纳米SiO2与间苯二酚-双(二苯基磷酸酯)对聚碳酸酯-ABS合金的协同阻燃机制

高顺 郭正虹

高顺, 郭正虹. 纳米SiO2与间苯二酚-双(二苯基磷酸酯)对聚碳酸酯-ABS合金的协同阻燃机制[J]. 复合材料学报, 2020, 37(11): 1-11
引用本文: 高顺, 郭正虹. 纳米SiO2与间苯二酚-双(二苯基磷酸酯)对聚碳酸酯-ABS合金的协同阻燃机制[J]. 复合材料学报, 2020, 37(11): 1-11
Shun GAO, Zhenghong GUO. Synergistic flame retardant mechanism of nano SiO2 and resorcinol bis(diphenylphosphate) on polycarbonate-ABS blends[J]. Acta Materiae Compositae Sinica.
Citation: Shun GAO, Zhenghong GUO. Synergistic flame retardant mechanism of nano SiO2 and resorcinol bis(diphenylphosphate) on polycarbonate-ABS blends[J]. Acta Materiae Compositae Sinica.

纳米SiO2与间苯二酚-双(二苯基磷酸酯)对聚碳酸酯-ABS合金的协同阻燃机制

基金项目: 国家自然科学基金(51991355)
详细信息
    通讯作者:

    郭正虹,博士,副教授,主要从事阻燃高分子复合材料的研究 Tel:057488130140; E-maill:guozhenghong@nit.zju.edu.cn

  • 中图分类号: TB324

Synergistic flame retardant mechanism of nano SiO2 and resorcinol bis(diphenylphosphate) on polycarbonate-ABS blends

  • 摘要: 选用以凝聚相阻燃机制为主的间苯二酚-双(二苯基磷酸酯)(RDP)作为阻燃剂,纳米SiO2为协效剂,以熔融共混法制备了聚碳酸酯(PC)-丙烯腈-丁二烯-苯乙烯共聚物(ABS)阻燃合金。通过垂直燃烧(UL94)和锥形量热测试(Cone)探究了纳米SiO2与RDP复配对PC-ABS合金阻燃性能和燃烧行为的影响。采用SEM观察燃烧残炭的微观形貌,用EDS分析炭层表面元素含量的变化,进一步探究了纳米SiO2与RDP在PC-ABS凝聚相中的协效阻燃机制。通过拉伸性能和冲击性能测试研究纳米SiO2与RDP复配对PC-ABS合金力学性能的影响及甲基丙烯酸甲酯-丁二烯-苯乙烯(MBS)对合金的增韧增容作用。结果表明,纳米SiO2与RDP可以在凝聚相中形成Si—O—P化合物,对PC-ABS合金的燃烧炭层起到增强作用,从而改善了PC-ABS合金的阻燃性能;适量MBS的加入可以提高合金的冲击强度和断裂伸长率,但会降低其阻燃性能。
  • 图  1  阻燃SiO2-RDP/PC-ABS合金的热释放速率(a)、质量损失(b)、总热释放量(c)、总生烟量(d)、烟释放速率(e)、CO生成率(f)和CO2生成率(g)曲线

    Figure  1.  Heat release rate(a),mass loss(b),total heat release(c),total smoke release(d),smoke production rate(e),volume fraction of CO(f) and volume fraction of CO2(g) curves of flame retardant SiO2-RDP/PC-ABS blends

    图  2  10RDP/PC-ABS((a),(b),(c))、1SiO2-10RDP/PC-ABS((d),(e),(f))和1SiO2/PC-ABS((g),(h),(i))燃烧残炭形貌

    Figure  2.  Morphology of char residues of 10RDP/PC-ABS((a),(b),(c)),1SiO2-10RDP/PC-ABS((d),(e),(f)) and 1SiO2/PC-ABS((g),(h),(i)) after Cone tests

    图  3  10RDP/PC-ABS(a)、1SiO2-10RDP/PC-ABS(b)和1SiO2/PC-ABS(c)燃烧残炭的SEM图像

    Figure  3.  SEM images of char residues for 10RDP/PC-ABS(a),1SiO2-10RDP/PC-ABS(b) and 1SiO2/PC-ABS(c) after Cone tests

