形变Cu-11.5 %Fe 原位复合材料的强度和导电性
STRENGTH AND CONDUCTIVITY OF DEFORMATION-PROCESSEDCu-11.5 %Fe IN SI TU COMPOSITE
-
摘要: 研究了经多次冷拔或冷拔配合中间热处理制得的形变Cu-11.5 %Fe 原位复合材料的组织、强度和导电性。用SEM 和TEM 观察分析了材料的组织结构。结果发现, 形变量η ≥5137 的形变Cu-11.5 %Fe 原位复合材料的Fe 树枝晶已成为细纤维状, 在横截面呈薄片弯曲状。形变量越大, 纤维越均匀细化。力学性能和电阻率测试结果发现, 随形变量增加, 强度提高, 同时电阻率增大。中间热处理可在不损失强度的同时, 明显降低电阻率。经3 次中间热处理后, 不同形变量下的材料电阻率均可下降约4.4μΩ·cm。几个较好的电导率和极限抗拉强度组合为: 70.6 %/ 659 MPa (Φ0.8) 、64.6 %/ 752 MPa (Φ0.5) 和51.9 %/ 880 MPa (Φ0.2) 。Abstract: St ructure, st rength and elect rical conductivity of Cu-11.5 %Fe in si tu composite obtained by cold drawing or cold drawing combined with intermediate heat treatments were investigated. The structures of the compositeswere examined by SEM and TEM. The result s indicate that the Fe dendrites were drawn into fine ribbons and the Feribbons are curl and fold in cross-section at st rainη ≥5.37. The fine ribbons are finer and more uniform with thest rain increasing. The experimental result s show that the tensile st rength and elect rical resistivity increase with theincreasing of deformation st rain. Af ter intermediate heat t reatment s, the st rength remains, but the elect rical resistivity decreases drastically. The elect rical resistivity of the in si tu composite with different st rains can decrease about4.4μΩ·cm af ter a series of intermediate heat t reatment s. The good combinations of the elect rical conductivity andthe tensile st rength are the following : 70.6 % IACS ( International Annealed Copper Standard) / 659 MPa (Φ 0.8),64.6 % IACS/ 752 MPa (Φ0.5) and 51.9 % IACS/ 880 MPa (Φ0.2) .
