复合材料B基准值计算方法研究进展

汪梓迅; 矫维成; 赫晓东

doi:10.13801/j.cnki.fhclxb.20210223.004

复合材料B基准值计算方法研究进展

汪梓迅^1,,
矫维成^{1, 2, ,},
赫晓东^{1, 2,}

1.
哈尔滨工业大学　特种环境复合材料技术国家级重点实验室，哈尔滨 150001
2.
深圳烯创先进材料研究院有限公司，深圳 518000

基金项目: 国家自然科学基金(U1837203)；国家重点研发计划课题(2018YFA0702802)；深圳市科技计划(KQTD2016112814303055)

详细信息

通讯作者:
矫维成，博士，教授，博士生导师，研究方向为树脂基复合材料　 E-mail：xiaojiao458@163.com

中图分类号: TB332
计量
- 文章访问数: 02212
- HTML全文浏览量: 0491
- PDF下载量: 0223
出版历程
- 收稿日期: 2020-11-15
- 录用日期: 2021-02-11
- 网络出版日期: 2021-02-22
- 刊出日期: 2021-06-22

Research progress in calculation method of composite material’s B basis

WANG Zixun^1,,
JIAO Weicheng^{1, 2, ,},
HE Xiaodong^{1, 2,}

1.
National Key Laboratory of Science and Technology on Advanced Composites in Special Environments, Harbin Institute of Technology, Harbin 150001, China
2.
Shenzhen STRONG Advanced Materials Research Institute CO. LTD., Shenzhen 518000, China

摘要

摘要: 在复合材料的结构设计中，复合材料的许用值是关键参数之一。通常采用B基准值这一统计量作为复合材料的许用值，B基准值是具有95%置信度的90%置信下限。准确计算复合材料的B基准值是复合材料安全、可靠应用的保障。本文归纳总结了复合材料B基准值计算方法的研究进展，详细分析了单点法、多环境样本合并法的计算原理、计算过程、适用条件等。结合工程实例数据，分析了不同方法对B基准值计算结果的影响。最后，对复合材料B基准值计算方法的发展趋势及预期研究方向进行了展望。
- 复合材料 /
- B基准值 /
- 单点法 /
- 多环境样本合并法
Abstract: In the structural design of composite materials, the allowable value is one of the key parameters. The statistic of B basis is usually used as the allowable value of composite materials, and the B basis is the lower limit of 90% confidence with 95% confidence. Accurate calculation of the B basis of composite materials is the guarantee for the safe and reliable application of composite materials. This article summarizes the research progress of the calculation method of the composite material’s B basis, and analyzes in detail the calculation principle, calculation process and applicable conditions of the single-point method and the pooling method. And combined with the project data, the influence of different methods on the calculation results of the B basis is analyzed. Finally, the development trend and expected research direction of the calculation method of composite material B basis are prospected.
- composite materials /
- B basis /
- single-point method /
- pooling method

HTML全文

图 1 复合材料B基准值计算方法发展历程^[3-5]

Figure 1. History of B basis^[3-5]

下载: 全尺寸图片幻灯片

图 2 MIL-HDBK-17-1F单点法计算流程^[10-15]

Figure 2. MIL-HDBK-17-1F single point method calculation process ^[10-15]

下载: 全尺寸图片幻灯片

图 3 CMH-17G单点法计算流程^[10-15]

Figure 3. CMH-17G single point method calculation process^[10-15]

下载: 全尺寸图片幻灯片

图 4 CMH-17G多点法计算流程^[10-15]

Figure 4. CMH-17G Pooling Method calculation process^[10-15]

C_v—Coefficient of variation

下载: 全尺寸图片幻灯片

图 5 威布尔分布与正态分布的L比较

Figure 5. L comparison of Weibull distribution and Normal distribution

下载: 全尺寸图片幻灯片

图 6 离散系数变化前后正态分布的L比较

Figure 6. Comparison of L before and after variation of dispersion coefficient

下载: 全尺寸图片幻灯片

图 7 离散系数变化前后正态分布与威布尔分布L之差

Figure 7. L graph of the normal distribution minus the Weibull distribution before and after the dispersion coefficient changes

下载: 全尺寸图片幻灯片

图 8 单点法与多环境样本法L比较

Figure 8. L comparison between single point method and pooling method

下载: 全尺寸图片幻灯片

图 9 合并离散系数与合并标准差L比较

Figure 9. L comparison of combined dispersion coefficient and combined standard deviation

下载: 全尺寸图片幻灯片

参考文献(21)