    图  4  1SiO2-10RDP/PC-ABS燃烧残炭表面的P元素(a)和Si元素(b)分布

    Figure  4.  P distribution(a) and Si distribution(b) of char residues for 1SiO2-10RDP/PC-ABS after Cone tests

    图  5  1SiO2-10RDP/PC-ABS合金的缺口冲击强度和拉伸强度(a)、断裂伸长率和弹性模量(b)和应力应变(c)随MBS添加量变化曲线

    Figure  5.  Izod impact strength and tensile strength(a), elongation at break and tensile modulus(b) and stress-strain(c) as the function of MBS loading for flame retardant 1SiO2-10RDP/PC-ABS blends

    图  6  PC-ABS((a),(b))、10RDP/PC-ABS((c),(d))、1SiO2-10RDP/PC-ABS((e),(f))和1SiO2-10RDP-20MBS/PC-ABS((g),(h))缺口冲击断面的SEM图像

    Figure  6.  SEM images for PC-ABS((a),(b))、10RDP/PC-ABS((c),(d))、1SiO2-10RDP/PC-ABS((e),(f)) and 1SiO2-10RDP-20MBS/PC-ABS((g),(h))

    表  1  阻燃SiO2-RDP-MBS/PC-ABS合金配比(质量分数/wt%)

    Table  1.   Formulations of flame retardant SiO2-RDP-MBS/PC-ABS blends (Mass fraction/wt%)

    Sample IDPCABSRDPSiO2PTFEMBS
    10RDP/PC-ABS 62.7 26.9 10 0.4
    0.5SiO2-10RDP/PC-ABS 62.4 26.7 10 0.5 0.4
    1SiO2-10RDP/PC-ABS 62.0 26.6 10 1 0.4
    2SiO2-10RDP/PC-ABS 61.3 26.3 10 2 0.4
    3SiO2-10RDP/PC-ABS 60.6 26.0 10 3 0.4
    4SiO2-10RDP/PC-ABS 59.9 25.7 10 4 0.4
    5SiO2-10RDP/PC-ABS 58.9 25.2 10 5 0.4
    6SiO2-10RDP/PC-ABS 58.5 25.1 10 6 0.4
    7SiO2-10RDP/PC-ABS 57.8 24.8 10 7 0.4
    1SiO2/PC-ABS 69.0 29.6 1 0.4
    1SiO2-10RDP-5MBS/PC-ABS 58.5 25.1 10 1 0.4 5
    1SiO2-10RDP-10MBS/PC-ABS 55.0 23.6 10 1 0.4 10
    1SiO2-10RDP-15MBS/PC-ABS 51.5 22.1 10 1 0.4 15
    1SiO2-10RDP-20MBS/PC-ABS 48.0 20.6 10 1 0.4 20
    1SiO2-10RDP-25MBS/PC-ABS 44.5 19.1 10 1 0.4 25
    PC—Polycarbonate; ABS—Acrylonitrile-butadiene-styrene copolymer; RDP—Resorcinol bis(diphenylphosphate); PTFE—Polytetrafluoroethylene; MBS—Methyl methacrylate-butadiene-styrene copolymer
    下载: 导出CSV

    表  2  阻燃SiO2-RDP-MBS/PC-ABS合金的UL94测试结果

    Table  2.   UL94 results for flame retardant SiO2-RDP-MBS/PC-ABS blends

    Sample ID$\bar t$1/s$\bar t$2/s$\bar t$1+$\bar t$2/sDripping/(Yes/No)UL94
    10RDP/PC-ABS 12.1 20.3 32.4 N V-1
    0.5SiO2-10RDP/PC-ABS 21.4 24.5 45.9 N V-1
    1SiO2-10RDP/PC-ABS 3.1 8.9 12.0 N V-0
    2SiO2-10RDP/PC-ABS 11.3 31.4 42.7 N V-1
    3SiO2-10RDP/PC-ABS 16.8 26.1 42.9 N V-1
    4SiO2-10RDP/PC-ABS 25.7 38.7 64.4 N V-1
    5SiO2-10RDP/PC-ABS >30 >60 >60 Y No-rating
    6SiO2-10RDP/PC-ABS >30 >60 >60 Y No-rating
    7SiO2-10RDP/PC-ABS >30 >60 >60 Y No-rating
    1SiO2/PC-ABS >30 >60 >60 N No-rating
    1SiO2-10RDP-5MBS/PC-ABS 16.2 24.5 40.7 N V-1
    1SiO2-10RDP-10MBS/PC-ABS 31.3 50.4 81.7 N V-2
    1SiO2-10RDP-15MBS/PC-ABS >30 >60 >60 Y No-rating
    1SiO2-10RDP-20MBS/PC-ABS >30 >60 >60 Y No-rating
    1SiO2-10RDP-25MBS/PC-ABS >30 >60 >60 Y No-rating
    t1—Self-extinguishing time after the first ignition; t2—Self-extinguishing time after the second ignition
    下载: 导出CSV

