Interface mechanical bonding properties between coarse synthetic polypropylene fiber and cement mortar
-
摘要: 纤维嵌入水泥基材料中的界面黏结力学性能对纤维增强混凝土材料的力学性能起着重要作用。单纤维拉拔试验可以较好地模拟纤维与水泥基体材料界面间的受力条件，因此考虑3种纤维直径(0.2 mm、0.6 mm、0.8 mm)、3种纤维埋置长度(10 mm、20 mm、30 mm)和3种纤维表面性状(压痕型、波浪型、光圆型)与3种水泥砂浆基体水胶比(0.66、0.51、0.41)影响因素，进行了单根粗聚丙烯纤维从水泥砂浆基体中的拔出试验，使用SEM观测了纤维被拔出后的形貌特征，通过ABAQUS有限元建立了纤维拔出过程的数值模型，以研究单根纤维与水泥基界面间的剪切应力。同时将试验结果和模拟结果进行了数值拟合，得到了各因素对界面黏结力学性能的影响规律：(1) 水泥砂浆的最佳水胶比为0.41~0.49；(2) 合成粗聚丙烯纤维埋置长度最佳为8~10 mm，最佳纤维直径在0.26~0.39 mm范围；(3) 纤维表面性状为压痕型时，纤维在水泥基材料中的利用率较大，并且与水泥砂浆的界面黏结性能良好。Abstract: The interfacial bonding mechanical properties of fiber-embedded cement-based materials play an important role in the mechanical properties of fiber-reinforced concrete materials. The pull-out test of single fiber can better simulate the stress conditions between the fiber and the cement matrix material interface. Therefore, a pull-out test of a single coarse polypropylene fiber from cement mortar matrix was carried out which considered three fiber diameters (0.2 mm, 0.6 mm, 0.8 mm), three fiber embedding lengths (10 mm, 20 mm, 30 mm), three fiber surface properties (indentation type, wave type, smooth type) and three kinds of cement mortar matrix water-binder ratio (0.66, 0.51, 0.41) influencing factors. The morphological characteristics of the fibers after being pulled out were observed by SEM, a numerical model of the fiber pull-out process was established by ABAQUS finite element to study the shear stress between a single fiber and the cement-based interface. At the same time, the experimental results and the simulation results were numerically fitted, and the influence rules of various factors on the interface bonding mechanical properties were obtained: (1) The optimum water-binder ratio of cement mortar is 0.41-0.49; (2) The embedded length of the synthetic crude polypropylene fiber is 8-10 mm, and the optimal fiber diameter is in the range of 0.26-0.39 mm; (3) When the fiber surface properties are indentation type, the utilization rate of fibers in cement-based materials is large, and the interface bonding performance with cement mortar is good.
-
-
![]()
图 1 不同表面性状和长径比的合成粗聚丙烯纤维
Figure 1. Synthetic crude polypropylene fibers with different surface properties and aspect ratios
![]()
图 3 各影响因素下合成粗聚丙烯纤维/水泥砂浆的荷载-滑移曲线：(a) 砂浆基体强度；(b) 纤维埋置长度；(c) 纤维直径大小；(d) 纤维表面性状
Figure 3. Load-slip curves under various influencing factors of synthetic coarse polypropylene fiber/cement mortar: (a) Mortar matrix strength; (b) Fiber embedded length; (c) Fiber diameter; (d) Fiber surface feature
![]()
图 4 各影响因素下合成粗聚丙烯纤维在水泥砂浆基体中的利用率
Figure 4. Utilization rate of synthetic coarse polypropylene fiber in cement mortar matrix under various influencing factors
![]()
图 5 合成粗聚丙烯纤维从水泥砂浆基体中拔出后的表面 ((a)、(b)) 及附着物 ((c)、(d)) 微观形貌
Figure 5. Micromorphologies of the surface ((a), (b)) and attachments ((c), (d)) after synthetic coarse polypropylene fibers being pulled out from cement mortar matrix
C-S-H—Hydrate calcium silicate
![]()
图 6 不同表面性状合成粗聚丙烯纤维与水泥砂浆基体拉拔试验的有限元模拟
Figure 6. Finite element simulation of drawing test of synthetic coarse polypropylene fibers with different surface properties and cement mortar matrix
