聚乙烯亚胺修饰富勒烯的制备及其对聚丙烯热氧稳定性的影响

沈海峰 邵胜栋 王子路 郭正虹

沈海峰, 邵胜栋, 王子路, 等. 聚乙烯亚胺修饰富勒烯的制备及其对聚丙烯热氧稳定性的影响[J]. 复合材料学报, 2020, 37(11): 1-6 doi:  10.13801/j.cnki.fhclxb.20200421.004
引用本文: 沈海峰, 邵胜栋, 王子路, 等. 聚乙烯亚胺修饰富勒烯的制备及其对聚丙烯热氧稳定性的影响[J]. 复合材料学报, 2020, 37(11): 1-6 doi:  10.13801/j.cnki.fhclxb.20200421.004
Haifeng SHEN, Shengdong SHAO, Zilu WANG, Zhenghong GUO. Preparation of polyethyleneimine-decorated fullerene and its effect on thermal stability of polypropylene[J]. Acta Materiae Compositae Sinica. doi: 10.13801/j.cnki.fhclxb.20200421.004
Citation: Haifeng SHEN, Shengdong SHAO, Zilu WANG, Zhenghong GUO. Preparation of polyethyleneimine-decorated fullerene and its effect on thermal stability of polypropylene[J]. Acta Materiae Compositae Sinica. doi: 10.13801/j.cnki.fhclxb.20200421.004

聚乙烯亚胺修饰富勒烯的制备及其对聚丙烯热氧稳定性的影响

doi: 10.13801/j.cnki.fhclxb.20200421.004
基金项目: 国家自然科学基金(51991355)
详细信息
    通讯作者:

    郭正虹,博士,副教授,研究方向为阻燃高分子复合材料的研究 E-maill:guozhenghong@nit.zju.edu.cn

  • 中图分类号: O631.2+1

Preparation of polyethyleneimine-decorated fullerene and its effect on thermal stability of polypropylene

  • 摘要: 利用聚乙烯亚胺(PEI)分子中活泼的—NH—与富勒烯(C60)结构中C=C键之间的加成反应,制备了PEI修饰C60杂化物(C60-PEI),并采用FTIR、TEM等测试方法对C60-PEI的分子结构和形态进行表征。采用熔融共混法制备了C60-PEI/聚丙烯(PP)复合材料,并对其热性能和阻燃性能进行研究。热失重分析结果表明,C60-PEI可以更有效地发挥C60的自由基捕捉作用,对PP热稳定性的提高效果较C60更明显;氧化诱导测试(OIT)结果表明,C60-PEI/PP复合材料比C60/PP复合材料具有更优异的抗氧性能;微型量热测试也表明,燃烧过程中C60-PEI/PP复合材料比C60/PP复合材料具有更低的热释放量。
  • 图  1  C60、PEI和C60-PEI的FTIR图谱

    Figure  1.  FTIR spectra of C60, PEI and C60-PEI

    图  2  C60-PEI的合成示意图

    Figure  2.  Schematic diagram of C60-PEI synthesis

    图  3  C60(a)和C60-PEI(b)的TEM图像

    Figure  3.  TEM images of C60(a) and C60-PEI(b)

    图  4  C60、PEI和C60-PEI在N2气氛下的TG曲线

    Figure  4.  TG curves of C60, PEI and C60-PEI in N2

    图  5  PP、3C60/PP、(3C60+PEI)/PP、3C60-PEI/PP和3PEI/PP复合材料空气气氛下的TG曲线

    Figure  5.  TG curves for PP, 3C60/PP, (3C60+PEI)/PP, 3C60-PEI/PP and 3PEI/PP composites in air

    图  6  PP、3C60/PP、(3C60+PEI)/PP、3C60-PEI/PP和3PEI/PP复合材料空气气氛下的DTG曲线

    Figure  6.  DTG curves for PP, 3C60/PP, (3C60+PEI)/PP, 3C60-PEI/PP and 3PEI/PP composites in air

    图  7  PP、3C60/PP、(3C60+PEI)/PP和3C60-PEI/PP复合材料180℃的氧化诱导时间(OIT)曲线

    Figure  7.  Oxidation induced time (OIT) curves of PP, 3C60/PP, (3C60+PEI)/PP and 3C60-PEI/PP composites at 180℃

    图  8  PP、3C60/PP、(3C60+PEI)/PP和3C60-PEI/PP复合材料的热释放率曲线

    Figure  8.  Heat release rate curves of PP, 3C60/PP, (3C60+PEI)/PP and 3C60-PEI/PP composites