    表  3  阻燃SiO2-RDP/PC-ABS合金的锥形量热测试结果

    Table  3.   Cone data for flame retardant SiO2-RDP/PC-ABS blends

    Sample ID10RDP/PC-ABS1SiO2-10RDP/PC-ABS1SiO2/PC-ABS
    tign/s 41.5±0.5 42.0±1.0 38.5±0.5
    tPHRR/s 155.0±5.0 167.5±2.5 70±0.1
    PHRR/(kW·m−2) 444.8±22.3 379.1±5.4 566.1±16.8
    THR/(MJ·m−2) 68.2±0.4 70.4±1.5 92.0±1.3
    AHRR/(kW·m−2) 135.9±2.1 142.7±0.6 224.3±2.3
    AMLR/(g·s−1) 0.060±0.001 0.062±0.002 0.082±0.002
    AEHC/(MJ·kg−1) 19.9±0.1 20.4±0.6 24.5±0.4
    ASEA/(m2·kg−1) 1048.1±35.8 1068.0±15.1 838.2±45.4
    ACOY/(kg·kg−1) 0.146±0.001 0.156±0.002 0.083±0.001
    ACO2Y/(kg·kg−1) 1.383±0.001 1.382±0.014 1.738±0.041
    TSR/(m2·m−2) 3592.1±102.9 3682.1±85.3 3156.6±182.8
    CHR/% 6.86±0.03 6.94±0.53 5.76±0.98
    FGI/(kW·m−2·s−1) 2.87 2.26 8.09
    FPI/(m2·s·kW−1) 0.093 0.110 0.068
    tign—Time to ignition; tPHRR—Time to PHRR; PHRR—Peak heat release rate; THR—Total heat release at 600 s; AHRR—Average heat release rate; AMLR—Average mass loss rate; AEHC—Average effective heat of combustion; ASEA—Average specific extinction area; ACOY—Average yield of CO; ACO2Y—Average yield of CO2; TSR—Total smoke release; CHR—Char residue; FGI—Fire spread index; FPI—Fire performance index
    下载: 导出CSV

    表  4  锥形量热燃烧残渣的元素分析数据

    Table  4.   The EDS analysis of char residues after Cone tests

    Sample IDElement/at%
    COPSi
    1SiO2/PC-ABS 83.89 16.09 0.03
    10RDP/PC-ABS 79.44 18.02 2.54
    1SiO2-10RDP/PC-ABS 54.17 36.71 7.24 1.88
    下载: 导出CSV

    表  5  阻燃SiO2-RDP-MBS/PC-ABS合金的缺口冲击强度、拉伸强度、断裂伸长率和弹性模量测试结果

    Table  5.   Izod impact strength、tensil strength、elongation at break and tensile modulus tests for flame retardant SiO2-RDP-MBS/PC-ABS blends

