预加方石英含量对SiO2基陶瓷型芯高温蠕变性能的影响

占红星 芦刚 严青松 查军辉 罗凌

占红星, 芦刚, 严青松, 等. 预加方石英含量对SiO2基陶瓷型芯高温蠕变性能的影响[J]. 复合材料学报, 2020, 37(0): 1-6
引用本文: 占红星, 芦刚, 严青松, 等. 预加方石英含量对SiO2基陶瓷型芯高温蠕变性能的影响[J]. 复合材料学报, 2020, 37(0): 1-6
占红星, 芦刚, 严青松, 等. 预加方石英含量对SiO2基陶瓷型芯高温蠕变性能的影响[J]. 复合材料学报, 2020, 37(0): 1-6
Citation: 占红星, 芦刚, 严青松, 等. 预加方石英含量对SiO2基陶瓷型芯高温蠕变性能的影响[J]. 复合材料学报, 2020, 37(0): 1-6

预加方石英含量对SiO2基陶瓷型芯高温蠕变性能的影响

基金项目: 国家自然科学基金(51861027);江西省优势科技创新团队重点项目(20181BCB19001)
详细信息
    通讯作者:

    芦刚,博士,副教授,研究方向为液态金属精密成形理论及工艺  Email:aimulalg@163.com

  • 中图分类号: TQ174.75

Effect of pre-added cristobalite content on high temperature creep properties of silicon-based ceramic core

  • 摘要: 将方石英作为第二相、锆英砂作为矿化剂加入到SiO2基陶瓷型芯基体材料中,采用热压注法制备陶瓷型芯试样。研究预加方石英含量对SiO2基陶瓷型芯性能的影响,分析在1550℃下预加方石英含量对SiO2基陶瓷型芯高温蠕变性能的影响机制。结果表明,随着预加方石英含量的增加,SiO2基陶瓷型芯抗弯强度和高温挠度逐渐减小、型芯的气孔率逐渐增加。当预加方石英含量为10wt%时,石英玻璃析晶速率最快,方石英开始相连构成耐高温的方石英骨架,型芯抵抗高温变形的能力显著提升,陶瓷型芯的综合性能最佳,其抗弯强度、高温挠度和气孔率分别为5.13 MPa、1.18 mm和40.55%。
  • 图  1  陶瓷型芯焙烧工艺曲线

    Figure  1.  Firing process curve of ceramic core

    图  2  预加方石英含量对陶瓷型芯高温挠度的影响

    Figure  2.  Effect of pre-added cristobalite content on high temperature deflection of ceramic core

    图  3  预加方石英含量对陶瓷型芯显气孔率和抗弯强度的影响

    Figure  3.  Effect of pre-added cristobalite content on apparent porosity and flexural strength of ceramic core

    图  4  预加不同含量方石英的陶瓷型芯XRD图谱

    Figure  4.  XRD pattern of ceramic core with different contents of cristobalite

    图  5  预加不同含量方石英的陶瓷型芯断口形貌

    Figure  5.  Fracture morphologies of ceramic core with different cristobalite contents

    表  1  陶瓷型芯原料配比(wt%)

    Table  1.   Raw material ratios of ceramic core (wt%)

    NumberingQuartz glass powderZircon sandCristobalite
    A0 85 15 0
    A1 80 15 5
    A2 75 15 10
    A3 70 15 15
    A4 65 15 20
    A5 60 15 25
    下载: 导出CSV
  • [1] 吴大观. 关于新版综合高性能涡轮发动机技术计划——兼谈航空发动机研制中“基础技术”和“验证机”的重要作用[J]. 航空发动机, 2003, 2929(2):1-4. doi:  10.3969/j.issn.1672-3147.2003.02.001

    WU Daguan. About the new version of the comprehensive high-performance turbine engine technology plan-also talk about the important role of "basic technology" and "verification machine" in the development of aero engine[J]. Aeroengine,2003,2929(2):1-4(in Chinese). doi:  10.3969/j.issn.1672-3147.2003.02.001
    [2] 梁启如, 吴玉胜, 刘孝福等. 航空发动机涡轮叶片铸造用陶瓷型芯研究进展[J]. 铸造, 2018, 67(09):790-793. doi:  10.3969/j.issn.1001-4977.2018.09.006

    LIANG Qiru, WU Yusheng, LIU Xiaofu, et al. Research progress of ceramic core for aeroengine turbine blade casting[J]. Foundry,2018,67(09):790-793(in Chinese). doi:  10.3969/j.issn.1001-4977.2018.09.006
    [3] 方昌德. 航空发动机的发展前景[J]. 航空发动机, 2004, 30(1):1-5. doi:  10.3969/j.issn.1672-3147.2004.01.001

    FANG Changde. Development prospects of aero engine[J]. Aeroengine,2004,30(1):1-5(in Chinese). doi:  10.3969/j.issn.1672-3147.2004.01.001
    [4] 赵效忠. 陶瓷型芯的制备与使用[M]. 北京: 科学出版社, 2013: 1.