![]()
7 合成粗聚丙烯纤维/水泥砂浆界面黏结仿真应力云图
7. Simulation stress contours of interfacial bonding between synthetic coarse polypropylene fibers and cement mortar matrix
S—Stress (Pa)
![]()
图 8 合成粗聚丙烯纤维/水泥砂浆界面黏结强度模拟值与试验值比较
Figure 8. Comparisons of simulated and experimental values of interfacial bonding strength between synthetic coarse polypropylene fibers and cement mortar matrix
![]()
图 9 合成粗聚丙烯纤维/水泥砂浆界面黏结强度随各影响因素的变化规律
Figure 9. Variation law of interfacial bond strength of synthetic crude polypropylene fiber/cement mortar with various influencing factors
y1—Average bond strength; y2—Equivalent bond strength
表 1 合成粗聚丙烯纤维与砂浆基体组合方案
Table 1 Combination scheme of synthetic crude polypropylene fiber and mortar matrix
Numbering Matrix strength Embedded length Lf/mm Diameter d/mm Surface feature Original fiber length L0/mm JT-1 M25 20 0.8 Smooth type 50 JT-2 M35 20 0.8 Smooth type 50 JT-3 M45 20 0.8 Smooth type 50 CHD-1 M35 10 0.8 Smooth type 30 CHD-2 M35 20 0.8 Smooth type 50 CHD-3 M35 30 0.8 Smooth type 70 ZHJ-1 M35 20 0.2 Smooth type 50 ZHJ-2 M35 20 0.6 Smooth type 50 ZHJ-3 M35 20 0.8 Smooth type 50 XZH-1 M35 20 0.8 Indentation type 50 XZH-2 M35 20 0.8 Wavy type 50 XZH-3 M35 20 0.8 Smooth type 50 Notes: JT—Matrix strength of specimens; CHD—Embedded length of fiber; ZHJ—Diameter of fiber; XZH—Surface feature of fiber.
下载: 导出CSV
表 2 砂浆基体强度配合比(质量比)
Table 2 Mortar matrix strength mix ratio (mass ratio)
Matrix strength number Cement Silica fume Fly ash Sand Water to binder ratio Water reducer M25 0.8 0.1 0.1 3.3 0.66 0.005 M35 0.8 0.1 0.1 2.5 0.51 0.005 M45 0.8 0.1 0.1 2.0 0.41 0.005
下载: 导出CSV
表 3 砂浆抗压抗折强度测定结果
Table 3 Determination results of compressive and flexural strength of mortar
Matrix strength number Water to binder ratio 28 d compressive strength/MPa 28 d flexural strength/MPa M25 0.66 31.8 7.2 M35 0.51 55.2 9.7 M45 0.41 60.0 11.2
下载: 导出CSV
表 4 各因素影响下的合成粗聚丙烯纤维/水泥砂浆界面黏结强度试验结果
Table 4 Test results of interfacial bond strength under the influence of various factors of synthetic coarse polypropylene fiber/cement mortar
Influencing factor Pull out peak
load/NAverage bond
strength/MPaPulling work/
(N·mm)Equivalent bond
strength/MPaMatrix strength/MPa M25 155.00 3.84 2206.66 4.39 M35 230.42 5.54 3443.19 6.85 M45 231.04 5.85 3347.68 6.66 Embedded length/mm 10 152.40 7.38 1372.46 10.93 20 236.97 5.67 3711.92 7.39 30 234.74 3.86 4665.11 4.13 Fiber diameter/mm 0.2 87.63 8.37 1196.21 9.52 0.6 268.29 8.57 5077.73 13.48 0.8 238.29 5.60 4697.30 9.35 Surface features Indentation type 228.34 5.65 3582.00 7.13 Wavy type 226.46 5.53 3153.85 6.28 Smooth type 152.93 3.88 2367.38 4.71
下载: 导出CSV
表 5 3种砂浆强度的模型内聚力参数
Table 5 Model cohesion parameters for 3 mortar strengths
Matrix strength class Density/(kg·m−3) Elasticity Plasticity Elastic modulus/MPa Poisson's ratio Compressive yield stress/MPa Plastic strain M25 2640 30 0.25 15 0 30 0.001 M35 2710 31 0.25 40 0 50 0.0012 M45 2780 32 0.25 45 0 60 0.0015
下载: 导出CSV
表 6 水泥砂浆其他单元参数
Table 6 Other unit parameters of cement mortar
Expansion angle Eccentricity fb0/fc0 k Viscosity parameter 30 0.1 1.16 0.6667 0.005 Note: fb0/fc0 and k—Set values of concrete damage shaping in abaqus.