    Sample IDIzod impact strength/(kJ·m−2)Tensile strength/MPaElongation at break/%Tensile modulus/MPa
    10RDP/PC-ABS 8.6±2.4 51.4±2.8 19.2±5.1 838.7±146.2
    1SiO2-10RDP/PC-ABS 6.0±1.1 50.9±3.7 18.6±3.1 893.2±168.4
    1SiO2-10RDP-5MBS/PC-ABS 8.1±0.6 47.8±2.4 14.9±3.1 372.2±366.1
    1SiO2-10RDP-10MBS/PC-ABS 13.1±3.5 39.8±2.9 25.1±6.8 504.1±84.6
    1SiO2-10RDP-15MBS/PC-ABS 15.4±1.5 36.9±2.9 37.9±5.8 406.2±178.5
    1SiO2-10RDP-20MBS/PC-ABS 26.8±3.5 32.3±3.3 29.1±4.1 414.9±105.9
    1SiO2-10RDP-25MBS/PC-ABS 23.1±0.9 27.7±2.6 24.5±8.1 468.1±149.1
    下载: 导出CSV
  • [1] LEE E J, PARK H J, KIM S M, et al. Effects of molecular weight of PC on mechanical properties of PC/ABS blends using high-shear rate processing[J]. Korean Chemical Engineering Research,2018,56(3):343-348.
    [2] PAWLOWSKI K H, SCHARTEL B. Flame retardancy mechanisms of aryl phosphates in combination with boehmite in bisphenol a polycarbonate/acrylonitrile-butadiene-styrene blends[J]. Polymer Degradation and Stability,2008,93(3):657-667. doi:  10.1016/j.polymdegradstab.2008.01.002
    [3] 朱世东, 徐自强, 何敏, 等. 纳米材料国内外研究进展-纳米材料的应用与制备方法[J]. 热处理技术与装备, 2010, 31(4):1-8. doi:  10.3969/j.issn.1673-4971.2010.04.001

    ZHU Shidong, XU Ziqiang, HE Min, et al. Research progress of nanomaterials at home and abroad - application and preparation of nanomaterials[J]. Heat Treatment Technology and Equipment,2010,31(4):1-8(in Chinese). doi:  10.3969/j.issn.1673-4971.2010.04.001
    [4] BEE S T, LIM K S, SIN L T, et al. Interactive effect of ammonium polyphosphate and montmorillonite on enhancing flame retardancy of PC/ABS composites[J]. Iranian Polymer Journal,2018,27(11):899-911. doi:  10.1007/s13726-018-0664-z
    [5] ZHANG W, LI Y G, MA H J, et al. Novel phosphorus-nitrogen-silicon copolymers with double-decker silsesquioxane in the main chain and their flame retardancy application in PC/ABS[J]. Fire and Materials,2018,42(8):946-957. doi:  10.1002/fam.2649
    [6] WEI P, TIAN G H, YU H Z, et al. Synthesis of a novel organic-inorganic hybrid mesoporous silica and its flame retardancy application in PC/ABS[J]. Polymer Degradation and Stability,2013,98(5):1022-1029. doi:  10.1016/j.polymdegradstab.2013.02.006
    [7] ZHENG K, CHEN L, LI Y, et al. Praparation and thermal properties of silica-graft-acrylonitrile-butadiene-styrene nanocomposites[J]. Polymer Engineering and Science,2004,44(6):1077-1082. doi:  10.1002/pen.20100
    [8] 徐晓楠, 卢林刚, 殷全明, 等. 四苯基双酚A二磷酸酯及复配纳米SiO2体系阻燃PC/ABS合金的热动力学分析[J]. 火灾科学, 2009, 18(2):95-100. doi:  10.3969/j.issn.1004-5309.2009.02.008

    XU Xiaonan, LU Lingang, YIN Quanming, et al. Thermo dynamic analysis of flame retardant PC/ABS alloy with tetraphenylbisphenol a diphosphate and nano-SiO2[J]. Fire Science,2009,18(2):95-100(in Chinese). doi:  10.3969/j.issn.1004-5309.2009.02.008
    [9] 钟柳, 刘治国, 欧育湘. BDP阻燃PC/ABS及其复合材料的阻燃性和热降解动力学[J]. 中国塑料, 2008, 22(5):25-29.