    ZHAO Xiaozhong. Preparation and application of ceramic core[M]. Beijing: Science Press, 2013: 1(in Chinese).
    [5] Wei Q, Zhong J, Xu Z, et al. Microstructure evolution and mechanical properties of ceramic shell moulds for investment casting of turbine blades by selective laser sintering[J]. Ceramics International,2018,44(11):12088-12097. doi:  10.1016/j.ceramint.2018.03.227
    [6] KHAMKONGKAEO A, BOOTCHANONT A, KLYSUBUN W, et al. Effect of phosphate compound on physical and mechanical properties of SiO2 ceramic[J]. Ceramics International,2019,45(1):1356-1362. doi:  10.1016/j.ceramint.2018.07.253
    [7] KIM Y H, YEO J G, CHOI S C. Shrinkage and flexural strength improvement of silica-based composites for ceramic cores by colloidal alumina infiltration[J]. Ceramics International,2016,42(7):8878-8883. doi:  10.1016/j.ceramint.2016.02.137
    [8] KIM Y H, YEO J G, CHOI S C. The effect of fused silica crystallization on flexural strength and shrinkage of ceramic cores for investment casting[J]. Journal of the Korean Ceramic Society,2016,53(2):246-252. doi:  10.4191/kcers.2016.53.2.246
    [9] 李世峰, 张定华, 卜昆. 单晶空心涡轮叶片精确控形技术的研究进展[J]. 稀有金属材料与工程, 2012, 41(03):559-564. doi:  10.3969/j.issn.1002-185X.2012.03.039

    LI Shifeng, ZHANG Dinghua, BU Kun. Research progress in precise shape-controlling technology of single crystal hollow turbine blades[J]. Rare Metal Mat Eng,2012,41(03):559-564(in Chinese). doi:  10.3969/j.issn.1002-185X.2012.03.039
    [10] 覃业霞, 杜爱兵, 张睿. 精密铸造用氧化铝基复合陶瓷型芯[J]. 稀有金属材料与工程, 2007(S1):774-776.

    QIN Yexia, DU Aibing, ZHANG Rui, et al. Alumina-Based Ceramic Core Nano-Composites for Investment Casting[J]. Rare Metal Materials and Engineering,2007(S1):774-776(in Chinese).
    [11] WU H H, LI D C, TANG Y P, et al. Improving high temperature properties of alumina based ceramic cores containing yttria by vacuum impregnating[J]. Materials Science and Technology,2011,27(4):823-828. doi:  10.1179/026708309X12506933873062
    [12] 康海峰, 李飞, 赵彦杰, 徐华苹. 高温合金空心叶片精密铸造用陶瓷型芯与型壳的研究现状[J]. 材料工程, 2013(08):85-91. doi:  10.3969/j.issn.1001-4381.2013.08.014

    KANG Haifeng, LI Fei, ZHAO Yanjie, XU Huaping. Research status on ceramic cores and shells for superalloy hollow blades investment casting[J]. Journal of Materials Engineering,2013(08):85-91(in Chinese). doi:  10.3969/j.issn.1001-4381.2013.08.014
    [13] 顾国红, 曹腊梅. 熔模铸造空心叶片用陶瓷型芯的发展[J]. 铸造技术, 2002, 23(2):81-83.

    GU Guohong, CAO Lamei. Development of ceramic coresfor investment casting hollow blades[J]. Foundry Technology,2002,23(2):81-83(in Chinese).
    [14] 王俊奎, 周施真. 陶瓷基复合材料的研究进展[J]. 复合材料学报, 1990(04):1-8.

    WANG Junkui, ZHOU Shizhen. Research progress of ceramic matrix composites[J]. Acta Materiae Compositae Sinica,1990(04):1-8(in Chinese).
    [15] 芦刚, 于航, 严青松, 等. Al2O3纤维对SiO2基陶瓷型芯的烧缩阻滞[J]. 复合材料学报, 2018, 35(1):168-172.

