含孔玻璃纤维/环氧树脂复合材料-铝合金层板的拉伸损伤行为与热暴露响应

谢波涛 高亮 江帅 李梦军

谢波涛, 高亮, 江帅, 等. 含孔玻璃纤维/环氧树脂复合材料-铝合金层板的拉伸损伤行为与热暴露响应[J]. 复合材料学报, 2020, 37(11): 1-9
引用本文: 谢波涛, 高亮, 江帅, 等. 含孔玻璃纤维/环氧树脂复合材料-铝合金层板的拉伸损伤行为与热暴露响应[J]. 复合材料学报, 2020, 37(11): 1-9
Botao XIE, Liang GAO, Shuai JIANG, Mengjun LI. Tensile damage behavior and thermal exposure response of glass fiber/epoxy resin composite-aluminum alloy laminates with an open-hole[J]. Acta Materiae Compositae Sinica.
Citation: Botao XIE, Liang GAO, Shuai JIANG, Mengjun LI. Tensile damage behavior and thermal exposure response of glass fiber/epoxy resin composite-aluminum alloy laminates with an open-hole[J]. Acta Materiae Compositae Sinica.

含孔玻璃纤维/环氧树脂复合材料-铝合金层板的拉伸损伤行为与热暴露响应

基金项目: 国家自然科学基金(11502031);2019年吉林省预算内基本建设资金(产业技术研究与开发)计划项目(2019C046-6)
详细信息
    通讯作者:

    高亮,博士,副教授,研究方向为轻质复合材料及结构多功能一体化 E-mail:gaol@ccut.edu.cn

  • 中图分类号: TB332

Tensile damage behavior and thermal exposure response of glass fiber/epoxy resin composite-aluminum alloy laminates with an open-hole

  • 摘要: 采用试验和数值方法研究了含孔玻璃纤维/环氧树脂复合材料-铝合金层板(glass fiber/epoxy resin composite-aluminum alloy laminates, GLARE)层板在不同热暴露温度下的拉伸剩余强度和损伤失效模式,揭示了层间损伤、纤维损伤及基体损伤的演化过程。结果表明:随着热暴露温度升高,含孔GLARE层板剩余强度不断下降,拉伸破坏呈现出明显的纤维断裂与层间分层混合失效模式。热暴露温度越高或开孔直径越大,GLARE层板的层间分层损伤区域越小。随着载荷的增大,沿加载方向的0°纤维和基体的损伤分别呈现出类似“漏斗”形和“花瓣”状的损伤演化形式,而层间损伤区域呈现出一对相对开孔对称的三角形损伤演化形式。基于GLARE层板的剩余强度和损伤失效模式的数值仿真与试验结果吻合较好。
  • 图  1  GLARE3-3/2层板铺层设计

    Figure  1.  Layup design of GLARE3-3/2 laminate

    图  2  GLARE层板固化工艺

    Figure  2.  Curing process for GLARE laminate

    图  3  GLARE层板制备工艺流程

    Figure  3.  Preparation process of GLARE laminate

    图  4  含圆形孔GLARE3-3/2层板试样示意图

    Figure  4.  Schematic diagram of GLARE3-3/2 laminate with an open-hole

    图  5  含孔GLARE3-3/2层板单向拉伸数值模型

    Figure  5.  Numerical model for unidirectional tensile of GLARE3-3/2 with an open-hole

    图  6  不同热暴露温度下GLARE3-3/2层板应力-应变曲线((a) 25℃, (b) 80℃, (c) 120℃)及不同温度下剩余强度随直径的变化(d)

    Figure  6.  Stress-strain curves of GLARE3-3/2 laminate at different thermal exposure temperatures ((a) 25℃, (b) 80℃, (c) 120℃) and variation of residual strength with diameter at different temperatures(d)

    图  7  GLARE3-3/2层板试验与仿真应力-应变曲线

    Figure  7.  Experimental and numerical stress-strain curves of GLARE3-3/2 laminate

    图  8  GLARE3-3/2层板试件拉伸断裂失效

    Figure  8.  Tensile fracture of GLARE3-3/2 laminate with an open-hole

    图  9  含孔GLARE3-3/2层板层间损伤的温度响应

    Figure  9.  Temperature response of interlaminar damage of GLARE3-3/2 laminate with an open-hole