下载: 导出CSV
表 7 纤维模型弹塑性参数
Table 7 Elastic-plastic parameters of fiber model
Density/(kg·m−3) Poisson's ratio Plasticity Yield stress/GPa Plastic strain 910 0.3 0.5 0 1 0.027 3 0.081 6 0.135 10 0.189
下载: 导出CSV
表 8 纤维长径比和表面性状等设置参数
Table 8 Setting parameters such as fiber aspect ratio and surface properties
Numbering Fiber diameter/mm Embedded length/mm Surface feature Elastic modulus/GPa 1 0.2 20 Smooth type 15 2 0.6 20 Smooth type 15 3 0.8 10 Smooth type 10 4 0.8 20 Smooth type 10 5 0.8 30 Indentation type 10 6 0.8 20 Wavy type 10 7 0.8 20 Smooth type 10
下载: 导出CSV
表 9 黏性接触处相关参数设置
Table 9 Related parameter settings of viscous contact
Viscosity behavior Knn Kss Ktt 9.375×109 9.375×109 9.375×109 Damage Normal only Shear−1 only Shear−2 only Fracture energy Viscosity coefficient 5.9×109 5.9×109 5.9×109 1 0.01 Note: Knn, Kss, Ktt—Specified stiffness coefficients for viscous behavior in abaqus.
下载: 导出CSV
-
[1] HUI Z, RENA Y. Inclined fiber pullout from a cementitious matrix: A numerical study[J]. Materials,2016,9(10):800. DOI: 10.3390/ma9100800
[2] 惠弘毅, 李宗利, 吕从聪. 混凝土细观力学研究方法及进展评述[J]. 混凝土, 2017(9):26-30. DOI: 10.3969/j.issn.1002-3550.2017.09.007 HUI Hongyi, LI Zongli, LV Congcong. A review of the research methods and progress of concrete meso-mechanics[J]. Concrete,2017(9):26-30(in Chinese). DOI: 10.3969/j.issn.1002-3550.2017.09.007
[3] 何锐. 高韧性水泥混凝土铺装材料特性与结构分析[D]. 西安: 长安大学, 2013. HE Rui. Characteristics and structural analysis of high toughness cement concrete paving materials[D]. Xi'an: Chang'an University, 2013(in Chinese).
[4] 陈公增, 马绪荣. 纤维-水泥基材料的界面黏结性能[J]. 筑路机械与施工机械化, 2018, 35(7):75-78. DOI: 10.3969/j.issn.1000-033X.2018.07.009 CHEN Gongzeng, MA Xurong. Interfacial bonding properties of fiber-cement based materials[J]. Road Construction Machinery and Construction Mechanization,2018,35(7):75-78(in Chinese). DOI: 10.3969/j.issn.1000-033X.2018.07.009
[5] 李大伟. 高温后钢纤维与砂浆黏结性能试验研究[D]. 郑州: 郑州大学, 2020. LI Dawei. Experimental research on bonding properties of steel fiber and mortar after high temperature[D]. Zhengzhou: Zhengzhou University, 2020(in Chinese).
[6] 冯璐. 磷酸镁水泥砂浆与钢纤维黏结性能试验研究[D]. 郑州: 郑州大学, 2018. FENG Lu. Experimental study on bonding properties of magnesium phosphate cement mortar and steel fiber[D]. Zhengzhou: Zhengzhou University, 2018(in Chinese).