    表  1  富勒烯/聚丙烯(C60/PP)和C60-聚乙烯亚胺(PEI)/PP复合材料的配方

    Table  1.   Composition of fullrene/polypropylene(C60/PP) and C60-polyethyleneimine(PEI)/PP composites

    SamplePP1C60/PP2C60/PP3C60/PP1C60−PEI/PP2C60−PEI/PP3C60−PEI/PP(3C60+PEI)/PP
    PP/wt% 100 99 98 97 99 98 97 97
    C60/wt% 1 2 3 2.75
    C60-PEI/wt% 1 2 3
    PEI/wt% 0.25
    下载: 导出CSV

    表  2  C60/PP和C60-PEI/PP复合材料空气气氛下的TG测试结果

    Table  2.   TG test results of C60/PP and C60-PEI/PP composites in air

    SamplePP1C60/ PP2C60/PP3C60/PP1C60-PEI/PP2C60-PEI/PP3C60-PEI/PP(3C60+PEI)/PP
    Tonset/℃ 266.1 285.5 293.5 303.9 293.2 296.7 312.0 271.3
    Tmax/℃ 381.2 397.8 400.0 417.5 399.2 404.6 427.5 396.8
    Residue at 800oC/wt% 0.3 1.3 0.7 1.2 0.6 0 0 0.4
    Notes: Tonset—Initial degradation temperature; Tmax—Maximum degradation temperature.
    下载: 导出CSV

    表  3  PP、3C60/PP、(3C60+PEI)/PP和3C60-PEI/PP复合材料180℃的OIT测试结果

    Table  3.   OIT test results of PP, 3C60/PP, (3C60+PEI)/PP and 3C60-PEI/PP composites at 180℃

    SamplePP3C60/PP(3C60+PEI)/PP3C60−PEI/PP
    tmax/min 35.5 37.4 32.5 48.5
    OIT/min 5.8 10.2 2.6 17.5
    ΔH/(J·g−1) 6 119 5 176 5 088 3 909
    Notes: tmax—Time corresponding to maximum oxidant speed; ΔH—Enthalpy.
    下载: 导出CSV

    表  4  PP、3C60/PP、(3C60+PEI)/PP和3C60-PEI/PP复合材料微型量热测试结果

    Table  4.   Micro-calorimeter test results of PP, 3C60/PP, (3C60+PEI)/PP and 3C60-PEI/PP composites

    SamplePP3C60/PP(3C60+PEI)/PP3C60−PEI/ PP
    PHRR/(W·g−1) 1 176 1 003 1 173 880
    THR/(kJ·g−1) 41.9 39.8 42.8 37.5
    Tp/℃ 486 488 487 489
    Notes: PHRR—Peak of heat release rate; THR—Total heat release; Tp—Temperature to PHRR.
    下载: 导出CSV
  • [1] 李建军, 欧育湘. 阻燃理论[M]. 北京: 科学出版社, 2013.

    LI Jiangjun, OU Yuxiang. Theory of flame retardancy[M]. Beijing: Science Press, 2013(in Chinese).
    [2] 欧育湘. 阻燃剂[M]. 北京: 国防工业出版社, 2009.

    OU Yuxiang. Flame retardants[M]. Beijing: National Defence Industry Press, 2009(in Chinese).
    [3] RUØYCKA M, GLEBULTOWICZ J, WROCZY-SKI P. Present-day toxicity of smoke inhalation[J]. Acta Poloniae Pharmaceutica Durg Research, 2018, 75(2): 281-295.
    [4] VOORHEES K J. Analysis of soot produced from the combustion of polymeric materials[M]//NELSON G L. Fire and polymers Ⅱ. Washington: American Chemical Society, 1995: 393-406.
    [5] SAOTOME T, KOKUBO K, SHIRAKAWA S, et al. Polymer nanocomposites reinforced with C60 fullerene: Effect of hydroxylation[J]. Journal of Composite Materials,2011,45(25):2595-2601. doi:  10.1177/0021998311416682
    [6] SONG P A, LIU H, SHEN Y, et al. Fabrication of dendrimer-like fullerene (C60)-decorated oligomeric intumescent flame retardant for reducing the thermal oxidation and flammability of polypropylene nanocomposites[J]. Journal of Materials Chemistry,2009,19(9):1305-1313. doi:  10.1039/b815610g
    [7] ZHAO L P, GUO Z H, RAN S Y, et al. The effect of fullerene on the resistance to thermal degradation of polymers with different degradation processes[J]. Journal of Thermal Analysis and Calorimetry,2014,115(2):1235-1244. doi:  10.1007/s10973-013-3453-0
    [8] ZHAO L P, GUO Z H, CAO Z H, et al. Thermal and thermo-oxidative degradation of high density polyethylene/fullerene composites[J]. Polymer Degradation and Stability,2013,98(10):1953-1962. doi:  10.1016/j.polymdegradstab.2013.07.020
    [9] 周强, 卞军, 王刚, 等. 功能化纳米氧化石墨烯/POE-g-MAH/聚苯乙烯复合材料的制备与性能[J]. 复合材料学报, 2016, 33(2):240-248.

