Low velocity impact resistance of woven fabric reinforced T-shaped composites
-
摘要: 为解决当前T字型铺层复合材料抗层间剪切能力弱的问题，通过对复合材料预制件织造工艺进行合理设计，使用SGA598小样织机织造了T字型织物，采用真空辅助树脂传递模塑(VARTM)工艺将其制备成复合材料，并研究其在低速冲击下的抗冲击性能；使用有限元软件ABAQUS建立了几何与材料模型，模拟了不同冲击能量下的冲击响应过程。研究结果表明，T字型加筋板具有较高的抗冲击能力，模拟结果与实验测试结果吻合较好，该有限元模型具有较好的可靠性。Abstract: In order to solve the problem of weak interlaminar shear resistance of T-shaped laminate composites, the weaving process of composite preform was reasonably designed, and the T-shaped fabric was woven by SGA598 small sample loom. The T-shaped fabric was prepared by vacuum assisted resin transfer molding (VARTM) process, and its impact resistance under low velocity impact was studied. The geometric and material models were established by using the finite element software ABAQUS to simulate the impact response process under different impact energies. The results show that the T-shaped stiffened plate has high impact resistance, and the simulation results are in good agreement with the experimental results. The finite element model has good reliability.
-
-
![]()
图 1 T字型加筋板径向截面示意图
Figure 1. Warp section schematic diagram of T-shaped stiffened plate
H—Total height of fabric; H1—Rib height of the stiffened plate; H2—Floor height; L—Bar width
![]()
图 3 T字型加筋板截面与纱线屈曲状态
Figure 3. Warp section schematic diagram of T-shaped stiffened and yarn buckling state
![]()
图 4 不同冲击能量下T型加筋板载荷峰值
Figure 4. Peak load of T-stiffened plate under different impact energies
![]()
图 7 T型加筋板1/4冲击载荷与边界条件模型
Figure 7. 1/4 impact load and boundary condition model of T-stiffened plate
![]()
图 10 纱线局部坐标与单胞全局坐标
Figure 10. Yarn local coordinates and unit cell global coordinates
W—Unit cell width; L—Unit cell length; L1—Weft width; L2—Binding width; W1—Warp width; W2—Binding length; H1—Weft height; H2—Warp height
![]()
图 11 试验与有限元模拟(FEM)的机织T型加筋板载荷-时间曲线
Figure 11. Test and finite element modelling (FEM) load-time curves of woven T-stiffened plate
EX—Text
![]()
图 12 试验与FEM的机织T型加筋板收能量-时间曲线
Figure 12. Absorb energy-time curves of test and FEM of woven T-stiffened plate
![]()
图 13 机织T型加筋板试验与有限元模拟冲击正面、背面图
Figure 13. Front and back view of impact of experiment and FEM of woven T-stiffened plate
表 1 环氧树脂JC-03 A的规格和性能
Table 1 Specifications and properties of epoxy resin JC-03 A
Material function Numerical value Density/(g·cm−3) 1.12-1.14 Tensile strength/MPa 80 Tensile modulus/MPa 2400 Bend strength/MPa 130 Flexural modulus/MPa 3500 Curing time/h 5-7 Thermal expansion coefficient/(10−6 ℃−1) 37 Curing temperature/℃ 70
下载: 导出CSV
表 2 T型加筋板复合材料规格
Table 2 Specifications of T-stiffened plate composites
Specification Numerical value Length/mm 150 Width/mm 50 Thickness of base plate/mm 5 Rib height/mm 5
下载: 导出CSV
表 3 正交各向异性复合材料力学性能参数
Table 3 Mechanical property parameters of orthotropic composites
Elastic constant Numerical value Young's modulus, E1/MPa 4644 Young's modulus, E2/MPa 5627 Young's modulus, E3/MPa 3705 Shear modulus, G23/MPa 1744 Shear modulus, G13/MPa 1633 Shear modulus, G12/MPa 1855 Poisson’s ratio, ν23 0.32 Poisson’s ratio, ν13 0.33 Poisson’s ratio, ν12 0.19
下载: 导出CSV
表 4 机织T型加筋板 FEM与实验测试误差
Table 4 FEM and experimental test error of woven T-stiffened plate
Energy/J Load peak error/% Maximum absorption
energy error/%20 2.4 2.0 30 4.4 3.6 50 7.2 −2.4 80 2.6 −1.5
下载: 导出CSV
-
[1] 肖遥, 李东升, 吉康, 等. 大型复合材料航空件固化成型模具技术研究与应用进展[J]. 复合材料学报, 2022, 39(3):907-925. XIAO Yao, LI Dongsheng, JI Kang, et al. Research and application progress of curing tooling technology for large composite aeronautical components[J]. Acta Materiae Compositae Sinica,2022,39(3):907-925(in Chinese).
