微纳结构超疏水表面的浸润性及防冰性能

武壮壮 马国佳 崔向中 刘星

武壮壮, 马国佳, 崔向中, 等. 微纳结构超疏水表面的浸润性及防冰性能[J]. 复合材料学报, 2020, 37(0): 1-7
引用本文: 武壮壮, 马国佳, 崔向中, 等. 微纳结构超疏水表面的浸润性及防冰性能[J]. 复合材料学报, 2020, 37(0): 1-7
武壮壮, 马国佳, 崔向中, 等. 微纳结构超疏水表面的浸润性及防冰性能[J]. 复合材料学报, 2020, 37(0): 1-7
Citation: 武壮壮, 马国佳, 崔向中, 等. 微纳结构超疏水表面的浸润性及防冰性能[J]. 复合材料学报, 2020, 37(0): 1-7

微纳结构超疏水表面的浸润性及防冰性能

详细信息
    通讯作者:

    马国佳,博士,研究员,研究方向为微纳加工及仿生表面制备及工艺 E-mail:lemontree7678@163.com

  • 中图分类号: TB332

Wettability and anti-icing performance of micro-nano structure superhydrophobic surface

  • 摘要: 本文以Ti合金为基体材料,通过超快激光加工微结构并复合纳米SiO2/氟化聚氨酯涂料,获得了微纳结构的涂层表面,并与涂料喷涂获得的纳米涂层表面和未处理的Ti合金表面进行了对比分析研究。分别采用扫描电镜、超景深显微镜、接触角和冰结合力测量仪,研究分析了未处理Ti合金表面、纳米结构表面、微纳结构表面的表面形貌、疏水性、防覆冰性能。结果表明:具有微纳结构的涂层表面具有最佳的超疏水性,显示出158.9°的接触角,1.5°的滚动角;与未处理Ti合金表面、纳米结构表面相比,微纳结构表面冰结合力显著降低,表面冰结合强度约为410 kPa。
  • 图  1  未处理表面、纳米结构表面、微纳结构表面润湿关系

    Figure  1.  Wetting relationships of untreated surface, nanostructure surface, and micro-nanostructure surface

    图  2  方阵柱微结构示意图

    Figure  2.  Squarematrix column microstructure diagram

    图  3  冰结合力测试装置及测试试验图

    Figure  3.  Ice adhesion test device and test image

    图  4  Ti合金基体上的三种不同表面形貌:(a)方阵柱复合SiO2/氟化聚氨酯涂层形成微纳结构表面形貌,微结构由边长~100 μm,间距~210 μm,高度~50 μm的方形结构构成;(b)纳米结构(SiO2);(c)微纳结构表面的三维形貌图;(d)SiO2/氟化聚氨酯纳米结构涂层表面形貌;(e)纳米结构(SiO2);(f)未处理的Ti合金表面

    Figure  4.  Three different surface morphologies on the Ti alloy substrate: (a) the surface topography of the micro-nano structure formed by square matrix column and SiO2/fluorinated polyurethane coating,the microstructure consists of a square structure with a side length of ~100 μm, a pitch of ~210 μm and a height of ~50 μm; (b) nanostructure (SiO2); (c) three-dimensional topography of the surface of the micro-nanostructure; (d) the surface morphology of SiO2/fluorinated polyurethane nanostructured coating; (e) nanostructure (SiO2);(f) the untreated Ti alloy surface

    图  5  Ti合金基体上的三种表面接触角:方阵柱复合SiO2/氟化聚氨酯涂层构成的微纳结构表面、SiO2/氟化聚氨酯构成的纳米结构表面、未处理的Ti合金表面接触角(微纳结构表面(MN-)接触角为158.9°;纳米结构表面(N-)接触角为148.4°;未处理Ti合金表面(UT-)接触角为69.03°)

    Figure  5.  Three types of surface contact angle on Ti alloy substrate: contact angle of the micro-nano structure surface formed by square matrix column and SiO2/fluorinated polyurethane coating, the nanostructure surface formed by SiO2/fluorinated polyurethane coating, andthe untreated Tialloy surface.(The micro-nano structure surface (MN-) contact angle is 158.9°; the nanostructure surface (N-) contact angle is 148.4°; the untreated surface (UT-) contact angle is 69.03°)

    图  6  -10℃下Ti合金基体上三种表面冰结合强度:方阵柱复合SiO2/氟化聚氨酯涂层形成微纳结构表面、SiO2/氟化聚氨酯涂层纳米结构表面、未处理的Ti合金表面冰结合强度(同一工艺不同样品冰结合强度)

