海藻酸钠-羧甲基纤维素-氧化石墨烯复合气凝胶的制备及其对Pb(II)的吸附

田甜; 付义乐; 关丽; 王溢源; 周军

doi:10.13801/j.cnki.fhclxb.20230314.001

海藻酸钠-羧甲基纤维素-氧化石墨烯复合气凝胶的制备及其对Pb(II)的吸附

doi: 10.13801/j.cnki.fhclxb.20230314.001

西安建筑科技大学　化学与化工学院，西安 710055

基金项目: 国家自然科学基金(21807086)；陕西省自然科学基础研究计划项目(2022JM-096)

详细信息

通讯作者:
付义乐，博士，副教授，硕士生导师，研究方向为功能材料的制备及性能研究　E-mail: fuyile@xauat.edu.cn

中图分类号: X703；TQ424
计量
- 文章访问数: 717
- HTML全文浏览量: 533
- PDF下载量: 38
- 被引次数: 0
出版历程
- 收稿日期: 2022-11-29
- 修回日期: 2023-02-20
- 录用日期: 2023-03-03
- 网络出版日期: 2023-03-15
- 刊出日期: 2023-10-15

Preparation of sodium alginate-carboxymethyl cellulose-graphene oxide composite aerogel for adsorption of Pb(II) ion

School of Chemistry and Chemical Engineering, Xi'an University of Architecture and Technology, Xi'an 710055, China

Funds: National Natural Science Foundation of China (21807086); Natural Science Basic Research Program of Shaanxi (2022JM-096)

摘要

摘要: 目前，开发具有优异吸附性能、可持续使用和绿色环保的吸附剂仍然是水污染治理领域的焦点问题。因此，本文以海藻酸钠(SA)、羧甲基纤维素(CMC)和氧化石墨烯(GO)为原料，通过简单的溶胶-凝胶法结合冷冻干燥，构建了具有三维多孔网络结构的SA-CMC-GO复合气凝胶。利用SEM、FTIR、XRD等对SA-CMC-GO复合气凝胶的微观形貌、官能团结构等进行表征分析。以水中Pb²⁺为吸附对象，通过一系列间歇吸附实验，探究了各种因素(pH、介质温度、接触时间等)对吸附剂去除水体中Pb²⁺的影响。结果表明：在pH值2~5的范围内，复合气凝胶对Pb²⁺的吸附量随着pH的升高而升高；复合气凝胶对于Pb²⁺的吸附过程属于自发放热过程并遵循Langmuir吸附等温模型，其最大吸附量为272.5 mg·g⁻¹；动力学研究表明，SA-CMC-GO复合气凝胶对Pb²⁺具有较快的吸附速率，可在60 min内达平衡并符合准二级动力学模型；此外，经过5次吸附-脱附试验，复合气凝胶仍对Pb²⁺保持较高的吸附性能。SA-CMC-GO复合气凝胶可以作为一种高效、快速的吸附剂用于从水体中去除Pb²⁺。
- 气凝胶 /
- 海藻酸钠 /
- 羧甲基纤维素 /
- 氧化石墨烯 /
- 吸附
Abstract: Exploiting adsorbents with excellent adsorption activity, good durability and environment friendly is still the core focus of water pollution treatment. Herein, in this study, sodium alginate (SA), carboxymethyl cellulose (CMC), and graphene oxide (GO) were used as raw materials to frame a SA-CMC-GO composite aerogel with a 3D network structure by a sol-gel and freeze-drying method. The functional group structure and microstructure of SA-CMC-GO composite aerogel were tested and analyzed by SEM, FTIR and XRD. Various parameters affecting the removal of Pb²⁺ such as pH, temperature and contact time were optimized by using a series of batch adsorption experiments. The results show that the adsorption amount of Pb²⁺ by the composite aerogel increases with the increase of pH=2-5. The adsorption process is a spontaneous exothermic process and the experimental data of the adsorption process are more fitted to Langmuir isotherm, the theoretical maximum adsorption capacity of Pb²⁺ on SA-CMC-GO composite aerogel is 272.5 mg·g⁻¹. Adsorption kinetics studies indicate the adsorption of Pb²⁺ by the SA-CMC-GO composite aerogel shows rapid uptake rates and reaches equilibrium within 60 min. The pseudo-second-order kinetic model coincides with the adsorption behavior of the composite aerogel. Furthermore, the composite aerogel exhibited better reusability for five adsorption and desorption cycles with highly adsorption properties. The results imply that the new SA-CMC-GO composite aerogel could be potentially applied as an effective and rapid adsorbent for Pb²⁺ removal from aqueous solutions.
- aerogel /
- sodium alginate /
- carboxymethyl cellulose /
- graphene oxide /
- adsorption