[2] 马全胜, 李学臻, 王玉琳, 等. 三维立体织物复合材料研究与进展[J]. 化工新型材料, 2021, 49(S1):279-282. MA Quansheng, LI Xuezhen, WANG Yulin, et al. Rescarch and progress of 3D stereo fabric composite[J]. New Chemical Materials,2021,49(S1):279-282(in Chinese).
[3] WANG C Z, SU D D, XIE Z F, et al. Low-velocity impact response of 3D woven hybrid epoxy composites with carbon and heterocyclic aramid fibres[J]. Polymer Testing,2021,101:107314. DOI: 10.1016/j.polymertesting.2021.107314
[4] 蔚凤生. 浅谈复合材料在飞机上的设计及应用[J]. 军民两用技术与产品, 2015(8):116. DOI: 10.3969/j.issn.1009-8119.2015.08.107 WEI Fengsheng. Design and application of composite materials in aircraft[J]. Dual Use Technologies & Products,2015(8):116(in Chinese). DOI: 10.3969/j.issn.1009-8119.2015.08.107
[5] 吴承思, 李庆飞. 复合材料机身加筋壁板选型研究[J]. 纤维复合材料, 2016, 33(2):3-5. DOI: 10.3969/j.issn.1003-6423.2016.02.001 WU Chengsi, LI Qingfei. Study about choice of stiffened structure configuration of laminated composite fuselage[J]. Fiber composites,2016,33(2):3-5(in Chinese). DOI: 10.3969/j.issn.1003-6423.2016.02.001
[6] CHEN X, TAYLOR L W, TSAI L J. Three-dimensional fabric structures. Part 1—An overview on fabrication of three-dimensional woven textile preforms for composites[M]. Duxford: Woodhead Publishing Series in Textiles, 2016: 285-304.
[7] CHOU S, CHEN H E. The weaving methods of three-dimensional fabrics of advanced composite materials[J]. Composite Structures,1995,33(3):159-172. DOI: 10.1016/0263-8223(95)00120-4
[8] 欧阳天, 关志东, 谭日明, 等. 复合材料T型加筋板筋条冲击损伤及冲击后压缩行为试验 [J]. 复合材料学报. 2018. 35(10): 2689-2697. OUYANG Tian, GUAN Zhidong, TAN Riming, et al. Experimental study on stiffener impact damage and compression after impact behavior of T-stiffened composite panels[J]. Acta Materiae Compositae Sincia, 2018, 35(10): 2689-2697(in Chinese).
[9] 崔勇江, 王斌团, 赵占文. 复合材料T型加筋壁板后屈曲承载能力研究[J]. 复合材料科学与工程, 2021(7):22-27. CUI Yongjiang, WANG Bintuan, ZHAO Zhanwen. Research on the post-buckling bearing capacity of T-type composite stiffened panel[J]. Composites Science and Engineering,2021(7):22-27(in Chinese).
[10] 贾佳乐. 碳纤维复合材料加筋板低速冲击及其剩余压缩性能研究[D]. 哈尔滨: 哈尔滨理工大学, 2021. JIA Jiale. Investigation on low velocity impact and residual compressive properties of reinforced composite skin[D]. Harbin: Harbin University of Science and Technology, 2021(in Chinese).
