复合材料厚壁连杆RTM成型工艺模拟及制造验证

基金项目: 国家973项目课题(2010CB631101)

详细信息

Process simulation and manufacture testing of composite thick-wall drag brace via RTM technology

1.
Science and Technology on Advanced Composites Laboratory, Beijing Institute of Aeronautical Materials, Beijing 100095, China;
2.
China Air-to-Air Missile Academy, Luoyang 471009, China

摘要

摘要: 根据复合材料的可制造性及RTM成型工艺的特点对复合材料厚壁连杆的几何外形进行了优化设计。测定了纤维预成型体的渗透率参数, 采用数值模拟技术研究其RTM成型工艺过程, 并根据RTM流动模拟结果设计了成型模具, 成功地利用RTM工艺制备了复合材料厚壁连杆样件。对样件的力学试验考核表明, 采用基于数值模拟技术的工艺设计能够很好地满足制件的制造及载荷要求。
- 复合材料 /
- RTM /
- 厚壁结构 /
- 渗透率 /
- 流动模拟
Abstract: The optimized configuration of thick-wall drag brace was designed according to the permissibility of composites and the characteristics of resin transfer molding (RTM) process. The permeability of the preforms was measured and the RTM process was investigated by the numerical simulation. The RTM mold was manufactured based on the results of the flow simulation. A specimen of thick-wall drag brace was successfully manufactured via RTM process and the specimen was evaluated by mechanical test. The mechanical results show that the drag brace designed based on the numerical simulation well meet the manufacturing and loading requirements.
- composites /
- RTM /
- thick-wall structure /
- permeability /
- flow simulation
