膨胀石墨-碳纤维/尼龙三元导热复合材料制备

史青, 彭勃, 朱爱萍

史青, 彭勃, 朱爱萍. 膨胀石墨-碳纤维/尼龙三元导热复合材料制备[J]. 复合材料学报, 2019, 36(3): 555-562. DOI: 10.13801/j.cnki.fhclxb.20180704.003
引用本文: 史青, 彭勃, 朱爱萍. 膨胀石墨-碳纤维/尼龙三元导热复合材料制备[J]. 复合材料学报, 2019, 36(3): 555-562. DOI: 10.13801/j.cnki.fhclxb.20180704.003
SHI Qing, PENG Bo, ZHU Aiping. Preparation of expanded graphite-carbon fiber/nylon ternary thermally conductive composites[J]. Acta Materiae Compositae Sinica, 2019, 36(3): 555-562. DOI: 10.13801/j.cnki.fhclxb.20180704.003
Citation: SHI Qing, PENG Bo, ZHU Aiping. Preparation of expanded graphite-carbon fiber/nylon ternary thermally conductive composites[J]. Acta Materiae Compositae Sinica, 2019, 36(3): 555-562. DOI: 10.13801/j.cnki.fhclxb.20180704.003

膨胀石墨-碳纤维/尼龙三元导热复合材料制备

基金项目: 江苏省高校重点项目(14KJA430006)
详细信息
    通讯作者:

    朱爱萍,博士,教授,博士生导师,研究方向为高分子及其微纳复合材料,E-mail:apzhu@yzu.edu.cn

  • 中图分类号: TB332

Preparation of expanded graphite-carbon fiber/nylon ternary thermally conductive composites

  • 摘要: 以尼龙6(PA6)为基体,膨胀石墨(EG)和碳纤维(CF)作为导热填料,采用熔融共混法制备了EG/PA6、CF/PA6和CF-EG/PA6导热复合材料。重点研究当固定导热填料(CF和EG)填充量为40wt%时,CF与EG不同的填充比例对CF与EG的接触方式及CF-EG/PA6复合材料的导热性和力学性能的影响。结果表明,相比单一CF填充,EG的加入有利于CF-EG/PA6复合材料热导率的增加;CF:EG质量比是25:15时的EG-CF/PA6三元复合材料,热导率可以达到2.554 W/(m·K),是PA6的8倍,拉伸强度提高了125.34%,弯曲强度提高了119.8%,同时具有优异的耐热性。SEM结果表明,纤维状CF与蠕虫状EG片层在适当的填充比例下可以形成"面接触"的三维网络结构,这种三维网络结构不仅显著增大EG-CF/PA6复合材料的热导率,而且明显提高了其力学性能和耐热性能。为研制填充型导热高分子材料提供了一条新思路。
    Abstract: With nylon 6 (PA6) as the matrix and carbon fiber (CF), expanded graphite (EG) as the thermal conductive filler, EG/PA6, CF/PA6 and CF-EG/PA6 thermal conductive composites were prepared by melt-mixing. Fixed the filling content of 40wt%, the effects of different ratios of CF to EG on the contact mode between CF and EG, and the thermal conductivity and mechanical properties of CF-EG/PA6 composites were studied. The results indicate that the addition of EG is beneficial to increase of the thermal conductivity of CF-EG/PA6 composites compared to single CF filling; When CF:EG mass ratio is 25:15, the thermal conductivity of CF-EG/PA6 composite reaches 2.554 W/(m·K), which is 7 times higher than that of PA6, the tensile strength is increased by 125.34%, the flexual strength is increased by 119.8%, and the heat resistance demonstrates excellent. The SEM results show that fibrous CF and worm-like EG can form a 3D network structure with "Terms contact" under the appropriate filling ratio. The 3D network structure not only significantly increases the thermal conductivity of CF-EG/PA6 composite, but also significantly improves the mechanical and thermal properties of the composite. It provides a new idea for the development of filled thermally conductive polymer materials.