    ZHONG Liu, LIU Zhiguo, OU Yuxiang. Flame retardancy and thermal degradation kinetics of BDP flame retardant PC/ABS and its composites[J]. China Plastics,2008,22(5):25-29(in Chinese).
    [10] JANG B N, WILKIE C A. The thermal degradation of bisphenol A polycarbonate in air[J]. Thermochimica Acta,2005,426(1):73-84.
    [11] REALINHO V, HAURIE L, FORMOSA J, et al. Flame retardancy effect of combined ammonium polyphosphate and aluminium diethyl phosphinate in acrylonitrile-butadiene-styrene[J]. Polymer Degradation and Stability,2018,155:208-219. doi:  10.1016/j.polymdegradstab.2018.07.022
    [12] FENG J, CARPANESE C, FINA A. Thermal decomposition investigation of ABS containing Lewis-acid type metal salts[J]. Polymer Degradation and Stability,2016,129:319-327. doi:  10.1016/j.polymdegradstab.2016.05.013
    [13] PAPASPYRIDES C D, KILIARIS P. Polymer Green Flame Retardants[M]. 2014.
    [14] QI Z, ZHANG W, HE X, et al. High-efficiency flame retardency of epoxy resin composites with perfect T8 caged phosphorus containing polyhedral oligomeric silsesquioxanes (P-POSSs)[J]. Composites Science and Technology,2016,127(11):8-19.
    [15] MONTERO B, RAMIREZ C, RICO M, et al. Effect of an epoxy octasilsesquioxane on the thermodegradation of an epoxy/amine system[J]. Polymer International,2010,59(1):112-118. doi:  10.1002/pi.2698
    [16] LIU Y L, CHOU C I. The effect of silicon sources on the mechanism of phosphoruse-silicon synergism of flame retardation of epoxy resins[J]. Polymer Degradation and Stability,2005,90(3):515-522. doi:  10.1016/j.polymdegradstab.2005.04.004
    [17] 王德义. 含磷共聚酯/无机纳米复合材料的制备、性能与阻燃机理研究[D]. 成都, 四川大学, 2007.

    WANG Deyi. Preparation, properties and flame retardant mechanism of phosphorus containing copolyester/inorganic nanocomposites[D]. Chengdu, Sichuan University, 2007 (in Chinese).
    [18] YANG F, NELSON G L. PMMA/silica nanocomposite studies: synthesis and properties[J]. Journal of Applied Polymer Science,2004,91(6):3844-3850. doi:  10.1002/app.13573
    [19] 李斌, 王建祺. 聚合物材料燃烧性和阻燃性的评价-锥形量热仪法[J]. 高分子材料科学与工程, 1998, 14(5):15-19. doi:  10.3321/j.issn:1000-7555.1998.05.004

    LI Bin, WANG Jianqi. Evaluation of flammability and flame retardancy of polymer materials-CONE[J]. Polymer Materials Science and Engineering,1998,14(5):15-19(in Chinese). doi:  10.3321/j.issn:1000-7555.1998.05.004
    [20] KASHIWAGI T, GILMAN J W, BUTLER K M, et al. Flame retardant mechanism of silica gel/silica[J]. Fire and Materials,2000,24(6):277-289. doi:  10.1002/1099-1018(200011/12)24:6<277::AID-FAM746>3.0.CO;2-A
    [21] CHIANG C L, MA C C. Synthesis, characterization, thermal properties and flame retardance of novel phenolic resin/silica nanocomposites[J]. Polymer Degradation and Stability,2004,83(2):207-214. doi:  10.1016/S0141-3910(03)00262-3
    [22] SONG R J, ZHANG B Y, HUANG B T, et al. Effect of fillers on the fire retardancy of intumescent polypropylene compounds[J]. Journal of Applied Polymer Science,2006,102:5988-5993. doi:  10.1002/app.25178
    [23] SPONTON M, MERCADO L A, RONGDA J C, et al. Preparation, thermal properties and flame retardancy of phosphorus and silicon containing epoxy resins[J]. Polymer Degradation and Stability,2008,93(11):2025-2031. doi:  10.1016/j.polymdegradstab.2008.02.014
    [24] LI J, WEI P, LI L K, et al. Synergistic effect of mesoporous silica SBA-15 on intumescent flame-retardant polypropylene[J]. Fire and Materials,2011,35(2):83-91. doi:  10.1002/fam.1040
    [25] 徐晓楠, 张健. 二氧化硅对膨胀型阻燃聚乙烯的性能影响研究[J]. 火灾科学, 2004, 13(3):159-172.

    XU Xiaonan, ZHANG Jian. Effect of silica on the properties of intumescent flame retardant polyethylene[J]. Fire Science,2004,13(3):159-172(in Chinese).
    [26] DEMIR H, ARLAS E, BALKOSE D, et al. Synergistic effect of natural zeolites on flame retardant additives[J]. Polymer Degradation and Stability,2005,89(3):478-483. doi:  10.1016/j.polymdegradstab.2005.01.028
    [27] PICOUET P A, FERNANDEZ A, REALINI C E, et al. Influence of PA6 nanocomposite films on the stability of vacuum-aged beef loins during storage inmodified atmospheres[J]. Meat Science,2014,96(1):574-580. doi:  10.1016/j.meatsci.2013.07.020