[1]	SPENDLEY P R. Design allowables for composite aerospace structures[D]. Guildford: University of Surrey, 2012.
[2]	YURVIANY, TAMAZA D, WIDAGDO D, et al. Statistical analysis of CFRP mechanical properties using B-basis based on weibull and ANOVA distribution analysis[J]. IOP Conference Series: Materials Science and Engineering,2020,852(1):012078.
[3]	HAN X L. Normalized B-basis of the space of trigonometric polynomials and curve design[J]. Applied Mathematics & Computation,2015,251:336-348.
[4]	EKVALL J C, GRIFFIN C F. Design allowables for T300/5208 graphite/epoxy composite materials[J]. Journal of Aircraft, 1982, 19(8): 661-667.
[5]	王思雍. T800级碳纤维/环氧树脂复合材料性能测试与B基准值计算研究[D]. 哈尔滨: 哈尔滨工业大学, 2020. WANG Siyong. Study on mechanical properties and B-basis calculation of T800 carbon fiber reinforced epoxy resin composites[D]. Harbin: Harbin Institute of Technology, 2020(in Chinese).
[6]	郝新超. 基于Anderson-Darling检验的复合材料厚板层间拉伸强度性能研究及B基准值[J]. 材料导报, 2020, 34(S1):480-485. HAO Xinchao. Interlaminar tensile strength behavior and B-basis value of thick laminates based on anderson-darling test[J]. Material Guide,2020,34(S1):480-485(in Chinese).
[7]	赵晖, 张立同, 张家鑫. 基于小样本物理测试的复合材料B基准许用值分析计算[J]. 玻璃钢/复合材料, 2019(4):62-66, 74. ZHAO Hui, ZHANG Litong, ZHANG Jiaxin. Composite material B-basis allowable simulation based on small sample physical tests[J]. FRP/Composite Materials,2019(4):62-66, 74(in Chinese).
[8]	BARBERO E, FERNÁNDEZ-SÁEZ J, NAVARRO C. Statistical analysis of the mechanical properties of composite materials[J]. Composites Part B: Engineering, 2000, 31(5): 375-381.
[9]	ELIZABETH C. Hexcel 8552 IM7 unidirectional prepreg 190 gsm & 35% RC qualification statistical analysis report[R]. USA: WichitaState University, National Institute for Aviation Research, 2012: 1-104.
[10]	ABUMERI G, HOUSNER J, GARG M, et al. Determination of composites A-and B-basis allowables with reduced testing[C]//The Society for the Advancement of Material and Process Engineering. California: 2011.
[11]	Federal Aviation Administration. Composite materials handbook-Volume 1. Polymer matrix composites: Guidelines for characterization of structural materials: MIL-HDBK-17-1F[S]. Washington: Federal Aviation Administration, 2002.
[12]	TOMBLIN J S, NG Y C, RAJU K S. Material qualification and equivalency for polymer matrix composite material systems: Updated procedure: DOT/FAA/AR-03/19[R]. Washington: Federal Aviation Administration, 2003.
[13]	沈薇, 杨胜春, 沈真. 复合材料力学性能表征标准化研究新进展[J]. 航空制造技术, 2009(S1):25-27, 29. SHEN Wei, YANG Shengchun, SHEN Zhen. New progress in standardization of mechanical properties characterization of composite materials[J]. Aviation Manufacturing Technology,2009(S1):25-27, 29(in Chinese).
[14]	Society of Automotive Engineers International. Composite materials handbook-Volume 1: Polymer matrix compo-sites: Guidelines for characterization of structural materials: CMH-17G[S]. Warrendale: SAE International, 2012.
[15]	孙坚石, 叶强. 复合材料力学性能数据B基准值计算程序[J]. 航空制造技术, 2009(S1):19-21, 24. SUN Jianshi, YE Qiang. Aeronautical manufacturing technology composite material mechanical performance data B benchmark value calculation program[J]. Aviation Manufacturing Technology,2009(S1):19-21, 24(in Chinese).
[16]	WHITEHEAD R S, KAN H P, CORDERO R, et al. Certification testing methodology for composite structure[R]. Atlanta, 1986.
[17]	ZHANG Y, KIM N H, PALLIYAGURU U R, et al. Reduced allowable strength of composite laminate for unknown distribution due to limited tests[J]. Journal of Composite Materials,2020,54(21):0021998320903781.
[18]	ZHANG Y, SCHUTTE J, MEEKER J, et al. Predicting B-basis allowable at untested points from experiments and simulations of plates with holes[C]//12th World Congress on Structural and Multidisciplinary Optimization, Braunschweig, 2017.
[19]	王艺. 航空材料性能设计许用值统计分析与软件开发[D]. 沈阳: 东北大学, 2012. WANG Yi. Statistical analysis and software development of the allowable value for the performance design of aviation materials[D]. Shenyang: Northeastern University, 2012(in Chinese).
[20]	王翔, 陈新文, 王海鹏, 等. 基于统计的复合材料B基准值计算方法研究[J]. 失效分析与预防, 2010, 5(4):210-215. DOI: 10.3969/j.issn.1673-6214.2010.04.004 WANG Xiang, CHEN Xinwen, WANG Haipeng, et al. Statistic-based calculation methods B-basis value of composites[J]. Failure Analysis and Prevention,2010,5(4):210-215(in Chinese). DOI: 10.3969/j.issn.1673-6214.2010.04.004
[21]	冯振宇, 刘星星, 魏书有, 等. 复合材料B基准值统计方法的对比分析[J]. 材料导报, 2012, 26(S2):147-149. FENG Zhenyu, LIU Xingxing, WEI Shuyou, et al. The comparision of statistical analysis methods on composite B basis value[J]. Materials Review,2012,26(S2):147-149(in Chinese).