    表  1  2024-T3铝合金材料性能

    Table  1.   Material properties of aluminum 2024-T3

    MaterialE1/GPaE2/GPaG12/GPaν12t/mm
    2024-T3 72 27 0.33 0.5
    下载: 导出CSV

    表  2  玻璃纤维/环氧树脂预浸料材料性能

    Table  2.   Mechanical properties of glass fiber/epoxy resin prepreg

    ParameterValue
    Longitudinal stiffness E11/GPa 48.75a
    Transverse stiffness E22/GPa 14.33a
    Out-of-plane stiffness E33/GPa 14.33a
    Poisson’s ratio υ12, υ13 0.252a
    Poisson’s ratio υ23 0.32a
    Shear modulus G12, G13/MPa 5 100a
    Shear modulus G23/MPa 5 100a
    Longitudinal tensile strength XT/MPa 1 280b
    Longitudinal compressive strength XC/MPa 800b
    Transverse tensile strength YT/MPa 40b
    Transverse compressive strength YC/MPa 145b
    Shear strength S12, S23, S13/MPa 73b
    Out-of-plane tensile strength ZT/MPa 40b
    Note: Superscripts ‘a’ and ‘b’ represent the data from experimental tests and research literature[13], respectively.
    下载: 导出CSV

    表  3  纤维增强树脂复合材料失效准则[16-17]

    Table  3.   Failure criteria of fiber reinforced resin composite[16-17]

    Failure modeFailure criterion
    Fiber tensile (${\varepsilon _{11}} > 0$) $F_{{\rm{f}}t}^2 = {\left( {\dfrac{{{\varepsilon _{11}}}}{{X_{\rm{T}}^\varepsilon }}} \right)^2} + {\left( {\dfrac{{{\varepsilon _{12}}}}{{S_{12}^\varepsilon }}} \right)^2} + {\left( {\dfrac{{{\varepsilon _{13}}}}{{S_{13}^\varepsilon }}} \right)^2}$
    Fiber compression (${\varepsilon _{11}} \leqslant 0$) $F_{{\rm{fc}}}^2 = {\left( {\dfrac{{{\varepsilon _{11}}}}{{X_{\rm{C}}^{11}}}} \right)^2}$
    Matrix tensile ($({\varepsilon _{22}} + {\varepsilon _{33}}) \geqslant 0$) $F_{{\rm{mt}}}^2 = {\left( {\dfrac{{{\varepsilon _{11}} + {\varepsilon _{33}}}}{{Y_{\rm{T}}^\varepsilon }}} \right)^2} + \left( {\dfrac{1}{{S{{_{23}^\varepsilon }^2}}}} \right)\left( {{\varepsilon _{23}}^2 - \dfrac{{{E_{22}}{E_{33}}}}{{{G_{23}}^2}}{\varepsilon _{22}}{\varepsilon _{33}}} \right) + {\left( {\dfrac{{{\varepsilon _{12}}}}{{S_{12}^\varepsilon }}} \right)^2} + {\left( {\dfrac{{{\varepsilon _{13}}}}{{S_{13}^\varepsilon }}} \right)^2}$
    Matrix compression ($({\varepsilon _{22}} + {\varepsilon _{33}}) < 0$) $\begin{array}{l} F_{{\rm{mc}}}^2 = {\left( {\dfrac{{{E_{22}}{\varepsilon _{22}} + {E_{33}}{\varepsilon _{33}}}}{{2{G_{12}}S_{12}^\varepsilon }}} \right)^2} + \left( {\dfrac{{{\varepsilon _{22}} + {\varepsilon _{33}}}}{{Y{{_{\rm{C}}^\varepsilon }^2}}}} \right)\left[ {{{\left( {\dfrac{{{E_{22}}Y_C^\varepsilon }}{{2{G_{12}}S_{12}^\varepsilon }}} \right)}^2} - 1} \right] +\\ \quad\quad\dfrac{1}{{S{{_{23}^\varepsilon }^2}}}\left( {{\varepsilon _{23}}^2 - \dfrac{{{E_{22}}{E_{33}}}}{{{G_{23}}^2}}{\varepsilon _{22}}{\varepsilon _{33}}} \right) + {\left( {\dfrac{{{\varepsilon _{12}}}}{{S_{12}^\varepsilon }}} \right)^2} + {\left( {\dfrac{{{\varepsilon _{13}}}}{{S_{13}^\varepsilon }}} \right)^2} \\ \end{array} $
    Delamination failure (${\varepsilon _{33}} \geqslant 0$) $F_{{\rm{ld}}}^2 = {\left( {\dfrac{{{\varepsilon _{33}}}}{{Z_{\rm{T}}^\varepsilon }}} \right)^2} + {\left( {\dfrac{{{\varepsilon _{13}}}}{{S_{13}^\varepsilon }}} \right)^2} + {\left( {\dfrac{{{\varepsilon _{23}}}}{{S_{23}^\varepsilon }}} \right)^2}$
    Notes:$X_{\rm{T}}^\varepsilon $—Longitudinal tensile strength strain; $X_{\rm{C}}^\varepsilon $—Longitudinal compressive strength strain; $Y_{\rm{T}}^\varepsilon $—Transverse tensile strength strain; $Y_{\rm{C}}^\varepsilon $—Transverse compressive strength strain; $S_{12}^\varepsilon $、$S_{13}^\varepsilon $ and $S_{23}^\varepsilon $—Shear strain in the corresponding directions; $Z_{\rm{T}}^\varepsilon $—Out-of-plane tensile strength strain.
    下载: 导出CSV

