一种高剥离强度和透气性的玻纤/纺粘无纺布复合滤材的制备工艺与性能

熊晨; 张久政; 王洪

doi:10.13801/j.cnki.fhclxb.20210615.002

一种高剥离强度和透气性的玻纤/纺粘无纺布复合滤材的制备工艺与性能

doi: 10.13801/j.cnki.fhclxb.20210615.002

熊晨¹,
张久政²,
王洪^1, ,

1.
东华大学　纺织面料技术教育部重点实验室，上海 201620
2.
中国船舶重工集团公司　第七〇七研究所九江分部，九江 332000

详细信息

通讯作者:
王洪，博士，教授，硕士生导师，研究方向为多孔功能材料、生物质材料和再生资源材料　E-mail：wanghong@dhu.edu.cn

中图分类号: TS176
计量
- 文章访问数: 1032
- HTML全文浏览量: 502
- PDF下载量: 64
- 被引次数: 0
出版历程
- 收稿日期: 2021-05-06
- 修回日期: 2021-05-25
- 录用日期: 2021-06-05
- 网络出版日期: 2021-06-15
- 刊出日期: 2022-03-23

Preparation and properties of a glass fiber/spunbond composite filter with high peel strength and permeability

1.
Key Laboratory of Textile Science & Technology, Ministry of Education, Donghua University, Shanghai 201620, China
2.
No.707 Research Institute Jiujiang Branch, China Shipbuilding Industry Corporation, Jiujiang 332000, China

摘要

摘要: 玻纤滤材具有过滤精度高和纳污量大等优点，但其耐折和耐压性能较差，需要与非织造布复合以提高其加工性和使用寿命，但传统的上胶复合工艺容易造成玻纤复合滤材透气性下降。将热熔胶树脂颗粒通过熔喷技术以超细纤维形式均匀负载到纺粘布上，进一步利用热轧复合技术与玻纤滤材复合，得到了剥离强力高、透气性基本不变的玻纤/纺粘复合滤材。通过对比复合玻纤滤材的剥离强度和透气性变化，发现超细纤维负载量对复合滤材的性能影响最大，当负载量为8 g/m²时，复合滤材剥离强度即可达到要求，对透气性也不会造成明显影响。综合考虑产品性能与生产实际，建立了最佳复合工艺为上胶量8 g/m²、辊间距0.3 mm、热轧温度120℃、热轧速度15 m/min，在此工艺下玻纤滤材和纺粘布间达到了较好的粘合效果，且复合滤材透气性变化较小。
- 熔喷 /
- 玻纤滤材 /
- 热熔胶 /
- 复合 /
- 透气性
Abstract: Glass fiber materials, a kind of filter medium, have advantages of high filtration accuracy and large holding capacity of pollution. It is usually composited with nonwoven materials to improve its processability and service life by overcoming the poor folding ability and pressure resistance. However, the air permeability of this kind of composites will be decreased caused by the hot melt adhesive coating method. In this paper, this issue is addressed by creating a melt-blown fibrous bonding layer of hot melt resin rather than just coating a compact film between glass fiber medium and spunbond nonwoven materials. By this approach, the loading amount of melt-blown fibrous layer plays a significant role in the filtration performance of this filter medium. The results show that a high peel strength can be achieved but without compromising the permeability when loading 8 g/m² melt-blown fibers. And, considering the properties of the product and the production, a filter medium product with good mechanical properties and filtration performance can be fabricated when setting the loading amount of melt-blown fibers, gauge, temperature, and speed of hot calender at 8 g/m², 0.3 mm, 120℃ and 15 m/min, respectively.
- melt-blown /
- glass fiber filter /
- hot melt adhesive /
- composite /
- air permeability

HTML全文

图 1 玻纤/纺粘无纺布复合滤材试样制备工艺路线图

Figure 1. Diagram of glass fiber/spunbond filter compounding process

下载: 全尺寸图片幻灯片

图 2 A热熔胶和B热熔胶的差示扫描量热 (DSC) 曲线图对比

Figure 2. Comparison of differential scanning calorimeter (DSC) curve for hot melt adhesive A and B

下载: 全尺寸图片幻灯片

图 3 B热熔胶的热降解性能

Figure 3. Thermal degradation properties of B hot melt adhesive

下载: 全尺寸图片幻灯片

图 4 不同温度下B热熔胶的温度-熔体流动速率(MFR)变化

Figure 4. Melting mass flow rate (MFR) change of hot melt adhesive B under different temperature

下载: 全尺寸图片幻灯片

图 5 热熔胶纤维形态结构

Figure 5. Fiber morphology and structure of hot melt adhesive

下载: 全尺寸图片幻灯片

图 6 剥离试验中玻纤/纺粘无纺布复合滤材破损照片

Figure 6. Photo of damaged glass fiber/spunbond composite filter damage during peeling test

下载: 全尺寸图片幻灯片

图 7 热轧温度100℃下的玻纤/纺粘无纺布复合滤材

Figure 7. Glass fiber/spunbond composite filter calendered at 100℃

下载: 全尺寸图片幻灯片

图 8 热轧速度为15 m/min时的玻纤/纺粘无纺布复合滤材截面SEM图像

Figure 8. Cross section SEM images of fiber/spunbond composite filter calendered at the speed of 15 m/min

下载: 全尺寸图片幻灯片

表 1 热熔胶剥离强力

Table 1. Peel strength of hot melt adhesives

Glue number	A	B	C
Peel strength/N	37.62	36.49	11.96
Notes: A, B—Different kinds of polyester hot melt adhesive; C—Polyamide hot melt adhesive.

下载: 导出CSV

表 2 玻纤/纺粘复合滤材透气性能测试

Table 2. Air permeability test of fiber/ spunbond composite filter

Microfiber loading/ (g·m⁻²)	Peel strength/ (N·cm⁻²)	Permeability/ (mm·s⁻¹)
5	3.3	168.5
8	Breakage	165.9
12	Breakage	154.0
Note: Air permeability of the original glass fiber filter material is 185.2 mm/s.

下载: 导出CSV

表 3 温度对玻纤/纺粘无纺布复合滤材透气率的影响

Table 3. Permeability of fiber/spunbond composite filter calendered at different temperatures

Calendering temperature/℃	120	150
Permeability/(mm·s⁻¹)	165.9	164.9
Note: Air permeability of the original glass fiber filter material is 185.2 mm/s.

下载: 导出CSV

表 4 热轧速度对玻纤/纺粘无纺布复合滤材透气率的影响

Table 4. Permeability of fiber/spunbond composite filter calendered at different speed

Calendering speed/(m·min⁻¹)	5	10	15
Permeability/(mm·s⁻¹)	171.0	165.9	168.0

下载: 导出CSV