[11] 唐振南, 戴瑛, 聂坤, 等. CFRP加筋板剪切稳定性试验和数值分析模型研究[J]. 力学季刊, 2015, 36(3):408-415. TANG Zhennan, DAI Ying, NIE Kun, et al. Shear stability test and numerical model study for carbon fiber reinforced composite stiffened plates[J]. Chinese Quarterly of Mechanics,2015,36(3):408-415(in Chinese).
[12] 刘峰, 张成雷, 马佳, 等. 复合材料工字梁铺层结构设计及强度研究[J]. 机械科学与技术, 2016, 35(4):641-645. DOI: 10.13433/j.cnki.1003-8728.2016.0426 LIU Feng, ZHANG Chenglei, MA Jia, et al. Laminate structure design and strength analysis of I-beam composite[J]. Mechanical Science and Technology for Aerospace Engineering,2016,35(4):641-645(in Chinese). DOI: 10.13433/j.cnki.1003-8728.2016.0426
[13] HAO A, SUN B, QIU Y, et al. Dynamic properties of 3-D orthogonal woven composite T-beam under transverse impact[J]. Composites Part A: Applied Science & Manufacturing,2008,39(7):1073-1082.
[14] 封端佩, 商元元, 李俊. 三维四向和五向编织复合材料冲击断裂行为的多尺度模拟[J]. 纺织学报, 2020, 41(10):67-73. FENG Duanpei, SHANG Yuanyuan, LI Jun. Multi-scale simulation of impact failure behavior for 4- and 5-directional 3D braided composites[J]. Journal of Textile Research,2020,41(10):67-73(in Chinese).
[15] 胡美琪. 三维编织复合材料梁多次横向冲击损伤分布的结构效应和温度效应[D]. 上海: 东华大学, 2020. HU Meiqi. Structural effect and temperature effect on multiple transverse impact damage distributions in 3-D braided composite beams[D]. Shanghai: Donghua University, 2020(in Chinese).
[16] 刘军, 刘奎, 宁博, 等. 三维编织复合材料T型梁的低温场弯曲性能[J]. 纺织学报, 2019, 40(12):57-62. LIU Jun, LIU Kui, NING Bo, et al. Bending properties of three-dimensional braided composite T-beam at low temperature[J]. Journal of Textile Research,2019,40(12):57-62(in Chinese).
[17] 魏小玲, 李瑞雪, 秦卓, 等. 经向T结构预制体成型关键技术[J]. 纺织学报, 2021, 42(11):51-55. WEI Xiaoling, LI Ruixue, QIN Zhuo, et al. Key technologies for formation of warp T-shape preforms[J]. Journal of Textile Research,2021,42(11):51-55(in Chinese).
[18] 邓奇林, 杨敏, 姚彧敏, 等. 三向正交预制体织造参数对C/C复合材料性能的影响[J]. 材料工程, 2022, 50(5):139-146. DENG Qilin, YANG Min, YAO Yumin, et al. Effect of three-directional orthogonal preform weaving parametes on properties of C/C composites[J]. Journal of Materials Engineering,2022,50(5):139-146(in Chinese).
[19] 全国塑料制品标准化技术委员会. 硬质塑料板耐冲性能试验方法(落锤法): GB 11548—89[S]. 北京: 中国质检出版社. 1989. National Technical Committee for Standardization of Plastic Products. Standard text method for impact resistance of rigid plastic sheeting by means of a tup(falling weight): GB 11548—89[S]. Beijing: Chian Quality Inspection Press, 1989(in Chinese).
[20] CHAMIS C C. Mechanics of composite materials: Past, present, and future[J]. Journal of Composites Technology & Research,1989,11(1):3-14.
[21] SUN B Z, LIU Y K, GU B H. A unit cell approach of finite element calculation of ballistic impact damage of 3-D orthogonal woven composite[J]. Composites Part B: Engineering,2009,40(6):552-560. DOI: 10.1016/j.compositesb.2009.01.012
[22] HU M Q, SUN B Z, GU B H. Microstructure modeling multiple transverse impact damages of 3-D braided composite based on thermo-mechanical coupling approach[J]. Composites Part B: Engineering,2021,214:108741. DOI: 10.1016/j.compositesb.2021.108741
-