HTML全文

图 1 海藻酸钠-羧甲基纤维素-氧化石墨烯(SA-CMC-GO)复合气凝胶制备流程

Figure 1. Preparation process of sodium alginate-carboxymethyl cellulose-graphene oxide (SA-CMC-GO) composite aerogel

T—Temperature; t—Time

下载: 全尺寸图片幻灯片

图 2 ((a), (b)) CMC-GO复合气凝胶的SEM图像；SA-CMC-GO复合气凝胶的SEM图像((c), (d))和EDS能谱(e)

Figure 2. ((a), (b)) SEM images of CMC-GO composite aerogel; SEM images ((c), (d)) and EDS mapping (e) of SA-CMC-GO composite aerogel

下载: 全尺寸图片幻灯片

图 3 CMC、GO、SA、SA-CMC-GO复合气凝胶的FTIR图谱

Figure 3. FTIR spectra of CMC, GO, SA and SA-CMC-GO composite aerogel

下载: 全尺寸图片幻灯片

图 4 CMC气凝胶和SA-CMC-GO复合气凝胶的XRD图谱

Figure 4. XRD patterns of CMC aerogel and SA-CMC-GO composite aerogel

下载: 全尺寸图片幻灯片

图 5 SA-CMC-GO复合气凝胶的XPS图谱：(a) 全谱；(b) C1s；(c) O1s

Figure 5. XPS spectra of SA-CMC-GO composite aerogel: (a) Full spectrum; (b) C1s; (c) O1s

下载: 全尺寸图片幻灯片

图 6 溶液pH与SA-CMC-GO复合气凝胶吸附Pb²⁺去除率和吸附量的关系

Figure 6. Relationship between solution pH and removal rate and adsorption capacity of Pb²⁺ by SA-CMC-GO composite aerogel

q_e—Equilibrium adsorption capacity

下载: 全尺寸图片幻灯片

图 7 吸附时间与SA-CMC-GO复合气凝胶对Pb²⁺的吸附量的关系

Figure 7. Relationship between adsorption time and the adsorption capacity of Pb²⁺ adsorbed by SA-CMC-GO composite aerogel

下载: 全尺寸图片幻灯片

图 8 温度与SA-CMC-GO复合气凝胶对Pb²⁺的吸附量的关系

Figure 8. Relationship between temperature and the adsorption capacity of Pb²⁺ adsorbed by SA-CMC-GO composite aerogel

下载: 全尺寸图片幻灯片

图 9 SA-CMC-GO复合气凝胶吸附Pb²⁺：(a) 准一级动力学模型；(b) 准二级动力学模型；(c) 粒子内扩散模型

Figure 9. Pb²⁺ adsorption by SA-CMC-GO composite aerogel: (a) Pseudo-first-order kinetic model; (b) Pseudo-second-order kinetic model; (c) Intra-particle diffusion model

q_t—Adsorption capacity at time t

下载: 全尺寸图片幻灯片

图 10 SA-CMC-GO复合气凝胶吸附Pb²⁺：(a) Langmuir模型；(b) Freundlich模型

Figure 10. SA-CMC-GO composite aerogel on Pb²⁺: (a) Langmuir model; (b) Freundlich model

c_e—Concentration at adsorption equilibrium

下载: 全尺寸图片幻灯片

图 11 循环次数与SA-CMC-GO复合气凝胶对Pb²⁺去除率的关系

Figure 11. Relationship between cycle times and the Pb²⁺ removal rate of SA-CMC-GO composite aerogel