    ZHOU Qiang, BIAN Jun, WANG Gang, et al. Preparation and property of functionalized nano graphene oxide/POE-g-MAH/polystyrene composite[J]. Acta Materiae Compositae Sinica,2016,33(2):240-248(in Chinese).
    [10] 何飞雄, 卞军, 蔺海兰, 等. 功能化纳米石墨烯片/PP-PP-g-MAH复合材料的制备与表征[J]. 复合材料学报, 2015, 32(1):47-53.

    HE Feixiong, BIAN Jun, LIN Hailan, et al. Preparation and characterization of functionalized nano-graphene sheet/POE-g-MAH/polystyrene composite[J]. Acta Materiae Compositae Sinica,2015,32(1):47-53(in Chinese).
    [11] IDUMAH C I, HASSAN A, AFFAM A C. A review of recent developments in flammability of polymer nanocomposites[J]. Reviews in Chemical Engineering,2015,31(2):149-177.
    [12] XING W Y, YANG W, YANG W J, et al. Functionalized carbon nanotubes with phosphorus- and nitrogen-containing agents: Effective reinforcer for thermal, mechanical, and flame-retardant properties of polystyrene nanocomposites[J]. ACS Applied Materials & Interfaces,2016,8(39):26266-26274.
    [13] DITTRICH B, WARTIG K A, HOFMANN D, et al. The influence of layered, spherical, and tubular carbon nanomaterials’ concentration on the flameretardancy of polypropylene[J]. Polymer Composites,2015,36(7):1230-1241. doi:  10.1002/pc.23027
    [14] 卫保娟, 肖潭, 李雄俊, 等. 石墨烯与多壁碳纳米管增强环氧树脂复合材料的制备及性能[J]. 复合材料学报, 2012, 29(5):53-60.

    WEI Baojuan, XIAO Tan, LI Xiongjun, et al. Preparation and properties of graphene and MWCNTs reinforced epoxy resin composites[J]. Acta Materiae Compositae Sinica,2012,29(5):53-60(in Chinese).
    [15] LIU J C, ZHANG Y B, GUO Y B, et al. Effect of carbon black on the thermal degradation and flammability properties of flame-retarded high impact polystyrene/magnesium hydroxide/microencapsulated red phosphorus composite[J]. Polymer Composites,2018,39(3):770-782.
    [16] DITTRICH B, WARTIG K A, HOFMANN D, et al. Carbon black, multiwall carbon nanotubes, expanded graphite and functionalized graphene flameretarded polypropylene nanocomposites[J]. Polymers for Advanced Technologies,2013,24(10):916-926.
    [17] GUO Z H, YE R F, ZHAO L P, et al. Fabrication of fullerene-decorated graphene oxide and its influence on flame retardancy of high density polyethylene[J]. Composites Science and Technology,2016,129:123-129. doi:  10.1016/j.compscitech.2016.04.024
    [18] SONG P A, ZHAO L P, CAO Z H, et al. Polypropylene nanocomposites based on C60-decorated carbon nanotubes: Thermal properties, flammability, and mechanical properties[J]. Journal of Materials Chemistry,2011,21(21):7782-7788. doi:  10.1039/c1jm10395d
    [19] KRÄTSCHMER W, FOSTIROPOULOS K, HUFFMAN D R. The infrared and ultraviolet absorption spectra of laboratory-produced carbon dust: evidence for the presence of the C60 molecule[J]. Chemical Physics Letters,1990,170(2-3):167-170. doi:  10.1016/0009-2614(90)87109-5
    [20] 王冬梅, 曹金丽, 张怡, 等. 红外光谱法研究聚乙烯亚胺的结构[J]. 光谱学与光谱分析, 2016, 36(10):199-200.

    WANG Dongmei, CAO Jinli, ZHANG Yi, et al. The structure characterization of polyethylenimine vis FTIR[J]. Spectroscopy and Spectral Analysis,2016,36(10):199-200(in Chinese).
    [21] ZANETTI M, CAMINO G, REICHERT P, et al. Thermal behaviour of poly(propylene) layered silicate nanocomposites[J]. Macromolecular Rapid Communications,2001,22(3):176-180.