    表  4  界面粘接单元的材料属性[24]

    Table  4.   Mechanical properties of cohesive element[24]

    Elastic propertiesDamage initiationDamage evolution
    E/GPaG/GPaNmax/MPaSmax/MPaTmax/MPaGIC /J·m−2GIIC/J·m−2GIIIC/J·m−2
    2 0.75 65 38 38 2 4 4
    下载: 导出CSV

    表  5  2024-T3铝合金的各向同性硬化数据[25]

    Table  5.   Isotropic hardening data of aluminum 2024-T3[25]

    Yield stress/MPa300320340355375390410430450470484
    Plastic strain/% 0.0 0.16 0.047 0.119 0.449 1.036 2.13 3.439 5.133 8.0 14.71
    下载: 导出CSV

    表  6  含孔GLARE3-3/2层板的损伤演化

    Table  6.   Damage evolution of GLARE3-3/2 with an open-hole

    Open-hole diameter DFiber and matrix tensile damage evolution
    2 mm Increment step 144 722 153 859 164 658 182 922
    4 mm Increment step 115 583 152 266 157 353 170 045
    6 mm Increment step 112 855 132 492 144 664 151 741
    8 mm Increment step 71 256 83 994 95 396 127 229
    10 mm Increment step 56 025 64 276 75 626 115 428
    下载: 导出CSV
  • [1] NOWAK T. Elastic-plastic behavior and failure analysis of selected fiber metal laminates[J]. Composite Structures,2017,183:450-456.
    [2] PATIL N A, MULIK S S, WANGIKAR K S, et al. Characterization of glass laminate aluminium reinforced epoxy-A review[J]. Procedia Manufacturing,2018,20:554-562. doi:  10.1016/j.promfg.2018.02.083
    [3] 吴素君, 解晓伟, 晋会锦, 等. 纤维金属层板力学性能的研究现状[J]. 复合材料学报, 2018, 35(4):733-747.

    WU S J, XIE X W, JIN H J, et al. Mechanical properties of fibre metal laminates: A review[J]. Acta Materiae Compositae Sinica,2018,35(4):733-747(in Chinese).
    [4] VOGELESANG L B, VLOT A. Development of fibre metal laminates for advanced aerospace structures[J]. Journal of Materials Processing Technology,2000,103(1):1-5. doi:  10.1016/S0924-0136(00)00411-8
    [5] TAMER S, EGEMEN A, MUSTAFA Ö B, et al. A review: Fibre metal laminates, background, bonding types and applied test methods[J]. Materials & Design,2011,32(7):3671-3685.
    [6] 李尧. 飞机温度环境适应性要求分析和确定技术探讨[J]. 装备环境工程, 2008, 5(6):60-64. doi:  10.3969/j.issn.1672-9242.2008.06.013

    LI Y. Analysis and confirmation techniques for requirements of temperature environmental worthiness of aircraft[J]. Equipment Environmental Engineering,2008,5(6):60-64(in Chinese). doi:  10.3969/j.issn.1672-9242.2008.06.013
    [7] RANS C D, ALDERLIESTEN R C, BENEDICTUS R. Predicting the influence of temperature on fatigue crack propagation in fibremetal laminates[J]. Engineering Fracture Mechanics,2011,78(10):2193-2201. doi:  10.1016/j.engfracmech.2011.04.005
    [8] PATRYK J, JAROSLAW B, BARBARA S. Interlaminar shear strength of fibre metal laminates after thermal cycles[J]. Composite Structures,2018,206:876-887. doi:  10.1016/j.compstruct.2018.09.001
    [9] MAJERSKI K, SUROWSKA B, BIENIAS J. The comparison of effects of hygrothermal conditioning on mechanical properties of fibre metal laminates and fibre reinforced polymers[J]. Composites Part B: Engineering,2018,142:108-116. doi:  10.1016/j.compositesb.2018.01.002
    [10] 李晓峰, 曲贵民, 李博儒. 圆孔对GLARE层合板抗冲击性能的影响[J]. 复合材料学报, 2016, 33(9):2104-2114.

