导热机制、本征导热环氧 (ITCE) 及应用

Figure 1. Thermal conductivity (k) of common polymers, mechanism, intrinsically thermal conductive epoxy (ITCE) and applications

k—Thermal conductivity; E_b—Dielectric strength; C_P—Specific heat capacity per unit volume; ν—Average phonon; l—Phonon mean free path

下载: 全尺寸图片幻灯片

图 2 液晶环氧 (LCEP) 结构示意图及常见液晶基元的化学结构^[5]

Figure 2. Schematic diagram of liquid crystal epoxy polymers (LCEP) and chemical structure of common liquid crystal epoxy units^[5]

下载: 全尺寸图片幻灯片

图 3 液晶 (LC) 基元自组装有序结构对声子导热影响示意图^[5]

Figure 3. Schematic diagram for formation of ordered structure from self-assemble liquid crystal (LC) and their effect on heat conduction^[5]

下载: 全尺寸图片幻灯片

图 4 (a)三类液晶(LC)结构对固化环氧(EP)及复合材料导热影响^[15]；(b)液晶(LC)基元长度对固化环氧(EP)导热影响^[18]

Figure 4. (a) Effects of three LCEPs on k of cured EP and composites^[15]；(b) Effect of length of LC units on k of cured EP^[18]

TA—Terephthalylidene-bis-(4-aminophenol); DP—4′, 4′-Bis-(4-hydroxybenzylidene)-diaminophenylene; DPE—4′, 4′-Bis-(4-hydroxybenzylidene)-diaminodiphenylether; LCE-TA—Terephthalylidene-bis-(4-aminophenol) diglycidyl ether; LCE-DP—4′, 4′-Bis(4-hydroxybenzylidene)-diaminophenylene diglycidyl ether; LCE-DPE—4′, 4′-Bis-(4-hydroxybenzylidene)-diaminodiphenylether diglycidyl ether; DDS—4, 4′-Diaminodiphenylsulfone; DDM—4, 4′-Diaminodiphenylmethane

下载: 全尺寸图片幻灯片

图 5 固化剂及交联方式对不同结构液晶环氧固化物的空间结构影响示意图: (a)基于XRD数据描述固化LCE-CB06分子结构的示意图；(b)稠联苯型LCEP的固化过程；(c)使用两种固化方法获得的液晶环氧树脂（LCER）不同微观结构的示意图^{[4, 23]}

Figure 5. Effects of curing agent and crosslinking on microstructure of various LECP: (a) A schematic describing the molecular structure of the cured LCE-CB06 based on the XRD data; (b) Curing process of thick biphenyl type LCEP; (c) Schematic illustration of the different microstructures of liquid crystalline epoxy resin (LCER) obtained using the two curing methods^{[4, 23]}

Cat. Ini.—Cationic initiator

下载: 全尺寸图片幻灯片

图 6 LCEP及BN/LCEP复合材料固化中取向结构形成及演化示意图^[27]

Figure 6. Formation and evolution process of oriented structure for LCEP and BN/LCEP composites during curing^[27]

BN—Boron nitride; LC—Liquid crystal

下载: 全尺寸图片幻灯片

图 7 LCEP的高阶结构有序性与导热关联示意图^{[2, 10]}

Figure 7. Relationship between advanced orderly structure of LCEP and thermal conduction^{[2, 10]}

下载: 全尺寸图片幻灯片

图 8 ((a)~(d)) 球晶形成过程；(e) 含介晶基元的树脂体系中球晶微观形态的示意图；(f) 球晶尺寸对体系导热性能的影响^[34]

Figure 8. ((a)-(d))Formation process of spherulite; (e) Schematic representation of microscopic pattern of the spherulites in the mesogen-containing resin system; (f) Effects of grain size on thermal conduction^[34]

Process of spherulite formation in epoxy resin monomer-100 (TM-100) film cast from methyl ethyl ketone (MEK) solution recorded by the polarized optical microscope (POM) 1 min (a), 5 min (b), at 100℃ (c) and fully cured at 190℃ (d) for 2 h

下载: 全尺寸图片幻灯片

图 9 基底的表面自由能 (SFE) 对LCEP自组装取向结构及导热系数 (k) 影响^[35]

Figure 9. Effects of surface free energy (SFE) of substrate on orientation structure of self-assemble LCEP and heat conductivity coefficient (k)^[35]

下载: 全尺寸图片幻灯片

图 10 LCEP 与导热粒子间的协同导热效应

Figure 10. Synergistic effect in thermal conduction between LCEP matrix and heat conductive particles

下载: 全尺寸图片幻灯片

表 1 各类LCEP、固化剂结构及固化LCEP的热导率 (k)

Table 1. Several kinds of LCEP, curing agents, and thermal conductivity (k) of cured LCEP

Category		LCEP	Curing agents	k/(W·(m·K)⁻¹)	Ref.
Main chain type	Biphenyl structure LCEP			0.43	[2]
				0.19	[11]
				0.28	[12]
				0.31	[13]
				0.51	[14]
				0.38	[20]
				0.33	[31]
				0.41-5.50	[35]
	Methylene aromatic amines LCEP			0.49	[15]
				0.38	[17]
				0.39	[21]
				0.89	[32]
				0.32	[33]
	Aromatic ester LCEP			1.05	[9]
	Aromatic ester LCEP			0.29	[20]
Side chain type				0.40	[21]
			DPMP	1.25	[20]
				0.46	[4]
Thick biphenyl type			—	—	[7]
Note: DPMP—Dipentaerythritol hexakis(3-mercaptopropionate).

下载: 导出CSV