    Figure  6.  Three types of surface ice adhesion strength on Ti alloy substrate at -10℃:ice adhesion strengthof the micro-nano structure surface formed by square matrix column and SiO2/fluorinated polyurethane coating, the nanostructure surface formed by SiO2/fluorinated polyure- thane coating, and the untreated Tialloy surface (Ice adhesion strength of different samples with same process)

    图  7  −10℃ 下同一样品测量20次Ti合金基体上三种表面冰结合强度变化趋势 (方阵柱复合SiO2/氟化聚氨酯涂层构成的微纳结构表面、SiO2/氟化聚氨酯构成的纳米结构表面、未处理的Ti合金表面)

    Figure  7.  Trend of ice adhesion strength of three types of surface on Ti alloy substrate measured 20 times at −10℃(the micro-nano structure surface formed by square matrix column and SiO2/fluorinated polyurethane coating, the nanostructure surface formed by SiO2/fluorinated polyure- thane coating, and the surface of untreated Ti alloy)

  • [1] 陈凯, 王强, 夏祖西. 飞机超疏水表面的防冰性能研究进展[J]. 应用化工, 2016, 45(10):1969-1973.

    CHEN Kai, WANG Qiang, XIA Zuxi. Research progress of anti-icing performance of aircraft superhydrophobicsurface[J]. Journal of Applied Chemicals,2016,45(10):1969-1973(in Chinese).
    [2] 王冠, 张德远, 陈华伟. 飞机防冰--从传统到仿生的发展[J]. 工业技术创新, 2014, 1(2):241-250.

    WANG Guan, ZHANG Deyuan, CHEN Hua wei. Aircraft anti-icing developmentfrom tradi-tional to biomimetic[J]. IndustrialTechnologyInnovation,2014,1(2):241-250(in Chinese).
    [3] 马蕾, 王贤明, 宁亮. 飞机防冰涂料的研究进展[J]. 中国涂料, 2014, 29(1):11-14, 18. doi:  10.3969/j.issn.1006-2556.2014.01.004

    MA Lei, WANG Xianming, NING Liang. Research progress of aircraft anti-icing coatings[J]. China Paint,2014,29(1):11-14, 18(in Chinese). doi:  10.3969/j.issn.1006-2556.2014.01.004
    [4] 杨钦, 罗荘 竹, 谭生, 等. 超疏水自清洁涂层防结冰技术的研究进展[J]. 中国表面工程, 2016, 29(4):10-22. doi:  10.11933/j.issn.1007-9289.2016.04.002

    YANG Qin, LUO Yizhu, TAN Sheng, et al. Research progress of anti-icing technology for superhydrophobic self-cleaning coatings[J]. China Surface Engineering,2016,29(4):10-22(in Chinese). doi:  10.11933/j.issn.1007-9289.2016.04.002
    [5] NEINHUIS C, BARTHLOTT W. Characterization and distribution of water-repellent, self-cleaning plantsurfaces[J]. Annalsof Botany,1997,79(6):667-677. doi:  10.1006/anbo.1997.0400
    [6] BHUSHAN B, JUNG Y C. Natural and biomimetic artificial surfaces for superhydrophobicity, self-cleaning, low adhesion, and drag reduction[J]. Progress in Materials Science,2011,56(1):1-108. doi:  10.1016/j.pmatsci.2010.04.003
    [7] ZHANG Q, JIN B, WANG B, et al. Fabrication of a highly stable superhydrophobic surface with dual-scale structure and its antifrosting properties[J]. Industrial & Engineering Chemistry Research,2017,56(10):2754-2763.
    [8] 翟广坤, 李曙林, 陈素素, 等. 氟化改性硅树脂制备的超疏水涂层防覆冰性能[J]. 工程科学学报, 2018, 40(7):864-870.

    ZHAI Guangkun, LI Shulin, CHEN Susu, et al. Anti-icing performance of superhydrophobic coating prepared by fluorinated modified silicone resin[J]. Journal of Engineering Science,2018,40(7):864-870(in Chinese).
    [9] LATTHE S S, SUTAR R S, KODAG V S, et al. Selfcleaning superhydrophobic coatings: potential industrial applications[J]. Progress in Organic Coatings,2019,128:52-58. doi:  10.1016/j.porgcoat.2018.12.008
    [10] 刘建峰, 肖新颜. 溶胶-凝胶法超疏水含氟硅聚氨酯丙烯酸酯/SiO2杂化涂层的制备[J]. 高分子材料科学与工程, 2014, 30(6):130-135.

