飞艇用织物膜材单轴拉伸蠕变强度试验与模型

宋寅搏 陈务军 高成军 陈龙龙 王晓情 闫勇升

宋寅搏, 陈务军, 高成军, 等. 飞艇用织物膜材单轴拉伸蠕变强度试验与模型[J]. 复合材料学报, 2021, 39(0): 1-8
引用本文: 宋寅搏, 陈务军, 高成军, 等. 飞艇用织物膜材单轴拉伸蠕变强度试验与模型[J]. 复合材料学报, 2021, 39(0): 1-8
Yinbo SONG, Wujun CHEN, Chengjun GAO, Longlong CHEN, Xiaoqing WANG, Yongsheng YAN. Uniaxial tensile creep experiment and creep model of fabric for airship structures[J]. Acta Materiae Compositae Sinica.
Citation: Yinbo SONG, Wujun CHEN, Chengjun GAO, Longlong CHEN, Xiaoqing WANG, Yongsheng YAN. Uniaxial tensile creep experiment and creep model of fabric for airship structures[J]. Acta Materiae Compositae Sinica.

飞艇用织物膜材单轴拉伸蠕变强度试验与模型

基金项目: 国家自然科学基金 (51778362)
详细信息
    通讯作者:

    陈务军,博士,教授,博士生导师,研究方向为超轻航空、宇航、近空间结构构造物分析理论与设计技术 E-mail: cwj@sjtu.edu.cn

  • 中图分类号: TB332

Uniaxial tensile creep experiment and creep model of fabric for airship structures

  • 摘要: 聚酯纤维织物类膜材因其轻质高强、耐候性好等特点常被用于飞艇结构的蒙皮材料,其在高应力水平下的蠕变失效行为决定飞艇结构长期安全性能,但目前尚未有相关的性能测试标准及研究。为研究此类膜材的蠕变性能,选用以Vectran纤维为基布材料的膜材在极限应力的85%、80%、75%、70%四组应力水平下进行单轴拉伸蠕变试验,分析了蠕变过程中膜材应变、模量以及蠕变破坏时间等参数关于应力水平的变化规律,并给出基于应力水平的蠕变强度包络线拟合公式;通过牛顿迭代法建立了参数化的四单元蠕变模型及蠕变破坏准则,可以较为准确反映材料在高应力水平下的蠕变破坏规律。



  • 图  1  Vectran-PVF织物膜材的细观结构

    Figure  1.  Mesostructure of Vectran-PVF fabric material

    图  2  Vectran-PVF膜材试样尺寸及试验方案

    Figure  2.  Configuration of Vectran-PVF fabric specimens and experimental scheme

    图  3  Vectran-PVF膜材蠕变应变曲线阶段划分

    Figure  3.  Stage division of Vectran-PVF fabric creep strain curve

    图  4  各应力水平下的Vectran-PVF膜材试样应变值

    Figure  4.  Strain comparison of Vectran-PVF fabric specimens under various stress levels

    图  5  各应力水平下Vectran-PVF膜材试样的蠕变应变曲线

    Figure  5.  Creep strain curves of Vectran-PVF fabric specimens under various stress levels

    图  6  各应力水平下Vectran-PVF膜材试样的蠕变模量曲线

    Figure  6.  Creep modulus curves of Vectran-PVF fabric specimens under various stress levels

    图  7  基于应力水平的Vectran-PVF膜材蠕变强度包络线

    Figure  7.  Envelope of Vectran-PVF fabric creep strength based on stress levels

    图  8  基于蠕变强度包络线的Vectran-PVF膜材试样寿命预测

    Figure  8.  Life prediction based on Vectran-PVF fabric creep strength envelope

    图  9  宏观和细观尺度的Vectran-PVF膜材试样破坏形态

    Figure  9.  Macroscopic and mesoscopic views of Vectran-PVF fabric specimen failure

    图  10  聚合物的四单元蠕变模型

    Figure  10.  Common creep model of polymers based on combination of spring elements and dashpot elements

    图  11  蠕变模型与Vectran-PVF膜材蠕变试验结果对比

    Figure  11.  Comparison between Vectran-PVF fabric creep model and experimental results

    表  1  Vectran-PVF膜材蠕变试验设备及参数

    Table  1.   Instruments parameters of Vectran-PVF fabric creep testing

    Test equipmentMeasuring rangeAccuracyError
    Electronic universal testing machine0~5000 N0.1 N±0.5%
    Displacement meter0~800 mm0.008 mm±1%
    Thickness gauge0~12.7 mm0.001 mm±1%
    下载: 导出CSV

    表  2  Vectran-PVF膜材模型预测带与试验结果的极限应变值对比

    Table  2.   Comparison of ultimate strain values of Vectran-PVF fabric between model prediction zone and test results