    LI X F, QU G M, LI B R. Effect of circular hole on impact resistance of GLARE laminates[J]. Acta Materiae Compositae Sinica,2016,33(9):2104-2114(in Chinese).
    [11] 翟豹, 王树彬, 张博明, 等. 阳极氧化工艺对纤维-铝合金层板力学性能的影响[J]. 复合材料学报, 2013, 30(03):154-159.

    ZHAI B, WANG S B, ZHANG B M, et al. Effect of anodizing process on the mechanical properties of glass fiber reinforced aluminum laminates[J]. Acta Materiae Compositae Sinica,2013,30(03):154-159(in Chinese).
    [12] 陈凯, 胡玉冰, 刘成. 温度对Ti/Cf/PMR超混杂层板力学性能的影响研究[J]. 机械制造与自动化, 2017, 46(6):31-34.

    CHEN K, HU Y B, LIU C. Influence of temperature on mechanical properties of Ti/Cf/PMR hybrid laminates[J]. Machine Building & Automation,2017,46(6):31-34(in Chinese).
    [13] KADDOUR A, HINTON M. Input data for test cases used in benchmarking triaxial failure theories of composites[J]. Journal of Composite Materials,2012,46(19-20):2295-2312. doi:  10.1177/0021998312449886
    [14] 中华人民共和国航空航天工业部. HB/Z197-1991结构胶接铝合金磷酸阳极化工艺规范[S]. 北京: 航空航天工业部, 1991.

    Aerospace Industry of Thee People’s Republic of China. HB/Z197-1991 Phosphoric acid anodizing process specifications of structural bonding of aluminum alloy[S]. Beijing: Aerospace Industry, 1991(in Chinese).
    [15] 中国国家标准化管理委员会. GB/T 1447-2005纤维增强塑料拉伸性能试验方法[S]. 北京: 中国标准出版社, 2005.

    Standardization Administration of the People’s Republic of China. GB/T 1447-2005 Fiber-reinforced plastics composites-determination of tensile properties[S]. Beijing: Standards Press of China, 2005(in Chinese).
    [16] BOTELHO E C, ALMEIDA R S, PARDINI L C, et al. Elastic properties of hygrothermally conditioned glare laminate[J]. International Journal of Engineering Science,2007,45(1):163-172. doi:  10.1016/j.ijengsci.2006.08.017
    [17] HASZIN Z. Failure criteria for unidirectional fiber composites[J]. Journal of Applied Mechanics,1980,47:329-334. doi:  10.1115/1.3153664
    [18] HUANG C H, LEE Y J. Experiments and simulation of the static contact crush of composite laminated plates[J]. Composite Structures,2003,61:265-270. doi:  10.1016/S0263-8223(02)00047-8
    [19] XIAO J R, GAMA B A, Gillespie J W. Progressive damage and delamination in plain weave S-2 glass/SC-15 composites under quasi-static punch-shear loading[J]. Composite Structures,2007,78:182-196. doi:  10.1016/j.compstruct.2005.09.001
    [20] FRIZZELL R M, MCCARTHY C T, MCCARTHY M A. Predicting the effects of geometry on the behaviour of fibre metal laminate joints[J]. Composite Structures,2011,93:1877-1889. doi:  10.1016/j.compstruct.2011.01.018
    [21] LINDE P, BOER H D. Modelling of inter-rivet buckling of hybrid composites[J]. Composite Structures,2006,73(2):221-228. doi:  10.1016/j.compstruct.2005.11.062
    [22] VO T P, GUAN Z W, CANTWELL W J, et al. Low-impulse blast behaviour of fibre-metal laminates[J]. Composite Structures,2012,94:954-965. doi:  10.1016/j.compstruct.2011.10.027
    [23] BENZEGGAGH M L, KENANE M. Measurement of mixed-mode delamination fracture toughness of unidirectional glass/epoxy composites with mixed-mode bending apparatus[J]. Composites Science and Technology,1996,56(4):439-449. doi:  10.1016/0266-3538(96)00005-X
    [24] SUGIMAN S, CROCOMBE A D, KATNAM K B. Investigating the static response of hybrid fibre-metal laminate doublers loaded in tension[J]. Composite Part B: Engineering,2014,42:867-884.
    [25] CHEN J F, MOROZOV E V, SHANKAR K, et al. Progressive failure analysis of perforated aluminium/CFRP fibre metal laminates using a combined elastoplastic damage model and including delamination effects[J]. Composite Structures,2014,114:64-79. doi:  10.1016/j.compstruct.2014.03.046
    [26] LIN Y, HUANG Y, HUANG T, et al. Open-hole tensile behaviour and failure prediction of carbon fibre reinforced aluminium laminates[J]. Polymer Composites,2018,39(11):123-138.