下载: 全尺寸图片幻灯片

图 12 SA-CMC-GO复合气凝胶对Pb²⁺的吸附原理图

Figure 12. Mechanism of the adsorption of Pb²⁺ by SA-CMC-GO composite aerogel

下载: 全尺寸图片幻灯片

表 1 元素的原子分数

Table 1. Atomic fraction of the element

Atomic fraction/at%
C		O			Na
C—C	C—O	C=O	C—O	COO⁻	—
65.55	10.63	4.88	19.23	1.83	1.87

下载: 导出CSV

表 2 不同吸附剂对Pb²⁺的平衡吸附时间

Table 2. Equilibrium adsorption time of Pb²⁺ by different adsorbents

Adsorbent	Time/min	Ref.
DGO/CMC	550	[3]
GO/CMC	600	[21]
NSC	150	[25]
Cell@PEI	240	[26]
NPCS-PEI	120	[27]
SA-CMC-GO	60	This study
Notes: DGO—Functionalized graphene oxide; NSC—Nano-cellulose/sodium alginate/carboxymethyl chitosan aerogel; Cell@PEI—Amino-modified cellulose aerogel; NPCS-PEI—N-methylene phosphonic acid chitosan.

下载: 导出CSV

表 3 SA-CMC-GO复合气凝胶对Pb²⁺的吸附热力学相关参数

Table 3. Thermodynamically relevant parameters for the adsorption of Pb²⁺ by SA-CMC-GO composite aerogel

T/K	ΔG/(kJ·mol⁻¹)	ΔS/(kJ·mol⁻¹·K⁻¹)	ΔH/(kJ·mol⁻¹)
303	−8.297	−0.08298	−33.44
308	−7.882
313	−7.467
Notes: T—Temperature; ΔH—Enthalpy change; ΔS—Entropy change; ΔG—Gibbs free energy change.

下载: 导出CSV

表 4 SA-CMC-GO复合气凝胶对Pb²⁺的吸附动力学拟合参数

Table 4. Fitting parameters for the kinetics of Pb²⁺ adsorption by SA-CMC-GO composite aerogel

Pseudo-first-order kinetic model			Pseudo-second-order kinetic model
q_e/(mg·g⁻¹)	k₁/min⁻¹	R²	q_e/(mg·g⁻¹)	k₂/(g·mg⁻¹·min⁻¹)	R²
71.71	0.02374	0.7546	230.9	3.576×10⁻⁴	0.9942
Notes: R²—Linear correlation coefficient; k₁—Pseudo-first-order kinetic constant; k₂—Pseudo-second-order kinetic constant.

下载: 导出CSV

表 5 SA-CMC-GO复合气凝胶吸附Pb²⁺的粒子内扩散模型拟合参数

Table 5. Fitting parameters for the intra-particle diffusion model for Pb²⁺ adsorption by SA-CMC-GO composite aerogel

k₁/ (mg·g⁻¹·min^0.5)	R₁²	k₂/ (mg·g⁻¹·min^0.5)	R₂²	k₃/ (mg·g⁻¹·min^0.5)	R₃²
37.70	0.9920	11.13	0.9917	0.5009	0.9923
Note: k_i—Intra-particle diffusion rate constant, i=1, 2, 3.

下载: 导出CSV

表 6 SA-CMC-GO复合气凝胶吸附Pb²⁺的等温线吸附Langmuir模型和Freundlich模型参数

Table 6. Isothermal adsorption parameters of SA-CMC-GO composite aerogel for Pb²⁺ adsorption by Langmuir model and Freundlich model

Langmuir model			Freundlich model
q_e/ (mg·g⁻¹)	K_L	R²	K_F	n	R²
272.5	0.4809	0.9974	155.1	7.125	0.6719
Notes: K_L—Langmuir adsorption coefficient; K_F—Freundlich adsorption coefficient; n—Adsorption strength constant.

下载: 导出CSV