    StressUltimate strain/%Error/%
    ExperimentCreep model
    85%σu2.402.33-2.550.0
    80%σu2.332.29-2.370.0
    75%σu2.222.04-2.105.4
    70%σu2.111.78-1.8910.4
    下载: 导出CSV
  • [1] CHEN Yonglin, LI Shuai, DING Kai, et al. Investigation of tear strength of an airship envelope fabric by theoretical method and uniaxial tear test [J]. Journal of Engineered Fibers and Fabrics, 2019, 14: 1558925019879295.
    [2] SHI Taibai, HU Jianhui, CHEN Wujun, et al. A refined numerical model for determining inflation-burst behavior of composite membrane structures[J]. Polymer Testing,2020,81:106123. doi: 10.1016/j.polymertesting.2019.106123
    [3] SHI Taibai, CHEN Wujun, GAO Chengjun, et al. Investigation of mechanical behavior of weld seams of composite envelopes in airship structures[J]. Composite Structures,2018,201:1-12.
    [4] QIU Zhenyu, CHEN Wujun, GAO Chengjun, et al. Initial configuration and nonlinear mechanical analysis of stratospheric nonrigid airship envelope[J]. Journal of Aerospace Engineering,2019,32(2):04018155. doi: 10.1061/(ASCE)AS.1943-5525.0000989
    [5] SUN Guojun, LI Longjun, XUE Suduo, et al. Mechanical properties of polyester-coated fabric membrane material subjected to uniaxial loading at elevated temperatures[J]. Journal of Materials in Civil Engineering,2021,33(7):04021169. doi: 10.1061/(ASCE)MT.1943-5533.0003771
    [6] ZHAO Bing and CHEN Wujun. Rate-dependent mechanical properties and elastic modulus of ETFE foils used in inflated forming of transparency air-inflated cushion membrane structures[J]. Engineering Structures,2021,227:111404. doi: 10.1016/j.engstruct.2020.111404
    [7] HU Jianhui, LI Yipo, CHEN Wujun, et al. A combined loading-creep model of ETFE foils for flat-patterning structures[J]. Thin-Walled Structures,2020,157:106976. doi: 10.1016/j.tws.2020.106976
    [8] CHEN Bo, GUO Liping, ZHANG Wenxiao, et al. Compressive creep behavior of cellulose fiber reinforced concrete// IOP Conference Series: Earth and Environmental Science[J]. IOP Publishing,2021,825(1):012022.
    [9] 宋彦琦, 李小龙, 马宏发, 等. 基于有损伤体元件的广义Kelvin模型蠕变全过程探究[J]. Applied Mathematics & Mechanics

    (1000-0887), 2021, 42(6). SONG Yanqi, LI Xiaolong, MA Hongfa, et al. Research on the whole creep process of the generalized kelvin model based on damaged body elements [J]. Applied Mathematics & Mechanics (1000-0887), 2021, 42(6)(in Chinese).
    [10] LI Yintang, WU Minger. Uniaxial creep property and viscoelastic–plastic modelling of ethylene tetrafluoroethylene (ETFE) foil[J]. Mechanics of Time-Dependent Materials,2015,19(1):21-34. doi: 10.1007/s11043-014-9248-2
    [11] A Fairhurst, M Thommen, C Rytka. Comparison of short and long term creep testing in high performance polymers[J]. Polymer Testing,2019,78:105979. doi: 10.1016/j.polymertesting.2019.105979
    [12] DUAN Xiaochang, YUAN Hongwei, TANG Wei, et al. A phenomenological primary–secondary–tertiary creep model for polymer-bonded composite materials[J]. Polymers,2021,13(14):2353. doi: 10.3390/polym13142353
    [13] ZHANG Yongjun, LIU Xiu, YIN Boyuan, et al. A nonlinear fractional viscoelastic-plastic creep model of asphalt mixture[J]. Polymers,2021,13(8):1278. doi: 10.3390/polym13081278
    [14] LIU Wenbo, ZHANG Shuguang. An improved unsteady creep model based on the time dependent mechanical parameters[J]. Mechanics of Advanced Materials and Structures,2021,28(17):1838-1848. doi: 10.1080/15376494.2020.1712624
    [15] American Society for testing and materials. Test Methods for Tensile, Compressive, and Flexural Creep and Creep-Rupture of Plastics: ANSI/ASTM D2990-2009[S].
    [16] 全国纺织品标准化技术委员会基础标准分技术委员会. 纺织品 织物拉伸性能 第1部分: 断裂强力和断裂伸长率的测定(条样法): GB/T 3923.1-2013

    S]. Basic standards sub Technical Committee of national textile Standardization Technical Committee. Textiles-Tensile properties of fabrics Part 1: Determination of maximum force and elongation at maximum force using the strip method: GB/T 3923.1-2013[S](in Chinese).
    [17] 中华人民共和国工业和信息化部. 膜结构用涂层织物拉伸蠕变性能试验方法: FZ/T 60037-2013

    S]. Ministry of industry and information technology of the people's Republic of China. Coated fabrics for membrane structures—Test method for tensile creep: FZ/T 60037-2013[S](in Chinese).
    [18] DANG Haoyuan, ZHAO Zhenqiang, LIU Peng, et al. A new analytical method for progressive failure analysis of two-dimensional triaxially braided composites[J]. Composites Science and Technology,2020,186:107936. doi: 10.1016/j.compscitech.2019.107936
    [19] HU Jianhui, CHEN Wujun, ZHAO Bing, et al. Uniaxial tensile mechanical properties and model parameters determination of ethylene tetrafluoroethylene (ETFE) foils[J]. Construction and Building Materials,2015,75:200-207. doi: 10.1016/j.conbuildmat.2014.10.017
    [20] WANG Xiaoyan, WANG Xiao, ZHANG Xiaochun, et al. Creep damage characterization of UNS N10003 alloy based on a numerical simulation using the Norton creep law and Kachanov–Rabotnov creep damage model[J]. Nuclear Science and Techniques,2019,30(4):1-9.
    [21] S Samadi, S Jin, H Harmuth. Combined damaged elasticity and creep modeling of ceramics with wedge splitting tests[J]. Ceramics International,2021,47(18):25846-25853. doi: 10.1016/j.ceramint.2021.05.315