[7] 尚秀琳. 纤维增强水泥混凝土中纤维-基体界面区研究综述[J]. 建筑工程技术与设计, 2017(18):3384-3384. SHANG Xiulin. A review of research on fiber-matrix interface zone in fiber-reinforced cement concrete[J]. Construction Engineering Technology and Design,2017(18):3384-3384(in Chinese).
[8] 陈亚迪, 洪丽, 蒋津, 等. 水泥砂浆基体中玄武岩纤维的拔出试验研究[J]. 硅酸盐通报, 2019, 38(9): 2985-2991. CHEN Yadi, HONG Li, JIANG Jin, et al. Pull-out test study of basalt fiber in cement mortar matrix[J]. Silicate Bulletin, 2019, 38(9): 2985-2991(in Chinese).
[9] 程俊, 刘加平, 张丽辉. 超高性能混凝土纤维-基体黏结性能测试与机理分析[J]. 混凝土与水泥制品, 2016(5): 62-66. CHENG Jun, LIU Jiaping, ZHANG Lihui. Testing and mechanism analysis of fiber-matrix bonding performance of ultra-high performance concrete[J]. Concrete and Cement Products, 2016(5): 62-66(in Chinese).
[10] 王照耀, 毕继红, 赵云, 等. 水泥基材料中倾斜端钩型钢纤维拔出力学性能计算模型[J]. 复合材料学报, 2021, 38(12): 4379-4392. WANG Zhaoyao, BI Jihong, ZHAO Yun, et al. Calculation model of mechanical properties of sloping end hook-shaped steel fiber pull-out in cement-based materials[J]. Acta Materiae Compositae Sinica, 2021, 38(12): 4379-4392(in Chinese).
[11] 王力. 钢纤维混凝土基体界面黏结性能数值分析[J]. 水利与建筑工程学报, 2019, 17(2):56-60. DOI: 10.3969/j.issn.1672-1144.2019.02.010 WANG Li. Numerical analysis of bonding properties of steel fiber-concrete matrix interface[J]. Chinese Journal of Hydraulic and Architectural Engineering,2019,17(2):56-60(in Chinese). DOI: 10.3969/j.issn.1672-1144.2019.02.010
[12] 赵燕茹, 邢永明, 黄建永, 等. 数字图像相关方法在纤维混凝土拉拔试验中的应用[J]. 工程力学, 2010, 27(6):169-175. ZHAO Yanru, XING Yongming, HUANG Jianyong, et al. Application of digital image correlation method in fiber reinforced concrete pull-out test[J]. Engineering Mechanics,2010,27(6):169-175(in Chinese).
[13] CHINDAPRASIRT P, SUKONTASUKKUL P, TECHAPHATTHANAKON A, et al. Effect of graphene oxide on single fiber pullout behavior[J]. Construction and Building Materials,2021,280:122539. DOI: 10.1016/j.conbuildmat.2021.122539
[14] 何锐, 李永鹏, 任思润, 等. 聚丙烯酰胺对粗合成纤维/水泥基体界面性能的影响[J]. 华南理工大学学报(自然科学版), 2015, 43(2):133-138. HE Rui, LI Yongpeng, REN Sirun, et al. Effect of polyacrylamide on the interface properties of crude synthetic fiber/cement matrix[J]. Journal of South China University of Technology (Natural Science Edition),2015,43(2):133-138(in Chinese).
[15] 李建辉, 邓宗才, 张建军, 等. 合成纤维与混凝土界面黏结性能研究与发展[J]. 混凝土, 2005(3):31-34. DOI: 10.3969/j.issn.1002-3550.2005.03.008 LI Jianhui, DENG Zongcai, ZHANG Jianjun, et al. Research and development of the interface bond between synthetic fibers and concrete[J]. Concrete,2005(3):31-34(in Chinese). DOI: 10.3969/j.issn.1002-3550.2005.03.008
[16] 殷石, 陈发兵, 闵锐. 高强度改性合成粗纤维在国际工程中的应用案例[J]. 混凝土与水泥制品, 2018(6):51-55. DOI: 10.3969/j.issn.1000-4637.2018.06.012 YIN Shi, CHEN Fabing, MIN Rui. Application case of high-strength modified synthetic crude fiber in international engineering[J]. Concrete and Cement Products,2018(6):51-55(in Chinese). DOI: 10.3969/j.issn.1000-4637.2018.06.012
[17] 中国工程建设协会标准. 纤维混凝土试验方法标准: CECS13: 2009[S]. 北京: 中国计划出版社, 2009. Standard of China Engineering Construction Association. Standard of fiber concrete test method: CECS13: 2009[S]. Beijing: China Planning Press, 2009(in Chinese).
