均匀粒度分布的双壳相变储湿微胶囊制备

Preparation of double-shell phase change and humidity storage micro-capsules with uniform particle size distribution

  • 摘要: 分别以正十八烷、甲基丙烯酸甲酯和壳聚糖作为核材料、内壳和外壳,采用细乳液原位聚合法及界面聚合法制备双壳相变储湿微胶囊。通过均匀设计与径向基函数神经网络结合,考察因素(如乳化剂用量、助乳化剂用量、引发剂用量、超声乳化时间和搅拌速度)对双壳相变储湿微胶囊粒度分布的影响,并且对最均匀粒度分布双壳相变储湿微胶囊进行表征与测试。结果表明,当扩展系数为0.55时,径向基函数神经(Radial Basis Function,RBF)网络具有最佳的逼近效果。最均匀粒度分布双壳相变储湿微胶囊的制备工艺参数:乳化剂用量为3.58wt%、助乳化剂用量为0.53wt%、引发剂用量为1.86wt%、超声乳化时间为11.35 min,搅拌速度为632 r· min-1。基于上述制备参数,d10为3 352.0 nm、d50为4 474.9 nm,d90为6 108.4 nm,d90-d10实测值为2 756.4 nm,实测值与预测值吻合较好,相对误差为2.69%。在相对湿度35%~65%的平衡含湿量为0.0547~0.1259 g · g-1,相变温度为28.87℃,相变焓为78.45 J · g-1



    Abstract: With n-octadecane, methyl methacrylate and chitosan as the core material, inner shell and outside shell respectively, the double-shell phase change and humidity storage micro-capsules were made by in-situ polymerization and emulsion interfacial polymerization method. Combining the uniform design and radial basis function neural network, the effect of parameters (i.e. emulsifier amount, co-emulsifier amount, initiator amount, phacoemulsification time and mixing speed) on particle size distribution of double-shell phase change and humidity storage micro-capsules were investigated. In addition, the optimal uniform particle size distribution of double-shell phase change and humidity storage micro-capsules were tested and characterized. The results show that radial basis function(RBF) neural network has the best approximation effect when "Spread" is 0.55. To obtain optimal uniform particle size distribution for double-shell phase change and humidity storage micro-capsules, the preparation parameters are identified as follows:emulsifier amount to be 3.58wt%, co-emulsifier amount to be 0.53wt%, initiator amount to be 1.86wt%, phacoemulsification time to be 11.35 min and mixing speed to be 632 r·min-1. On the base of the above preparation parameters, d10 is 3 352.0 nm, d50 is 4 474.9 nm, d90 is 6 108.4 nm, and the measured value of d90-d10 is 2 756.4 nm. Therefore, the measured value agrees well with the predictive value (relative error is 2.69%). In the case of relative humidity between 35% and 65%, the equilibrium moisture content is obtained to be between 0.0547 g·g-1 and 0.1259 g·g-1, phase transition temperature is 28.87℃ and phase change enthalpy is 78.45 J·g-1.



/