    LIU Jianfeng, XIAO Xinyan. Preparation of superhydrophobic fluorinated silicone urethane acrylate/SiO2 hybrid coating by sol-gel method[J]. Polymer Science and Engineering,2014,30(6):130-135(in Chinese).
    [11] WANG S, FENG L, JIANG L. One-step solutionimmersion process for the fabrication of stable bionic superhydrophobic surfaces[J]. Advanced Materials,2006,18(6):767-770. doi:  10.1002/adma.200501794
    [12] LIN Feng, LI Shuhong, LI Huanjun, et al. Superhydrophobic surface of aligned polyacry-lonitrile nanofibers[J]. Communications and Control Engineering,2002,41(7):1221-1223.
    [13] MA M, HILL R M. Superhydrophobic surfaces[J]. Current Opinion in Colloid & Interface Science,2006,11(4):193-202.
    [14] EBERT D, BHUSHAN B. Durable lotus-effect surfaces with hierarchical structure using micro- and nanosized hydrophobic silica particles[J]. Journal of Colloid and Interface Science,2012,368(1):584-591. doi:  10.1016/j.jcis.2011.09.049
    [15] BAKE A, MERAH N, MATIN A, et al. Preparation of transparent and robust superhydrophobic surfaces for self-cleaning applications[J]. Progress in Organic Coatings,2018,122:170-179. doi:  10.1016/j.porgcoat.2018.05.018
    [16] 马国佳, 刘星, 张伟, 等. 超疏水仿生表面制造及其应用[J]. 稀有金属材料与工程, 2018, 47(6):1866-1871.

    MA Guojia, LIU Xing, ZHANG Wei, et al. Fabrication and application of superhydrophobic bionic surface[J]. Rare Metal Materials and Engineering,2018,47(6):1866-1871(in Chinese).
    [17] DARMANIN T, GIVENCHY E T D, AMIGONI S, et al. Superhydrophobic surfaces by electrochemical processes[J]. Advanced Materials,2013,25(10):1378-1394. doi:  10.1002/adma.201204300
    [18] 郗金明. 超疏水_超双疏材料的制备与研究[D]. 北京: 中国科学院化学研究所, 2008.

    XI Jinming. Preparation and research of superhydrophobic_super double sparse materials[D]. Beijing: Institute of Chemistry, Chinese Academy of Sciences, 2008(in Chinese).
    [19] 黄建业. 仿生超疏水表面的制备_疏水稳定性与应用研究[D]. 西安: 西北工业大学, 2014.

    HUANG Jianye. Preparation of bionic superhy- drophobicsurface_research on hydrophobic stability and application[D]. Xi'an: Northwestern Polytechnical University, 2014(in Chinese).
    [20] 王强峰. 超浸润表面的制备及其防覆冰性能与机理的研究[D]. 杭州: 浙江大学, 2018.

    WANG Qiangfeng. Preparation of super-wetting surface and its anti-icing performance and mechanism[D]. Hangzhou: Zhejiang University, 2018(in Chinese).
    [21] FARHADI S, FARZANEH M, KULINICH SA. Anti-icing performance of superhydrophobic surfaces[J]. AppliedSurfaceScience,2011,257:6264-6269.
    [22] KULINICH S A, FARZANEH M. How wetting hysteresis influences ice adhesion strength on superhydrophobic surfaces[J]. Langmuir,2009,25(16):8854-8856. doi:  10.1021/la901439c
    [23] HAO Pengfei, LV Cunjing, ZHANG Xiwen. Freezing of sessile water droplets on surfaces with various roughness and wettability[J]. Applied Physics Letters,2014,16(104):1-5.
    [24] 杨钦. 工程实用性超疏水自清洁涂层防结冰行为及机理研究[D]. 重庆: 中国科学院大学, 2017.

    Yang Qin. Anti-icing behavior and mechanism of superhydrophobic self-cleaning coatings for engineering applications[D]. Chongqing: University of Chinese Academy of Sciences, 2017(in Chinese).
    [25] SCHUTZIUS T M, JUNG S, MAITRA T, et al. Spontaneous droplet trampolining on rigid superhydrophobic surfaces[J]. Nature,2015,527(7576):82-85. doi:  10.1038/nature15738
