仿贝壳TiB2/Al-Cu层状复合材料的组织及其力学性能

林波 王明辉 张文馨 肖华强 赵愈亮 张卫文

林波, 王明辉, 张文馨, 等. 仿贝壳TiB2/Al-Cu层状复合材料的组织及其力学性能[J]. 复合材料学报, 2022, 39(7): 3554-3563. doi: 10.13801/j.cnki.fhclxb.20211020.001
引用本文: 林波, 王明辉, 张文馨, 等. 仿贝壳TiB2/Al-Cu层状复合材料的组织及其力学性能[J]. 复合材料学报, 2022, 39(7): 3554-3563. doi: 10.13801/j.cnki.fhclxb.20211020.001
LIN Bo, WANG Minghui, ZHANG Wenxin, et al. Microstructure and mechanical properties of nacre-inspired TiB2/Al-Cu composites[J]. Acta Materiae Compositae Sinica, 2022, 39(7): 3554-3563. doi: 10.13801/j.cnki.fhclxb.20211020.001
Citation: LIN Bo, WANG Minghui, ZHANG Wenxin, et al. Microstructure and mechanical properties of nacre-inspired TiB2/Al-Cu composites[J]. Acta Materiae Compositae Sinica, 2022, 39(7): 3554-3563. doi: 10.13801/j.cnki.fhclxb.20211020.001

仿贝壳TiB2/Al-Cu层状复合材料的组织及其力学性能

doi: 10.13801/j.cnki.fhclxb.20211020.001
基金项目: 国家自然科学基金项目(52074131;51704084);贵州省千层次创新型人才项目(贵大“千”层次[2018]03);贵州省自然科学基金一般项目(黔科合基础-ZK[2021]一般267);贵州省科技成果应用及产业化项目(黔科合成果[2021]一般067);贵州大学培育项目(2019[23])
详细信息
    通讯作者:

    林波,博士,副教授,硕士生导师,研究方向为铝基层状复合材料 E-mail: linbo1234@126.com

    张文馨,硕士,研究方向为铝基复合材料 E-mail: 18813094070@163.com

  • 中图分类号: TB333

Microstructure and mechanical properties of nacre-inspired TiB2/Al-Cu composites

  • 摘要: 陶瓷增强铝基复合材料是轻量化结构件的较理想材料,但随着陶瓷增强相含量的增加,复合材料的韧性会降低,导致复合材料服役过程中安全性的下降。因此如何实现复合材料高强韧性的匹配是制备陶瓷增强铝基复合材料一直存在的难题。根据仿生学思想,采用冷冻铸造及压力浸渗技术制备了不同陶瓷初始固相含量(20vol%、30vol%、40vol%)的TiB2/Al-Cu层状复合材料。采用光学显微镜(OM)、扫描电子显微镜(SEM)、X射线衍射分析(XRD)和力学性能测试研究了不同陶瓷初始固相含量对于TiB2/Al-Cu层状复合材料微观组织和力学性能的影响。实验结果表明,随着陶瓷初始固相含量的提升,复合材料中陶瓷片层厚度增加,金属片层厚度减小,复合材料的抗压强度有所提升但抗弯强度和断裂韧性下降。其中,20vol%陶瓷初始固相含量的TiB2/Al-Cu层状复合材料拥有较优的断裂韧性,达到了(20.59±1.5) MPa·m1/2;40vol%陶瓷初始固相含量制备的TiB2/Al-Cu层状复合材料拥有较优的抗压强度,达到了(670±20) MPa。这主要是因为随着复合材料中陶瓷初始固相含量的提升,层状复合材料更容易发生界面脱层,层状复合材料通过合金塑性变形等增韧效果减弱;同时,裂纹偏折、界面剥落、裂纹分支等增韧效果也降低。



  • 图  1  冷冻铸造实验装置示意图

    Figure  1.  Schematic diagram of the freeze casting process

    PTFE—Poly tetra fluoroethylene

    图  2  不同陶瓷初始固相含量的TiB2/Al-Cu层状复合材料的XRD图谱

    Figure  2.  XRD patterns of the TiB2/Al-Cu composites corresponding with different ceramic initial solid contents