[18] 张献民, 陈雪芳, 李长辉, 等. 纤维与水泥砂浆界面黏结性能研究[J]. 硅酸盐通报, 2021, 40(12): 3927-3937. ZHANG Xianmin, CHEN Xuefang, LI Changhui, et al. Research on the bonding properties of fiber and cement mortar interface[J]. Silicate Bulletin, 2021, 40(12): 3927-3937(in Chinese).
[19] 霍海峰, 刘汉磊, 杨雅静, 等. ECC单轴拉伸疲劳变形特性及寿命预测[J]. 复合材料学报, 2022, 39(7): 3404-3414. HUO Haifeng, LIU Hanlei, YANG Yajing, et al. ECC Uniaxial tensile fatigue deformation characteristics and life prediction[J]. Acta Materiae Compositae Sinica, 2022, 39(7): 3404-3414(in Chinese).
[20] HUANG L, YUAN M, WEI B D, et al. Experimental investigation on sing fiber pullout behaviour on steel fiber-matrix of reactive powder concrete (RPC)[J]. Construction and Building Materials, 2022, 318: 125899.
[21] 牛恒茂, 武文红, 赵燕茹, 等. 基于PVA纤维-基体界面性能分析水泥基材料的弯曲性能[J]. 材料导报, 2018, 32(6):995-999, 1009. DOI: 10.11896/j.issn.1005-023X.2018.06.026 NIU Hengmao, WU Wenhong, ZHAO Yanru, et al. Analysis of flexural properties of cement-based materials based on PVA fiber-matrix interface properties[J]. Materials Review,2018,32(6):995-999, 1009(in Chinese). DOI: 10.11896/j.issn.1005-023X.2018.06.026
[22] 邓明科, 成媛, 翁世强, 等. 高温后高延性混凝土的抗压性能及微观结构[J]. 复合材料学报, 2020, 37(4):985-996. DENG Mingke, CHENG Yuan, WENG Shiqiang, et al. Compressive properties and microstructure of high ductility concrete after high temperature[J]. Acta Materiae Compositae Sinica,2020,37(4):985-996(in Chinese).
[23] 赵楠, 卿龙邦, 杨卓凡, 等. 不同龄期钢纤维增强水泥砂浆纤维拉拔试验与模拟研究[J]. 硅酸盐通报, 2021, 40(7):2165-2173. ZHAO Nan, QING Longbang, YANG Zhuofan, et al. Study on fiber pulling test and simulation of steel fiber reinforced cement mortar at different ages[J]. Silicate Bulletin,2021,40(7):2165-2173(in Chinese).
[24] 刘韡, 郭银波. 基于ABAQUS对钢纤维混凝土界面强度分析[J]. 公路交通科技, 2021, 38(5):65-72. DOI: 10.3969/j.issn.1002-0268.2021.05.008 LIU Wei, GUO Yinbo. Analysis of the interface strength of steel fiber reinforced concrete based on ABAQUS[J]. Highway Transportation Science and Technology,2021,38(5):65-72(in Chinese). DOI: 10.3969/j.issn.1002-0268.2021.05.008
[25] 李凡凡. 单纤维与水泥土基体拉拔模拟与破坏机理研究[D]. 舟山: 浙江海洋大学, 2017. LI Fanfan. Drawing simulation and failure mechanism of single fiber and cement-soil matrix[D]. Zhoushan: Zhejiang Ocean University, 2017(in Chinese).
-