    LU Gang, YU Hang, YAN Qingsong, et al. Effect of Al2O3 fiber on shrinkage blocking of SiO2 matrix ceramic core[J]. Acta Materiae Compositae Sinica,2018,35(1):168-172(in Chinese).
    [16] XU Z L, ZHONG J W, SU X L. Experimental study on mechanical properties of silica-based ceramic core for directional solidification of single crystal superalloy[J]. Ceramics International,2018,44:394-401. doi:  10.1016/j.ceramint.2017.09.189
    [17] WERESZCZAK A A, BREDER K, FERBER M K, et al. Dimensional changes and creep of silica core ceramics used in investment casting of superalloys[J]. Journal of materials science,2002,37(19):4235-4245. doi:  10.1023/A:1020060508311
    [18] KIM Y H, YEO J, LEE J S, et al. Influence of silicon carbide as a mineralizer on mechanical and thermal properties of silica-based ceramic cores[J]. Ceramics International,2016,42(13):14738-14742. doi:  10.1016/j.ceramint.2016.06.100
    [19] WILSON P J, BLACKBUM S, GREENWOOD R W, et al. The role of zircon particle size distribution, surface area and contamination on the properties of silica–zircon ceramic materials[J]. Journal of the European Ceramic Society,2011,31(9):1849-1855. doi:  10.1016/j.jeurceramsoc.2011.03.005
    [20] 陈昊, 李鑫, 牛书鑫, 等. 氧化硅/莫来石陶瓷型芯的析晶行为及性能研究[J]. 人工晶体学报, 2020, 49(05):902-907. doi:  10.3969/j.issn.1000-985X.2020.05.023

    CHEN Hao, LI Xin, NIU Shuxin, et al. Crystallization behavior and properties of silica/mullite ceramic cores[J]. Journal of Synthetic Crystals,2020,49(05):902-907(in Chinese). doi:  10.3969/j.issn.1000-985X.2020.05.023
    [21] 赵效忠. 陶瓷型芯的制备与使用[M]. 北京: 科学出版社, 2013: 165.

    ZHAO Xiaozhong. Preparation and application of ceramic core[M]. Beijing: Science Press, 2013: 165 ((in Chinese).
    [22] LI K, JIANG W, WANG S, et al. Effect of specimen thickness on the creep deformation of a silica-based ceramic core material[J]. Journal of Alloys and Compounds,2018,763:781-790. doi:  10.1016/j.jallcom.2018.05.253
    [23] CHAO C H, LU H Y. Optimal composition of zircon–fused silica ceramic cores for casting superalloys[J]. Journal of the American Ceramic Society,2002,85(4):773-779.
    [24] 田国利. 硅基陶瓷型芯方石英含量与叶片浇注不露芯率的关系[J]. 材料工程, 1995(07):33-35.

    TIAN Guoli. Effects of cristobalite contents of silica base ceramics core on the rate of qualified pouring[J]. Journal of Materials Engineering,1995(07):33-35(in Chinese).
    [25] 李倩, 马德文, 蒋殷红, 等. 影响定向空心叶片陶瓷型芯性能的一个重要因素──方石英含量的控制[J]. 材料工程, 1994(05):18-19.

    LI Qian, MA Dewen, JIANG Yinhong, et al. Effcet of cristoablite content on the properties of ceramic core in making directionally solidified hollow blade[J]. Journal of Materials Engineering,1994(05):18-19(in Chinese).
    [26] 国防科学技术工业委员会. 熔模铸造陶瓷型芯性能试验方法[S]. 北京: 中国航空综合技术研究所, 2004.

    State Administration of Science, Technology, and Industry for National Defense. Test method for properties of investment casting ceramic core[S]. Beijing: AVIC China Aero-Polytechnology Establishvient, 2004 (in Chinese).
    [27] WANG L Y, HON M H. The effect of cristobalite seed on the crystallization of fused silica based ceramic core-kinetic study[J]. Ceramics International,1995,21:187-193. doi:  10.1016/0272-8842(95)90909-3
    [28] BOGANOV A G, RUDENKO V S, BASHINA G L. Crystallization patterns and the nature of quartz galss[J]. Neorgan Materialy,1966,2(2):363-375.