    图  3  TiB2/Al-Cu层状复合材料30vol%陶瓷初始固相含量试样的SEM图像(a)和EDS能谱图((b)~(g))

    Figure  3.  SEM image (a) and EDS mappings ((b)-(g)) of the TiB2/Al-Cu composites corresponding with 30vol% ceramic initial solid content

    图  4  不同陶瓷初始固相含量的TiB2/Al-Cu层状复合材料试样光学显微镜图像:(a) 20vol%;(b) 30vol%;(c) 40vol%

    Figure  4.  Optical microscope images of nacre-inspired TiB2/Al-Cu composites with different ceramic initial solid contents: (a) 20vol%; (b) 30vol%; (c) 40vol%

    图  5  不同陶瓷初始固相含量TiB2/Al-Cu层状复合材料试样的强度、应力-应变曲线和断裂韧性:(a)压缩应力-应变曲线;(b)三点弯曲应力-应变曲线;(c)单边缺口梁(SENB)试样力-位移曲线; (d)强度与断裂韧性

    Figure  5.  Stress-strain curves and strength and crack-initiation toughness of the nacre-inspired TiB2/Al-Cu composites with different ceramic initial solid contents: (a) Compressive stress-strain curves; (b) Three-point bending stress-strain curves; (c) Load-displacement curves of the SENB samples; (d) Strength and crack-initiation toughness

    图  6  不同陶瓷初始固相含量的TiB2/Al-Cu层状复合材料弯曲试样断口形貌:((a)、(b)) 20vol%;((c)、(d)) 30vol%;((e)、(f)) 40vol%

    Figure  6.  Fracture surfaces of the samples after bending tests of the nacre-inspired TiB2/Al-Cu composites with different ceramic initial solid contents: ((a), (b)) 20vol%; ((c), (d)) 30vol%; ((e), (f)) 40vol%

    图  7  不同陶瓷初始固相含量TiB2/Al-Cu层状复合材料SENB试样裂纹扩展路径:((a)、(b)) 20vol%;((c)、(d)) 30vol%;((e)、(f)) 40vol%

    Figure  7.  Crack propagation path of SENB sample of nacre-inspired TiB2/Al-Cu composite with different ceramic initial solid contents: ((a), (b)) 20vol%; ((c), (d)) 30vol%; ((e), (f)) 40vol%

    表  1  Al-Cu合金化学成分

    Table  1.   Al-Cu alloy chemical composition at%

    ElementCuMnMgTiAl
    Content5.040.560.10.08Others
    下载: 导出CSV

    表  2  不同陶瓷初始固相含量TiB2/Al-Cu层状复合材料及其他仿贝壳珍珠层状陶瓷增强铝基复合材料 (AMCs)的力学性能

    Table  2.   The mechanical properties of nacre-inspired TiB2/Al-Cu composites with different ceramic initial solid contents and the other reported nacre-inspired lamellar structure AMCs

    AlloyDirectionCompressive strength/MPaBending strength/MPaBreaking tenacity KIC /(MPa·m1/2)Ref.
    0vol% TiB2/Al-Cu410±10In this study
    20vol% TiB2/Al-CuLongitudinal560±5574±420.59±1.5In this study
    30vol% TiB2/Al-CuLongitudinal615±8578±220.32±1.15In this study
    40vol% TiB2/Al-CuLongitudinal670±20551±1514.13±1.3In this study
    18vol% TiC/AlLongitudinal35513.6[20]
    35vol% Al2O3/AlLongitudinal34517[27]
    30vol% Al2O3/6061Longitudinal538-854278-3507.6-9.2[28]
    30vol% TiB2/Al-SiLongitudinal71062916.4[25]
    20vol% SiC/ZL205ALongitudinal760±1014.7±0.3[29]
    30vol% SiC/ZL205ALongitudinal626±1212.9±0.6[29]
    40vol% SiC/ZL205ALongitudinal445±157.3±0.4[29]
    下载: 导出CSV
